Icom IC-7100 Service Manual

4-6
4-5 TRANSMIT ADJUSTMENTS (HF/50 MHz/70 MHz BANDS) (continued)
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION
ADJUST
POINT
VALUE
AM CARRIER POWER
RATIO
1 • Display:
"POWER AM Ratio HF"
• Receive
• Push [SET]. (Automatically starts to
transmit.)
[MAIN DIAL] 30 W
Push [SET]*.
TX POWER & POWER
METER SETTING (50 M)
1 • Display: "POWER 50M" – – Push [SET].
(Automatically starts
to transmit.)
2 • Display: "POWER 50M Min"
• Transmit continues
[MAIN DIAL] 2 W
Push [SET].
3 • Display: "POWER 50M 10%"
• Transmit continues
10 W
Push [SET].
4 • Display:
"POWER 50M Tuner"
• Transmit continues
10 W
Push [SET].
5 • Display: "POWER 50M 50%"
• Transmit continues
50 W
Push [SET].
6 • Display:
"POWER 50M 100%"
• Transmit continues
100 W
Push [SET]*.
AM CARRIER POWER
RATIO (At 50 MHz)
1 • Display:
"POWER AM Ratio 50M"
• Receive
• Push [SET]. (Automatically starts to
transmit.)
30 W
Push [SET]*.
TX POWER & POWER
METER SETTING
(At 70 MHz)
1 • Display: "POWER 70M"
• Receive
– – Push [SET].
(Automatically starts
to transmit.)
2 • Display: "POWER 70M Min"
• Transmit continues
[MAIN DIAL] 2 W
Push [SET].
3 • Display: "POWER 70M 10%"
• Transmit continues
5 W
Push [SET].
4 • Display:
"POWER 70M Tuner"
• Transmit continues
10 W
Push [SET].
5 • Display: "POWER 70M 50%"
• Transmit continues
25 W
Push [SET].
6 • Display:
"POWER 70M 100%"
• Transmit continues
50 W
Push [SET]*.
AM CARRIER POWER
RATIO (At 70 MHz)
1 • Display: "POWER AM Ratio 70M" • Push [SET]. (Automatically starts to
transmit.)
15 W
Push [SET]*.
ID APC (Verify) 1 • Display: "ID-APC CHECK" – – Push [SET].
(Automatically starts
to transmit.
A beep sounds, and
then another beeps
sound 3 sec. later.*)
ALC METER 1 • Display: "ALC HF"
2 • Display: "ALC 70M"
DRIVE GAIN 1 • Display: "DRIVE HF/50M"
2 • Display: "DRIVE HF/70M"
SWR METER 1 • Display: "SWR HF/50M" • Connect the 100
Ω
dummy load to
[ANT1].
2 • Display: "SWR 70M"
The Transmit adjustment menu is displayed.
1) Set or modify the adjustment value as specifi ed by rotating [MAIN DIAL].
2) Push [SET] to store the value.
*; Stop transmitting.

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
