Version: 2.0
IceTech PR350H
User’s manual
Date: 2017.07.03
Init: JM
By activating the “mode select” button, it is possible
to choose between automatic mode and single mode.
The default selection is automatic mode, which must
be selected for production. In single mode the
components can be operated individually.
Single mode controls
By activating the “Single mode” button, the manual
operation page will appear. On this page it is possible
to access the function in single mode, i.e. operating
the components one by one.
This page should only be operated by well-trained
staff and with reference to P&I diagram.
The components will be activated by pressing the
buttons. When the component is activated and
working properly, the button will turn green showing
“Component OK”.
Most components have real names like “purge valve”
and moving the hydraulic cylinders can be done by
starting the hydraulic motor and pressing the arrow
buttons.
The hydraulic valves have numbers corresponding to
the P&I diagram.
By pressing the “toothed wheel” button the “Setpoint”
(SV) page is activated.
The “set point” page contains a 2 column display of
set values for the current Dry Ice production. Fixed
set points are password protected and have
hardcoded limits to avoid unsafe production.
A special feature is the option to select an individual
pillow size for 3, 10 and 16mm extruder plates. For
example when changing the 3 mm extruder plate to a
16mm extruder plate, the program automatically uses
the new setpoint for the pillow size.
