Icom IC-718 - Page 29

[MAIN UNIT][MAIN UNIT]
S.=Surface mount
R1523 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1601 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R1602 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1603 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R1604 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1610 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R1611 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1612 7510000721 S.THERMISTOR NTCCM2012 3FH 332KC-T
R1614 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472
R1615 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1616 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1617 7510001330 S.THERMISTOR NTCCM1005 4BH 332KC-T
R1621 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1622 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R1623 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R1624 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1625 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R1626 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R1627 7510001330 S.THERMISTOR NTCCM1005 4BH 332KC-T
R1631 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1632 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1633 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1703 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1706 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R1707 7310002580 S.TRIMMER RV-108 (RH03A3A15X05A) 104
R1708 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R1709 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1710 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R1711 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R1712 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1713 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R1714 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R1715 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R1716 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1717 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1718 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1719 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R1720 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R1721 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R1722 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R1723 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R1724 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1725 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1729 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1730 7310002580 S.TRIMMER RV-108 (RH03A3A15X05A) 104
R1751 7030003790 S.RESISTOR ERJ3GEYJ 824 V (820 kΩ)
R1752 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R1754 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R1755 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1801 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1802 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
R1803 7030003830 S.RESISTOR ERJ3GEYJ 185 V (1.8 MΩ)
R1804 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R1805 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1806 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R1807 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1808 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1809 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R1810 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R1812 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R1813 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R1814 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1815 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R1901 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R1902 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R1903 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R1904 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R1905 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R1906 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R1907 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2001 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R2002 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R2003 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R2004 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R2005 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R2006 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R2007 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R2008 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R2101 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R2102 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2103 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2104 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2105 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2106 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2107 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2108 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R2201 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2202 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2203 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2204 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2206 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R2208 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2209 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2210 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2211 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R2212 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R2213 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R2214 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2215 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2216 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2217 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2218 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2219 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R2220 7310002800 S.TRIMMER RV-156 (RH03A3AJ5) 224
R2221 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R2222 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R2223 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R2224 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2225 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R2300 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R2301 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2302 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2303 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472
R2304 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2305 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2306 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R2307 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2308 7510001330 S.THERMISTOR NTCCM1005 4BH 332KC-T
R2310 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2312 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2313 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2317 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2318 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R2319 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R2320 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R2321 7310002800 S.TRIMMER RV-156 (RH03A3AJ5) 224
R2352 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R2353 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2381 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2382 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R2383 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R2384 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2385 7310002740 S.TRIMMER RV-150 (RH03A3A14X0FC) 103
R2386 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2387 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2401 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2402 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2403 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2406 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2407 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2501 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2601 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2602 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2603 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2604 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2605 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2606 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R2607 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2701 7310002720 S.TRIMMER RV-148 (RH03A3AS3X0DA) 472
R2702 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R2703 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2704 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R2705 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2706 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R2707 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R2708 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R2709 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R2710 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R2720 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2721 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R2722 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2803 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2804 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R2805 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
6 - 6
