IBM THINKPAD T60 - Page 130

4
4
5
5
a
a
4
4
Remove the hinges (a) from the LCD panel.
Step Screw (quantity) Color Torque
4 M2 × 2.8 mm, flat-head, nylon-coated (4) Silver 0.167 Nm
(1.7 kgfcm)
Remove the LCD cable assembly (b) from the LCD panel.
6
7
b
Removing and replacing a FRU
124 MT 1951, 1952, 1953, 1954, 1955, 1956, 2007, 2008, 2009, 2613, 2623, and 2637
