Transmitting a Test Call D
Enter “TEST CALL” in the DSC CALLS menu. q
Selectorenterthedesiredindividualaddress. w
Aconrmationscreenappears. e
Push[CALL]totransmittheTestcall. r
Whentheacknowledgementcallisreceived,beepssound. t
Push[ALARMOFF]tostopthebeeps,andthenpush[EXIT] y
toreturntothenormaloperatingmode.
Transmitting a Test Acknowledgement Call D
Quick ACK:
When q
aTestcallisreceived,beepssound.
 Push[ALARMOFF]tostopthebeeps.
Push [ACK]. w
 •Push[INFO]todisplaytheTestcallinformation.
 Push[BACK]toreturntothepreviousscreen,orpush[ACK].
TheTestACKconrmationscreenisdisplayed. e
 Push[CALL]totransmittheacknowledgementcall.
Aftertransmittingtheacknowledgementcall,thetransceiver r
returnstothenormaloperatingmode.
Manual ACK:
Enter “TEST ACK” in the DSC CALLS menu. q
 •IfnoTestcallhasbeenreceived,the“TESTACK”itemwillnot
bedisplayed.
SelectadesiredTestcalltoreplyto,usingDialor[ w ∫]/[√],
thenpushDialor[ENT].
TheTestACKconrmationscreenisdisplayed. e
 Push[CALL]totransmittheacknowledgementcall.
Aftertransmittingtheacknowledgementcall,thetransceiver r
returnstothenormaloperatingmode.
Transmitting a Position Reply Call D
Quick Reply:
When q
aPositionRequestcallisreceived,beepssound.
Push[ALARMOFF]tostopthebeeps.
Push [ACK]. w
•Push[INFO]todisplaythePositionRequestcallinformation.
 Push[BACK]toreturntothepreviousscreen,orpush[ACK].
ThePositionReplyconrmationscreenisdisplayed. e
 Push[CALL]totransmitthereplycall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
Manual Reply:
Enter “POSITION REPLY” in the DSC CALLS menu. q
 •IfnoPositionRequestcallhasbeenreceived,the“POSITION
REPLY”itemwillnotbedisplayed.
SelectadesiredPositionRequestcalltoreplyto. w
ThePositionReplycallconrmationscreenisdisplayed. e
 Push[CALL]totransmittheacknowledgementcall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
Transmitting a Position Report Reply Call D
Quick Reply:
When q
aPositionReportRequestcallisreceived,beeps
sound.
Push[ALARMOFF]tostopthebeeps.
Push [ACK]. w
•Push[INFO]todisplaythePositionReportRequestcallinfor-
mation.
 Push[BACK]toreturntothepreviousscreen,orpush[ACK].
ThePositionReportReplyconrmationscreenisdisplayed. e
Push[CALL]totransmitthereplycall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
Manual Reply:
q
Enter “POSITION REPORT REPLY” in the DSC CALLS
menu.
 •IfnoPositionReportRequestcallhasbeenreceived,the“PO-
SITIONREPORTREPLY”itemwillnotbedisplayed.
SelectadesiredPositionReportRequestcalltoreplyto,us- w
ingDialor[∫]/[√],thenpushDialor[ENT].
The Position Report Reply call conrmation screen is dis- e
played.
 Push[CALL]totransmittheacknowledgementcall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
Transmitting a Polling Reply Call D
Quick Reply:
When q
aPollingRequestcallisreceived,beepssound.
Push[ALARMOFF]tostopthebeeps.
Push [ACK]. w
•Push[INFO]todisplaythePollingRequestcallinformation.
 Push[BACK]toreturntothepreviousscreen,orpush[ACK].
The e PollingReplyconrmationscreenisdisplayed.
 Push[CALL]totransmitthereplycall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
Manual Reply:
Enter q “POLLING REPLY” in the DSC CALLS menu.
 •If no PollingRequest call has been received, the“POLLING
REPLY”itemwillnotbedisplayed.
SelectadesiredPollingRequestcalltobereplied. w
e
ThePollingReplycallconrmationscreenisdisplayed.Push
[CALL]totransmittheacknowledgementcall.
Aftertransmittingthereplycall,thetransceiverreturnstothe r
normaloperatingmode.
¤1 Transmitting DSC calls
ToensurecorrectoperationoftheDSCfunction,makesure
yousetthesquelchcorrectly.
Transmitting an Individual Call D
Enter “INDIVIDUAL CALL” in the DSC CALLS menu. q
Selectorenterthedesiredindividualaddress. w
SelectRoutine,SafetyorUrgencyasthedesiredcalltype. e
NOTE:Whenacoaststationisselectedinstepw,thevoice
channel is automatically specied by the coast station.
