• Touch [TX/ID] on the main adjustment menu screen.

4-4

ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION

ADJUST

POINT

VALUE

TX POWER &

POWER METER SETTING

(Preparation)

1 • Display: “TX POWER SET”

• Receive

Connect the AG with the millivoltmeter

to [MIC], and then set it as;

Frequency : 1.5 kHz

Level : 30 mVrms

2) Connect the power meter to the

antenna connector.

3) Touch [Power] to enter to the TX

power adjustment mode.

– –

(HF BAND) 2 • Display: "TX Total HF Gain"

• Transmit (automatic)

•

Adjust the

TX power by rotating

[MAIN DIAL], and then touch [SET].

[MAIN DIAL] 50 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

3 • Display: "POWER HF 1%"

• Transmit (automatic)

2 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

4 • Display: "POWER HF 10%"

• Transmit (automatic)

12.5 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

5 • Display: "POWER HF TUNE"

• Transmit (automatic)

6 • Display:

"POWER HF 50%"

• Transmit (automatic)

52.5 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

7 • Display:

"POWER HF 100%"

• Transmit (automatic)

105 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

AM CARRIER POWER

(HF BAND)

8 • Display:

"POWER AM Ratio HF"

• Transmit (automatic)

1) Touch [SET].

(Automatically starts to transmit.)

2) Adjust the TX power by rotating

[MAIN DIAL], and then touch [SET].

25 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

9 • Display: "POWER 50M SET"

• Transmit (automatic)

–

Touch [SET].

TX POWER &

POWER METER SETTING

(50 MHz band)

10 • Display: "TX Total 50M Gain"

• Transmit (automatic)

• Adjust the TX power by rotating

[MAIN DIAL], and then touch [SET].

[MAIN DIAL]

50 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

11 • Display: "POWER 50M 1%"

• Transmit (automatic)

– 2 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

12 • Display: "POWER 50M 10%"

• Transmit (automatic)

12.5 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

13 • Display: "POWER 50M TUNE"

• Transmit (automatic)

14 • Display: "POWER 50M 50%"

• Transmit (automatic)

52.5 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

15 • Display: "POWER 50M 100%"

• Transmit (automatic)

105 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

AM CARRIER POWER RATIO

(50 MHz band)

16 • Display: "POWER AM Ratio 50M"

• Transmit (automatic)

1) Touch [SET].

(Automatically starts to transmit.)

2) Adjust the TX power by rotating

[MAIN DIAL], and then touch [SET].

25 W

(A beep sounds, and

then another beeps

sound 0.5 sec. later.)

17 • Display: "POWER 70M SET"

• Receive

– – Touch [SET].

4-4 TX POWER ADJUSTMENTS

(Continued on the next page.)

NOTE: The transceiver automatically transmits when a TX adjustment item is selected.
