4-3
4-3 TX IDLING CURRENT ADJUSTMENTS
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION VALUE
PREPARATION 1 1) Connect the power meter (or dummy load)
to the antenna connector.
2) Touch [ID] to enter to the TX idling current
adjustment mode.
ADJUSTMENT 2 • Display: “VDL IDL Set”
• Receive
Touch [SET].
(A beep sounds, and
then another beep
sounds 0.5 sec. later.)
3 • Display: “FINAL ID SET”
• Receive
4 • Display: “FINAL1 IDV”
• Transmit (automatic)
5 • Display: “FINAL2 IDV”
• Transmit (automatic)
6 • Display: “DRIVER ID SET”
• Transmit (automatic)
7 • Display: “DRIVER IDV”
• Transmit (automatic)
• Push [EXIT] to return to the TX adjustment menu.
Touch [TX/ID] on the main adjustment menu screen.
NOTE: The transceiver automatically transmits when a TX adjustment item is selected.
