v Attach the fan bracket.
v Secure the screws in order as shown in this figure.
Attention: Do not use an electric screwdriver to secure these screws.
4
2
3
1
5
Removing and replacing a FRU
92 MT 1951, 1952, 1953, 1954, 1955, 1956, 2007, 2008, 2009, 2613, 2623, and 2637
