Icar RPC 8BGA - Protection and Communication Parameters; Password and Communication Settings; Basic Protection Settings

s. 23 / 40
P14.n.03
Contact type
Adv
NO
NO/NC
P14.n.04
Delay ON
Adv
s
0.05
0.00-600.00
P14.n.05
Delay OFF
Adv
s
0.05
0.00-600.00
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M15 – PASSWORD
UoM
Default
Range
P15.01
Enable password
OFF
OFF-ON
P15.02
User level password
1000
0-9999
P15.03
Advanced level password
2000(*)
0-9999
P15.04
Remote access password
OFF
OFF/1-9999
P15.01 – If set to OFF, password management is disabled and anyone has access to the settings and commands menu.
P15.02 – With P15.01 enabled, this is the value to specify for activating user level access. See Password access chapter.
P15.03 – As for P15.02, with reference to Advanced level access.
P15.04 – If set to a numeric value, this becomes the code to specify via serial communication before sending commands from a remote control.
(*) Available value only if the controller is not installed on the ICAR cabinet
M16 –COMMUNICATION (COMn,n=1…2)
Psw
(M15)
UoM
Default
Range
P16.n.01
Node serial address
Usr
01
01-255
P16.n.02
Serial speed
Usr
bps
9600
1200
2400
4800
9600
19200
38400
57600
115200
P16.n.03
Data format
Usr
8 bit – n
8 bit, no parity
8 bit, odd
8bit, even
7 bit, odd
7 bit, even
P16.n.04
Stop bits
Usr
1
1-2
P16.n.05
Protocol
Usr
(various)
Modbus RTU
Modbus ASCII
Modbus TCP
P16.n.06
IP address
Usr
192.168.1.1
000.000.000.000 –
255.255.255.255
P16.n.07
Subnet mask
Usr
255.255.255.0
000.000.000.000 –
255.255.255.255
P16.n.08
IP port
Usr
1001
0-9999
P16.n.09
Channel function
Usr
Slave
Slave
Gateway
Mirror
P16.n.10
Client/server
Usr
Server
Client
Server
P16.n.11
Remote IP address
Usr
000.000.000.000
000.000.000.000-
255.255.255.255
P16.n.12
Remote IP port
Usr
1001
0-9999
P16.n.13
IP gateway address
Usr
000.000.000.000
000.000.000.000-
255.255.255.255
For more information download the complete manual of the RPC 8BGA power factor controller from the web site www.icar.com download area concerning the low voltage power
factor correction systems.
M17 – BASIC PROTECTIONS
Psw
(M15)
UoM
Default
Range
P17.01
Temperature unit of measure
Adv
°C
°C
°F
P17.02
Panel interior temperature measurement source
Adv
Internal sensor
Internal sensor
AINx
NTCx
P17.03
Channel nr. (x)
Adv
1
1-99
P17.04
Fan start temperature
Adv
°C/°F
25
0-212
P17.05
Fan stop temperature
Adv
°C/°F
20
0-212
P17.06
Panel interior temperature alarm threshold
Adv
°C/°F
55
0-212
P17.07
Capacitor current overload
Adv
ON
OFF
ON
P17.08
Capacitor current overload threshold
Adv
%
50
OFF / 0 – 150
P17.09
Immediate step disconnection threshold
Adv
%
83
OFF / 0 – 200
P17.10
Current overload alarm reset time
Adv
min
15
1 – 30
P17.11
Step trimming
Adv
ON
OFF / ON
P17.13
Maximum voltage threshold
Adv
%
110
OFF / 90...150
P17.14
Minimum voltage threshold
Adv
%
90
OFF / 60..110
