• Removing the CONTROL unit
➀ Remove 2 knobs A.
➂ Unscrew 2 screws C, and remove the LCD plate.
➃ Remove the CONTROL unit.
A
➁ Unscrew 2 screws B, and remove the cover.
B
C
CONTROL UNIT
3 - 2
