Icom IC-7300 Adjustment Procedure

4-6
4-6 FREQUENCY ADJUSTMENTS
ADJUSTMENT ITEM TRANSCEIVER'S CONDITION OPERATION VALUE
PREPARATION 1
–
1)
Connect the power meter to the antenna
connector.
2) Touch [TUNER/REF].
(Enters to the [TUNER/REF ADJ.] menu.)
3) Touch [TUNER].
Touch [TUNER/REF].
(Enters to the [TUNER/
REF ADJ.] menu.)
TUNER REFERENCE
VOLTAGE ADJUSTMENT
(HF and 50 MHz bands)
2 • Display: "Tune IREFV HF 50M"
• Transmit (automatic)
– Touch [SET].
(A beep sounds, and
then another beeps
sound 11 sec. later.)
(70 MHz band)
Only for [#03, 05 and 06]
3 • Display: “Tune IREFV HF 70M”
• Transmit (automatic)
Touch [SET].
(A beep sounds, and
then another beeps
sound 1 sec. later.)
REFERENCE
FREQUENCY
4 – 1) Connect the frequency counter to the
antenna connector, through the 50 dB
attenuator.
2) Touch [MENU] REF adjustment menu.
–
5 • Display: "REF OSC"
• Transmit (automatic)
1)
Set
the transmit frequency by rotating
[MAIN DIAL].
2) Touch [SET].
50.100000 MHz
(±1.2 Hz)
(A beep sounds, and
then another beeps
sound 0.5 sec. later.)
• Push [EXIT] to return to the main adjustment menu.
• Touch [TUNER/REF] on the main adjustment menu screen.
NOTE: The transceiver automatically transmits when a TX adjustment item is selected.
