Screw abbreviations
A, B0, BT: Self-tapping PH: Pan head ZK: Black
NI-ZU: Nickel-Zinc SUS: Stainless
6 - 1
SECTION 6 MECHANICAL PARTS AND DISASSEMBLY
[CHASSIS PARTS]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J3 6510000370 MR-DS 1
J4 6510000370 MR-DS 1
P3 6510009330 51006-0200 1
P4 6510003240 TMP-P01X-A1 1
SP1 2510000991 VS-C66Y0811A 1
MF1 2710000580 FBA06T12HF 1
W1 8900008850 OPC-874 1
W2 8900015940 OPC-875A 1
W3 8900015020 OPC-877A 1
W4 9016910510 51/99/160/A14A/W99A 1
W5 9011130780 Wire 00 1
W12 9016910450 62/99/075/C31/W17D 1
W13 9086700300 Wire 08 1
W14 8900008700 OPC-852 1
W15 8900008870 OPC-876 1
EP4 6910000630 FSOH070RN 1
EP5 9068000100 Wire D=5.0 L=10MM 1
EP7 9010001410 Wire D=8.0 1
EP8 6910009680 H-110-02 L=50MM 1
EP9
†
– UT-106 [EUR-1], [FRA-1], [ESP-1], [USA-1],
[OTH-1], [ITA-1], [ITR-1] only 1
EP10 9019501210 Wire D=7.0 1
MP1 8010017543 2177 CHASSIS-3 1
MP2 8110006061 1897 U-COVER-1 1
MP3 8110006591 2177 L-COVER-1 1
MP4 8010001490 stand (D) 1
MP5 8930005790 Color reg (A) 1
MP6 8930005800 Color reg (B) 1
MP7 8930049123 2177 FAN HOLDER-3 1
MP8 8820000530 Flange bolt M4X8 NI 1
MP9 8930002820 rubber leg (D) SK136A 2
MP10 8930015850 Speaker net (SX-611) 1
MP11 8930018520 TR clip (A) 1
MP12 8950004181 1691 CONTACT BASE (A)-1 1
MP14 8930052330 sponge (GN) 1
MP17 8310045920 2177 ANT PLATE 1
MP19 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 5
MP20 8810007410 Screw PH M3X6 NI 2
MP21 8810009611 Screw M2.6X6 ZK3 5
MP22 8850000140 Flat washer M4 BS NI 1
MP24 8810008991 Screw BT B0 2X10NI-ZK3 (BT) 1
MP25 8850001561 TOOTHED WASHER (A) M4 ZC3 1
MP26 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 4
MP27 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 5
MP28 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 6
MP29 8810004431 Screw PH M3X6 ZK3 2
MP30 8810004431 Screw PH M3X6 ZK3 2
MP31 8810004431 Screw PH M3X6 ZK3 2
MP32 8810007410 Screw PH M3X6 NI 2
MP33 8810008490 Setscrew (H) 2.6X8 NI 2
MP34 8810008490 Setscrew (H) 2.6X8 NI 2
MP35 8810008490 Setscrew (H) 2.6X8 NI 2
MP36 8810009611 Screw M2.6X6 ZK3 5
MP37 8810008490 Setscrew (H) 2.6X8 NI 2
MP38 8930038650 Thermal sheet (BE) 1
MP40 8930038820 alminium sheet (V) 1
MP49 8930028390 Thermal sheet (AH) 5
MP60 8930042441 1897 SP HOLDER-1 1
MP61 8810009611 Screw M2.6X6 ZK3 4
MP62 8810009391 Screw BT B0 3X18NI-ZC3 (BT) 4
MP63 8810007410 Screw PH M3X6 NI 2
MP65 8810008661 Screw BT B0 3X8 NI-ZC3 (BT) 2
MP74 8510011940 2177 PLATE 1
MP75 8810009511 Screw BT B0 2X4 NI-ZC3 (BT) 2
MP76 8510006440 ANT cover 1
MP77 8930048550 2177 CLIP 1
MP79 8930048960 SHIELD TAPE (B) 1
MP80 8930048970 SHIELD TAPE (C) 1
