Instruction Manual C100-AE
1.6 Technical data
Mechanical characteristics
Case Aluminium, epoxy powder coated
Front panel Acrylic-glass front panel, anti-reflex
Keypad Spring loaded keys for feedback with sturdy rectangular
caps
Dimensions W x H x D / Weight 45 x 370 x 52 mm / approx. 820 g
Electrical characteristics
Power block Primary switched power supply with wide voltage input
Main voltage / Frequency 85 ... 260 V AC / 47...440 Hz
Max. power consumption 5,5 VA
Displays
Column display Scale with 100 LED's, 3-coloured, 254 mm long, automatic
colour selection and programmable tolerance marks
Numeric display 6-digit LED display; 6,4 mm, red
Mode, Unit, Range, Programming light fields 16 light fields with changeable labelling
Connections
Air pressure supply connection
Quick coupling for PU hose 8/6 mm
Air pressure supply ( input pressure regulator ) 4 - 8 bar / 60 - 120 psi
Air pressure ( C100-AE input ) 2 - 3 bar / 30 - 45 psi ( filtered air < 5µm )
Outlet of measuring air Coupling DN2,7
Connection of gauge head Nipple DN2,7 for PU hose 6/4 mm
Interface ( RS232 ) 9-pin. SUB-D male connector, Hardware according to EIA
RS232 Standard, Data format according to OPTO RS232
Trigger input / Tolerance outputs ( Tol. Out ) 9-pin. SUB-D socket
Trigger input for ext. contact / foot switch and serial output
for OC3, OE3 and OP3 adapters
Measurement parameters
Measurement range / Resolution ± 1,5 mm/ 0,1µm or ± 15 mm / 1µm
± 0,059 / 0.00001 inch or ± 0,59 / 0.0001 inch
Measurement rate 31,25 measurements / sec.
Resolution 16 Bit ( internal )
Environmental conditions
Operating temperature range 0 ... 45°C
Storage temperature range -30 ... +60°C
Type of protection IP50 ( CEI / IEC 529 )
Electromagnetic compatibility ( EMC )
Electromagnetic compatibility ( EMC ) Generation of interference according to EN50081-2
Resistance to interference according to EN50082-2