Therefore,skipsteprandgodirectlytostept.
Selectadesiredintershipchannel. r
Aconrmationscreenappears. t
Push[CALL]totransmittheIndividualcall. y
Standby on Channel 70 until an acknowledgement is re- u
ceived.
When the acknowledgement ‘Able to comply’ is received, i
beepssoundandthescreenbelowisdisplayed.
 Push[ALARMOFF]tostopthebeeps,andthenselectthe
intershipchannelspeciedinstepr.
 •Adifferentintershipchannelwillbeautomaticallyselectedifthe
stationyoucalledcannotusethechannel.
 •Replyusingthemicrophone.Andgotostep
o.
 Or, when the acknowledgement ‘Unable to comply’ is re-
ceived,beepssound.
 Push [ALARM OFF] to stop the beeps.Then push [EXIT]
toreturn to theoperatingchannel (before youentered the
MENUscreen).
Aftercommunicating,push[EXIT]toreturntothenormalop- o
eratingmode.
Transmitting an Individual Acknowledgement D
Quick ACK:
When q
anIndividualcallisreceived,beepssound.
 Push[ALARMOFF]tostopthebeeps.
Push [ACK]. w
Selectoneofthreeoptions,AbletoComply,UnabletoCom- e
plyorProposeNewChannel,andthenpush[ENT].
TheIndividualACKconrmationscreenisdisplayed. r
Push[CALL]totransmittheacknowledgementcall. t
Replytothecallusingthemicrophone. y
Push[EXIT]toreturntothenormaloperatingmode. u
Manual ACK:
Enter “INDIVIDUAL ACK” in the DSC CALLS menu. q
 •WhennoIndividualcallhasbeenreceived,the“IndividualACK”
itemwillnotbedisplayed.
Selecta desired individual addressorID code toreplyto, w
usingDialor[∫]/[√],thenpush[ENT].
Performsteps e e to u,asdescribedin“QuickACK:”above.
Transmitting a Group Call D
Enter “GROUP CALL” in the DSC CALLS menu. q
Selectorenterthedesiredgroupaddress. w
Selectadesiredintershipchannel. e
Aconrmationscreenappears. r
Push[CALL]totransmittheGroupcall. t
Announcetheinformationusingthemicrophone. y
Aftertheannouncement,push[EXIT]toreturntothenormal u
operatingmode.
Transmitting an All Ships Call D
Enter “ALL SHIPS CALL” in the DSC CALLS menu. q
Selectadesiredcategory. w
 •Theselectablecategorymaydifferaccordingtotheconnected
transceiversetting.
Selectadesiredtrafcchannel. e
Aconrmationscreenappears. r
Push[CALL]totransmittheAllShipscall. t
Announcethemessageusingthemicrophone. y
Aftertheannouncement,push[EXIT]toreturntothenormal u
operatingmode.
Transmitting a Position Request Call D
Enter“POSITIONREQUEST”intheDSCCALLSmenu. q
Selectorenterthedesiredindividualaddress. w
Aconrmationscreenappears. e
 •Conrmthecallcontents.
Push[CALL]totransmitthePositionRequestCall. r
 •IfChannel70 is busy, the transceiver stands byuntil the
channelbecomesclear.
Whentheacknowledgementcallisreceived,beepssound. t
Push[ALARMOFF]tostopthebeeps,andthenpush[EXIT] y
toreturntothenormaloperatingmode.
Transmitting a Position Report Call D
Enter “POSITION REPORT” in the DSC CALLS menu. q
Selectorenterthedesiredindividualaddress. w
Aconrmationscreenappears. e
 •Conrmthecallcontents.
Push[CALL]totransmitthePositionReportCall. r
 •IfChannel70 is busy, the transceiver stands byuntil the
channelbecomesclear.
AfterthePositionReportCallhasbeentransmitted,thetrans- t
ceiverautomaticallyreturnstothenormaloperatingmode.
Transmitting a Polling Request Call D
Enter“POLLINGREQUEST”intheDSCCALLSmenu. q
Selectorenterthedesiredindividualaddress. w
Aconrmationscreenappears. e
 •Conrmthecallcontents.
Push[CALL]totransmitthePollingRequestCall. r
 •IfChannel70 is busy, the transceiver stands byuntil the
channelbecomesclear.
Whentheacknowledgementcallisreceived,beepssound. t
Push[ALARMOFF]tostopthebeeps,andthenpush[EXIT] y
toreturntothenormaloperatingmode.
+See “Instructions q” (z to ⁄5) or “Instructions e” (¤2 to ‹0) for other functions.