MP81 8930048960 SHIELD TAPE (B) 1
MP82 8930045920 2056 SPONGE 1
MP83 8930015640 Cable holder (SX-713) 1
MP84 8930048120 SHIELD TAPE (A) 1
MP87 8930049110 sponge (GC) 1
MP89 8930049710 2177 FAN SPRING 1
MP92 8850000571 TOOTHED WASHER (B) M3 ZC3 1
MP93 8850000571 TOOTHED WASHER (B) M3 ZC3 1
MP94 8930045920 2056 SPONGE 1
MP95 8930045920 2056 SPONGE 1
MP96 8930049110 sponge (GC) 1
MP97 8930049110 sponge (GC) 1
MP98 8930056020 sponge (GU) 1
MP100 8930049130 SHIELD TAPE (D) 1
MP101 8930048960 SHIELD TAPE (B) 1
MP102 8930049130 SHIELD TAPE (D) 1
MP103 8930049130 SHIELD TAPE (D) 1
MP104 8930048970 SHIELD TAPE (C) 1
MP105 8930049130 SHIELD TAPE (D) 1
MP106 8930045920 2056 SPONGE 1
MP107 8930056010 emboss tape (K) 1
MP108 8930056160 Doublesided tape (AG) 1
MP109 8930041830 sponge (ER) 1
MP110 8930041830 sponge (ER)
1
[FRONT UNIT]
[DISPLAY UNIT]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W1 8900006040 OPC-593 1
W2 8900006252 OPC-610B 1
EP1 6910013810 RMS20-100-201-1C 1
MP1 8210015781 2177 FRONT PANEL-1 1
MP2 8210015890 1691 REAR PANEL (A) 1
MP3 8930047970 2177 MENU KEY 1
MP4 8930047960 2177 MODE KEY 1
MP5 8930048370 1691 UP/DOWN KEY (B) 1
MP6 8930036731 1691 4-KEY-1 1
MP7 8930036751 Push spring (Y)-1 1
MP8 8930060190 2591 N-SPRING 1
MP9 8830001010 HEX NUT (A) 2
MP10 8610010660 Knob N-237 (A) 1
MP11 8610010670 Knob N-238 (A) 2
MP12 8610010024 Knob N-239 BASE-4 1
MP13 8610010030 Knob N-239 COVER 1
MP14 8610010040 Knob N-239 FINGER REST 1
MP15 8930036691 1691 RELEASE BUTTON-1 1
MP16 8930048090 2177 LENS 3
MP17 8310036280 1691 WINDOW PLATE 1
MP18 8310036273 1691 BRAKE PLATE-3 1
MP19 8950004192 1691 CONTACT BASE (B)-2 1
MP20 8930036740 1691 BRAKE PAD 2
MP21 8930037111 1691 BRAKE SHEET-1 1
MP22 8310036583 1691 Warning sticker (S)-3 1
MP23 8810008991 Screw BT B0 2X10NI-ZK3 (BT) 2
MP24 8930038940 sponge (EF) 1
MP26 8610010360 Knob N-260 1
MP27 8610007510 knob spring NO.7800 1
MP28 8610007510 knob spring NO.7800 1
REF ORDER
DESCRIPTION
QTY.
NO. NO.
J1* 6510019121 S8B-PH-SM4-TB (LF) (SN) 1
J2 6450001630 HSJ1406-01-050 1
J3* 6510018891 52559-1370 1
DS4 5030001670 DLC-8309YBGF 1
DS5 5030001290 D2264 1
W1 7030003860 ERJ3GE-JPW 1
W2 7120000470 ERDS2T0 1
W3 7120000470 ERDS2T0 1
EP2 8930039790 SRCN-1691-ZSS-505 2
MP1 8930036710 1691 LCD HOLDER 1
MP3 8810009040 Setscrew (H) 2.6X10 NI 1
MP4 8830000180 Nut M2.6 BS NI 1
MP5 8930043471 1897 FRONT PLATE-1 1
MP6 8510014100 2177 FRONT SHIELD 1
[VR BOARD]
REF ORDER
DESCRIPTION
QTY.
NO. NO.
R1 7210002780 RV-300 1
R2 7210002940 TP96D231E20-20F-10KB-1897 1
J1 6510018891 52559-1370 1
S1 2220000540 SW-162 1
*: Refer to SECTION 8 “BOARD LAYOUTS.”
†
: Optional product
To Next Page
