Icom IC-706MKIIG

5 - 10
[PLL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
IC101 1140007881 S.IC TC190G08EFG0046JDZ/SC1246A
IC102 1130009581 S.IC TC7W66FU (TE12L,F)
IC201 1110003300 S.IC M5282FP 70CD
IC231 1110003091 IC LA4425A-E
IC271 1180000421 S.IC TA78L05F (TE12R,F)
IC281 1110002031 IC TA7808S (Q)
IC291 1180001071 S.IC TA7805F (TE16L,Q)
IC461 1130009230 S.IC LMX2306TMX/NOPB
IC541 1110003320 S.IC uPC2710T-E3
IC901 1140004550 S.IC M65343FP/SC1287
Q1 1560000331 S.FET 2SK210-GR (TE85R,F)
Q10 1530002571 S.TR 2SC4405-3-TL-E
Q21 1530002060 S.TR 2SC4081 T106 R
Q51 1530002060 S.TR 2SC4081 T106 R
Q71 1530002060 S.TR 2SC4081 T106 R
Q141 1590001330 S.TR DTA114EUA T106
Q142 1590001330 S.TR DTA114EUA T106
Q143 1590001330 S.TR DTA114EUA T106
Q144 1590001330 S.TR DTA114EUA T106
Q145 1590001330 S.TR DTA114EUA T106
Q161 1530002060 S.TR 2SC4081 T106 R
except [USA], [USA-1], [EUR], [EUR-1]
Q232 1590000680 S.TR DTC114EUA T106
Q251 1590000720 S.TR DTA144EUA T106
Q261 1590002310 S.TR DTC114EE TL
Q301 1560000491 S.FET 2SK508-T2B-A K52 [USA] only
Q321 1530003091 S.TR 2SC4213-B (TE85R,F)
Q322 1590000720 S.TR DTA144EUA T106
Q331 1560000491 S.FET 2SK508-T2B-A K52 [USA] only
Q351 1530003091 S.TR 2SC4213-B (TE85R,F)
Q352 1590000720 S.TR DTA144EUA T106
Q361 1560000491 S.FET 2SK508-T2B-A K52 [USA] only
Q362 1530002691 S.TR 2SC4116-GR (TE85R,F)
Q381 1530003091 S.TR 2SC4213-B (TE85R,F)
Q391 1530002691 S.TR 2SC4116-GR (TE85R,F)
Q461 1590000720 S.TR DTA144EUA T106
Q491 1560000541 S.FET 2SK880-Y (T5RICOM,F)
Q521 1590002480 S.TR UMC3N TR
Q621 1530002561 S.TR 2SC4403-3-TL-E
Q661 1530002561 S.TR 2SC4403-3-TL-E
Q681 1530002561 S.TR 2SC4403-3-TL-E
Q851 1590001330 S.TR DTA114EUA T106
Q931 1530002060 S.TR 2SC4081 T106 R
Q941 1530002060 S.TR 2SC4081 T106 R
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
D1 1720000590 S.VCP MA357 (TX)
D231 1750000520 S.DIO DAN222TL
D261 1750000520 S.DIO DAN222TL
D271 1710000780 S.DIO MA114 (TX)
D301 1720000831 S.VCP KV1770STL-G
D302 1790000620 S.DIO MA77 (TX)
D331 1720000831 S.VCP KV1770STL-G
D332 1790000620 S.DIO MA77 (TX)
D361 1790001400 S.VCP MA304B (TX)
D362 1790000620 S.DIO MA77 (TX)
D511 1790000620 S.DIO MA77 (TX)
D531 1750000620 S.DIO MA717WK (TX)
D601 1720000590 S.VCP MA357 (TX)
D701 1790000450 S.DIO MA862 (TX)
D731 1790000450 S.DIO MA862 (TX)
D732 1790000450 S.DIO MA862 (TX)
D761 1750000211 S.DIO 1SV237 (TE85R,F)
D762 1750000211 S.DIO 1SV237 (TE85R,F)
D821 1790001621 S.DIO 1SV308 (TPL3,F)
D822 1790001621 S.DIO 1SV308 (TPL3,F)
D825 1790001621 S.DIO 1SV308 (TPL3,F)
D851 1790001621 S.DIO 1SV308 (TPL3,F)
D861 1750000211 S.DIO 1SV237 (TE85R,F)
D862 1160000060 S.DIO DAN202U T106
D863 1790001250 S.DIO MA2S111-(TX)
D864 1790001250 S.DIO MA2S111-(TX)
D931 1790001250 S.DIO MA2S111-(TX)
FI71 2020001820 S.CER SFECV10M5FA00-R0 (SFECV10.5MA5S
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
X621 6050005712 XTL CR-275B (30.000 MHz)
[ESP], [OTH], [ITA], [ITR], [OTH-1], [ITR-1], [CHN], [CHN-01] only
L1 6130002970 COL LB-343
L11 6200005011 S.COL NLV25T-100J
L12 6200007830 S.COL ELJFC 4R7K-F except [EUR], [FRA], [USA]
L30 6200002041 S.COL NLV25T-101J
L41 6200003590 S.COL EXCCL3225U1
L42 6200003590 S.COL EXCCL3225U1
L43 6200003590 S.COL EXCCL3225U1
L44 6200003590 S.COL EXCCL3225U1
L45 6200001831 S.COL NLV32T-100J
L48 6200001831 S.COL NLV32T-100J
L71 6200002861 S.COL NLV25T-4R7J
L131 6200001831 S.COL NLV32T-100J
L161 6200002041 S.COL NLV25T-101J
L163 6200007730 S.COL LQW2BHN39NJ03L [ESP] only
L165 6200005180 S.COL MLF1608D R39K-T
L231 6140002220 COL LR-270 (TR6X3X2 3A9)
L238 6200005011 S.COL NLV25T-100J
S.=Surface mount
[PLL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
L251 6200007710 S.COL LQW2BHN27NJ03L
except [USA], [USA-1], [EUR], [EUR-1]
L301 6170000230 COL LW-25
L302 6190001281 COL #E544GN-110248
L303 6170000230 COL LW-25
