Icom IC-718 - Page 28

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
L3502 6180000960 COIL LAL 03NA 102K
L4501 6200003950 S.COIL HF50ACC 322513-T
L4651 6200003950 S.COIL HF50ACC 322513-T
L4652 6200001830 S.COIL NL 322522T-100J
L4653 6200003950 S.COIL HF50ACC 322513-T
L4654 6200003950 S.COIL HF50ACC 322513-T
L4656 6200001830 S.COIL NL 322522T-100J
L4657 6200001830 S.COIL NL 322522T-100J
L4658 6200003260 S.COIL NL 322522T-101J
L4659 6200001830 S.COIL NL 322522T-100J
L4660 6200001830 S.COIL NL 322522T-100J
L4661 6200003260 S.COIL NL 322522T-101J
L4801 6200003260 S.COIL NL 322522T-101J
L4802 6200003950 S.COIL HF50ACC 322513-T
L5101 6200003330 S.COIL NL 322522T-1R0J-3
L5102 6200003330 S.COIL NL 322522T-1R0J-3
R1 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R2 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R3 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R4 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R5 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R6 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R7 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R101 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R102 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R103 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R104 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R106 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R107 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R108 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R151 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R152 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R153 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R154 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R155 7510001330 S.THERMISTOR NTCCM1005 4BH 332KC-T
R156 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R202 7030007180 S.RESISTOR ERJ12YJ150U (15 Ω)
R203 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R204 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R205 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R206 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R301 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R302 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R303 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R304 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R401 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R402 7030003230 S.RESISTOR ERJ3GEYJ 180 V (18 Ω)
R403 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R501 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R502 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R503 7310002600 S.TRIMMER RV-110 (RH03A3AS4X0AA) 473
R504 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R505 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R506 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R507 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R508 7510000751 S.THERMISTOR NTCCM2012 3NH 103KC-T
R509 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R510 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R511 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R512 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R513 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R514 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R601 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R602 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R603 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R604 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R605 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R606 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R611 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R612 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R613 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R614 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R621 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R622 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R623 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R624 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R631 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R632 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R633 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R634 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R635 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R701 7030009830 S.RESISTOR ERJ12YJ391U (390 Ω)
R703 7030006250 S.RESISTOR ERJ12YJ271U (270 Ω)
R704 7030009830 S.RESISTOR ERJ12YJ391U (390 Ω)
R705 7030006260 S.RESISTOR ERJ12YJ471U (470 Ω)
R801 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R802 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R821 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R822 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R823 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R824 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R831 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R832 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R841 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R842 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R851 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R852 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R861 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R862 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R871 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R872 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R881 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R882 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R891 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R892 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R901 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R902 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R903 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R904 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1001 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1002 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1101 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1102 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1103 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R1105 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R1107 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470)
R1108 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1202 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R1204 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R1205 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R1206 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R1207 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R1208 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1209 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1300 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1301 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1302 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R1304 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R1305 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R1306 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R1307 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R1308 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R1310 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R1311 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R1401 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R1402 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R1403 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R1404 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1501 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1502 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1503 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1504 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R1505 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1506 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1507 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1508 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R1509 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R1510 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1511 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1513 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1514 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1515 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R1516 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R1517 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R1518 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1519 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1520 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R1521 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1522 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
