Instruction Manual C100-AE
3.3 Quick programming guide for programmers in a hurry
Menu selection and programming
1. Use the PRG/CAL key to toggle from Measuring mode to Programming mode and viceversa.
2. In Programming mode the adjustable element is flashing.
3. The flashing element can be modified with the Ï or Ð keys.
( Ï or Ð → +1, -1 or move to the next display field ).
4. Press the ENTER key to confirm a flashing setting.
Menu-Overview
Input of .... Numeric Display Input or selection...
Static measurement
Dyn. measurement ( MIN, MAX, TIR, MEAN )
mm
inch
Master value for zero adjustment
Master values for gauge calibration
Programming the column display
Zero point of column display
Tolerance limits 1...4 as deviation from
nominal value
Coefficients for pneumatic converter
Instrument parameters for operation ( see below )
a. Resolution ( 1µm / 0.1µm or 0.0001 inch / 0.00001 inch )
b. Column range ( Auto, ± 1,5mm to ± 50µm or 0.1500 inch ... 0.0005 inch )
c. Controlling of display output by foot switch ( oFF, trAnS, hold )
d. Automatic zero adjustment (using keypad on / oFF, using foot switch on / oFF )
e. Serial data transfer continuous - SoC on / oFF / foot switch - Sot on/ oFF
f. Automatic gauge calibration ( on / oFF )
g. Column display mode ( StAndA - from bottom, CentrE - from center, toP - from top )
h. Tolerance marks FLASH - Tolerance marks are flashing when measured value is out
of tolerance
i. Password to secure programming ( 6-digit number )
j. Filter time value ( oFF, 1 = 10msec, ... 6 = 1sec. )
For quick help during programming use the programming reference card !!!
The card will provide you with more information and should be your main aid.
First-time users of the column gauge should carefully read through the instructions given in the
following chapter, which deals extensively with the different programme steps.
Users with a basic knowledge should use the following chapter for reference.
Set.OP
Unit
Preset
Set.Pnt
Set.tol.
0.50 A
SetUP
Measuring mode Î
Unit Î
Master value
s
Î
Nominal valu
Î
Tolerances Î
Probe mixin
Î
Setu
Î