L331 6170000230 COL LW-25
L332 6190001371 COL #E544GN-110254
L333 6170000230 COL LW-25
L363 6180000810 COL LAL 03NA 2R2M
L364 6180000810 COL LAL 03NA 2R2M
L366 6190001390 COL C-13975-4.5
L367 6200005011 S.COL NLV25T-100J
L382 6200003261 S.COL NLV32T-101J
L383 6180000810 COL LAL 03NA 2R2M
L391 6200005011 S.COL NLV25T-100J
L411 6140002220 COL LR-270 (TR6X3X2 3A9)
L461 6200005011 S.COL NLV25T-100J
L501 6200001981 S.COL NLV25T-1R0J
L531 6140002810 S.COL LR-317
L532 6200003540 S.COL MLF1608D R22K-T
L542 6200002920 S.COL ELJNC R33K-F
L600 6200002041 S.COL NLV25T-101J
L601 6130001100 COL LB-146
L621 6200003261 S.COL NLV32T-101J
L622 6200003590 S.COL EXCCL3225U1
L623 6150004521 S.COL LS-508-LF
L641 6200002001 S.COL NLV25T-3R3J
L642 6200004671 S.COL NLV25T-3R9J
L681 6150004831 S.COL LS-509-LF
L682 6150004831 S.COL LS-509-LF
L711 6200002160 S.COL ELJNC 82NK-F
L712 6200001630 S.COL ELJNC R10K-F
L713 6200002160 S.COL ELJNC 82NK-F
L741 6200002150 S.COL ELJNC 56NK-F
L742 6200003670 S.COL ELJNC 68NK-F
L743 6200003670 S.COL ELJNC 68NK-F
L771 6200002160 S.COL ELJNC 82NK-F
L781 6200001770 S.COL ELJNC 47NK-F
L782 6200002120 S.COL ELJNC 33NK-F
L801 6200005741 S.COL ELJRE 47NGFA
L802 6200005721 S.COL ELJRE 33NGFA
L811 6200005711 S.COL ELJRE 27NGFA
L812 6200005721 S.COL ELJRE 33NGFA
L821 6200007740 S.COL LQW2BHN47NJ03L
L822 6200007720 S.COL LQW2BHN33NJ03L
L823 6200007730 S.COL LQW2BHN39NJ03L
L824 6200007710 S.COL LQW2BHN27NJ03L
L861 6200005701 S.COL ELJRE 22NGFA
L862 6200005681 S.COL ELJRE 15NGFA
L871 6200005681 S.COL ELJRE 15NGFA
L872 6200005671 S.COL ELJRE 12NGFA
L881 6200002651 S.COL NLV25T-R18J
L882 6200005661 S.COL ELJRE 10NGFA
L901 6200005011 S.COL NLV25T-100J
L941 6200008080 S.COL LQW2BHNR22J03L
L981 6200003171 S.COL NLV32T-330J
L991 6200007390 S.COL ELJFC 120K-F
L992 6200006380 S.COL ELJFC 150K
L1000 6200006981 S.COL ELJRE R10GFA
L1001 2040000490 COL EXC-ELDR25C
L1016 6200005011 S.COL NLV25T-100J
R11 7030003280 S.RES ERJ3GEYJ 470 V (47)
R12 7030003320 S.RES ERJ3GEYJ 101 V (100)
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R14 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R15 7030003340 S.RES ERJ3GEYJ 151 V (150)
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R21 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R23 7030003320 S.RES ERJ3GEYJ 101 V (100)
R24 7030003370 S.RES ERJ3GEYJ 271 V (270)
R32 7030003420 S.RES ERJ3GEYJ 681 V (680)
R41 7030003220 S.RES ERJ3GEYJ 150 V (15)
R52 7030003280 S.RES ERJ3GEYJ 470 V (47)
R53 7030003370 S.RES ERJ3GEYJ 271 V (270)
R54 7030003660 S.RES ERJ3GEYJ 683 V (68 k)
R71 7030003280 S.RES ERJ3GEYJ 470 V (47)
R72 7030003360 S.RES ERJ3GEYJ 221 V (220)
except [EUR], [FRA], [USA]
R73 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
except [USA], [USA-1], [EUR], [EUR-1]
R75 7030003400 S.RES ERJ3GEYJ 471 V (470)
R76 7030003360 S.RES ERJ3GEYJ 221 V (220)
R101 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R102 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R103 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R104 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R105 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R106 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R131 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
except [USA], [USA-1], [EUR], [EUR-1]
R133 7030009690 S.RES RR0816P-101-D (100)
R134 7030005730 S.RES RR0816R-823-D (82 k)
R135 7030005390 S.RES RR0816P-102-D (1 k)
R136 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
R137 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
R138 7030003320 S.RES ERJ3GEYJ 101 V (100)
except [EUR], [FRA], [ESP], [USA], [EUR-1], [ESP-1], [USA-1]
R141 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R142 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R143 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
