Icom IC-7100 Service Manual

1-1
SECTION 1
.
SPECIFICATIONS
'ENERAL D
s&REQUENCYCOVERAGE     UNIT-(Z
Receive
0.030000 – 199.999999*
1
*
2
400.000000 – 470.000000*
1
*
2
Transmit
1.800000 – 1.999999*
2
, 3.500000 – 3.999999*
2
,
5.255000 – 5.405000*
1
*
3
,
5.332000*
3
*
4
, 5.348000*
3
*
4
, 5.358500*
3
*
4
,
5.373000*
3
*
4
, 5.405000*
3
*
4
,
7.000000 – 7.300000*
2
, 10.100000 – 10.150000*
2
,
14.000000 – 14.350000*
2
, 18.068000 – 18.168000*
2
,
21.000000 – 21.450000*
2
, 24.890000 – 24.990000*
2
,
28.000000 – 29.700000*
2
, 50.000000 – 54.000000*
2
,
70.000000 – 70.500000*
2
, 144.000000 – 148.000000*
2
,
430.000000 – 450.000000*
2
*
1
Some frequency ranges are not guaranteed.
*
2
Depending on version. *
3
USA version only.
*
4
Center frequency.
s-ODE  53",3"#72449!-&-
WFM (RX only), DV
s.OOFMEMORYCHANNELS #(
(99CH × 5 bank)
s.OOFSCANEDGEMEMORYCHANNELS
6 CH
(2 × 3 edges)
s.OOFCALLCHANNELS  #((2 × 2 band)
s!NTENNACONNECTOR  3/× 2
sAntenna impedance: 50 ø
s5SABLETEMPERATURERANGE
–10˚C to +60˚C;
+14˚F to +140˚F
s&REQUENCYSTABILITY  ,ESSTHANÒPPMMINUTES
after power ON.
(0˚C to +50˚C;
+32˚F to +122˚F at 430 MHz band)
s&REQUENCYRESOLUTION  (Z
s0OWERSUPPLY  6$#Ò
(negative ground)
s0OWERCONSUMPTION
Transmit
Max. power: 22.0 A
Receive
Standby: 0.9 A
Max. audio: 1.2 A
s$IMENSIONSPROJECTIONSNOTINCLUDED
Main unit: 167(W) × 58(H) × 225(D) mm;
6.6(W) × 2.3(H) × 8.9(D) in
Controller: 165(W) × 64(H) × 78.5(D) mm;
6.5(W) × 2.5(H) × 3.1(D) in
s7EIGHTAPPROXIMATELY
Main unit: 2.3 kg; 5.1 lb
Controller: 0.5 kg; 1.1 lb
s!##CONNECTOR  PIN
s$!4!CONNECTOR  CONDUCTORDMM
1
⁄10″)
s$!4!CONNECTOR  PIN
s2%-/4%CONNECTOR  CONDUCTORDMM
1
⁄8″)
Transmitter D
s/UTPUTPOWER(at 13.8 V DC/+25˚C): (continuously adjustable)
&REQUENCYBAND /UTPUTPOWER
HF/50 MHz 2 to 100 W (AM: 1 to 30 W)*
70 MHz 2 to 50 W (AM: 1 to 15 W)*
144 MHz 2 to 50 W
430 MHz 2 to 35 W
* In the AM mode, transmission can be performed only on
the HF/50/70 MHz frequency band.
s-ODULATIONSYSTEM
SSB: Digital PSN modulation
AM: Digital Low power modulation
FM: Digital Phase modulation
DV: GMSK Digital Phase modulation
s3PURIOUSEMISSION
(Spurious domain)
HF bands: Less than –50 dB
50 MHz band: Less than –63 dB
70/144/430 MHz bands:
Less than –60 dB
(Out-of-band domain)
HF bands: Less than –40 dB
50/70/144/430 MHz bands:
Less than –60 dB
s#ARRIERSUPPRESSION  -ORETHAND"
s5NWANTEDSIDEBANDSUPPRESSION
More than 50 dB
s-ICROPHONECONNECTOR  PINMODULARJACK
s-ICROPHONEIMPEDANCE  ø
s%,%#+%9CONNECTOR  CONDUCTORDMM
1
⁄8″)
s+%9CONNECTOR  CONDUCTORDMM
1
⁄8″)

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
