IBR C100-AE - Connectors Round-Up; Dimensions

5
Instruction Manual C100-AE
102 mm
136.5 mm
390 mm
370 mm
45 mm
5
2
m
m
5°
1.4 Dimensions
1.5 Connectors round-up ( all accessories shown )
Figure :
Column display on footplate
