SERVICE MODULARI06/2014
5. SERVICE SPECIFICATION
• In servicing a machine, it is often, useful to compare that in
dividual units operating characteristics to those of a normally
o
perating machine.
• The data that follows gives those characteristics; however, be
aware that these values are for NEW, CLEAN machine oper
ating at 21 °C ambient and 15 °C water.
U
SE THESE NUMBERS AS A GUIDELINE ONLY.
Refrigerant charge R 404 A  gr.
Refrigerant metering device
Thermostatic expansion valve.
Nota: Always check nameplate on individual icemachine for
special refrigerant charge before charging the refrigeration sy-
stem.
Such refrigerant charge is the average charge for the M Modular
Cubers. However it is important to check nameplate for each
machine.
5.1 OPERATING CHARACTERISTICS
• On aircooled models during the freezing cycle, the dis
c
harge pressure is maintained between two preset values by
means of fan control condenser sensor; and at the same
time, the suction pressure will also decline reaching it’s low
est point just before harvest. Compressor amps experience a
similar drop.
O
n watercooled, the discharge pressure is constantly, main
tained during the freeze cycle by the water regulating valve.
However, suction pressure and compressor amps, will still de
cline as the machine freezes ice.
i
MODEL
Disch.
Pressure
Freeze max
bar
Disch.
Pressure
Freeze min
bar
Hi Pressure
CUT OUT bar
Suction
Pressure
Beginning
Freeze bar
Suction
Pressure end
Freeze bar
Cycle time
minutes
Amps
Compressor
Beginning
Freeze
Amps Com-
pressor end
Freeze
M132 - 230/50/1 17,5 14,0 30 4,3 2,3 15 3,8 3,2
M192 - 230/50/1 16,5 16,5 30 4,3 2,4 16 3,6 3,1
M202 - 230/50/1 17,5 15,5 33 3,5 2,0 15 4,7 3,6
M202 W - 230/50/1 16,5 16,5 30 3,5 2,2 16 4,2 3,4
M302 - 230/50/1 18 16 33 2,7 1,5 13 6,2 4,8
M302 W - 230/50/1 16,5 16,5 30 3,2 1,7 13 5,8 4,5
M402 - 230/50/1 18,5 16,5 33 2,0 1,8 12,5 8,6 6,4
M402 W - 230/50/1 16,5 16,5 30 3,5 1,9 14,5 9,0 6,7
M502 - 400/50/3 16 14 33 2,9 1,6 12 3,7 3,0
M502 W - 400/50/3 16,5 16,5 30 3,2 1,8 13,5 3,6 2,8
MODEL M132 M192 M202 M302 M402 M502
Air Cooled 50 Hz 500 800 700 850 1300 1500
Water cooled 50 Hz 450 600 500 550 650 1200
