Icom IC-706MKIIG - Page 47

6 - 3
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
EP609 6910000640 FSOH090RN 1
EP610 6910000640 FSOH090RN 1
EP611 6910000640 FSOH090RN 1
EP612 9010000630 Tube D=10.0 1
MP101 8930014140 earth spring (D) 1
MP231 8860001130 2177 RUG 1
MP232 8930049100 2177 PA SPRING 1
MP233 8930014140 earth spring (D) 1
MP234 8860001130 2177 RUG 1
MP235 8930053490 Insulation sheet (GH) 1
MP241 8930050261 2177 THERMALLY SHEET-1 1
MP451 8510012150 2177 PA S-PLATE 1
MP501 8930024170 earth spring (G) 1
MP502 8930024170 earth spring (G) 1
MP601 8950000180 Cable tie -80 1
MP602 8950000180 Cable tie -80 1
MP603 8510014090 2177 DRIVER SHIELD 1
MP604 8510014110 2177 PA SHIELD 1
MP605 8950000180 Cable tie -80 1
MP606 8950000180 Cable tie -80 1
MP607 8930014140 earth spring (D) 1
MP608 8930027810 emboss tape (B) 1
MP610 8930049110 sponge (GC) 1
MP611 8930030380 FERRITE SHEET (C) 1
MP612 8930024170 earth spring (G) 1
MP613 8950000180 Cable tie -80 1
[FILTER BOARD]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1 6510007900 TBP-P01X-A1 1
J2 6510007900 TBP-P01X-A1 1
J4 6450001491 HLJ7001-016010 1
J5 6510024661 TCS5072-1041577 1
J7 6450001650 HSJ0836-01-500 1
J8 6450001660 EX345GLB 1
J9* 6510020081 52808-2071 1
J11 6510016171 52018-8836 1
J12* 6510020081 52808-2071 1
J13 6510017150 TMP-S01X-C1 1
J14 6450001841 TCS7568-4320177 1
P1 6510003240 TMP-P01X-A1 1
P2 6510003240 TMP-P01X-A1 1
W11 9012962951 62/99/180/C24/C31 1
W12 9086700300 Wire 08 1
W21 9086700060 62/99/110/C31/C24 1
W22 9086700300 Wire 08 1
MP1 8930017200 752 earth spring 1
MP3 8930001170 earth spring (A) (FX-294) 1
MP4 8930055970 2177 GND SPRING 1
MP5 8930055970 2177 GND SPRING 1
MP6 8930055970 2177 GND SPRING 1
[ACCESSORIES]
REF ORDER
DESCRIPTION QTY.
NO. NO.
P1 5610000410 AP-319 1
P2 5610000420 AP-338 1
MC1
†
– HM-103-1 1
F1 5210000090 FGB 30A 2
F2 5210000131 FGB 4A PBF 1
W1 8900006490 OPC-025D 1
W2 8900006110 OPC-596 1
EP1 0880000230 OPC-639 (EX-1874 PACKING) 1
EP2 6910011960 ZCAT1518-0730 1
MP1 8930007300 MIC hunger 1
*: Refer to SECTION 8 “BOARD LAYOUTS.”
†
: Optional product
Screw abbreviations
A, B0, BT: Self-tapping PH: Pan head ZK: Black
NI-ZU: Nickel-Zinc SUS: Stainless
