Sterilizer views
1. Door
9. Touch pad
17. Power socket
2. Door seal ring
10. Printer
18. Steam vent
3. Door lock
11. USB port
19. Condenser vent
4. Door handle
12. Main switch
20. Bacterial filter
5. Chamber
13. Distilled water tank
vent
21. Used water tank
vent(optional)
6. Door interlock
14. Used water tank vent
22. Rating plate
7. Distilled water tank
15. Safety valve
8. Screen
16. Circuit breaker
