4-7-2 AUTOMATIC ADJUSTMENTS (TRANSMITTER)
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
PREPARATION 1 1) Connect an Audio Generator to the MIC jack and set it as;
Frequency : 1.5 kHz
Level : 10 mV
2) Connect an RF power meter to the [ANT1].
3) Connect an terminator (SWR=2) to the [ANT2].
––
POWER METER
(HF BAND)
<Preset>
1
–
• Push [F-7] key.
[POWER HF/
50M 0W]
–
<10 W> 2 • Transmitting (Automatically) 1) Adjust the transmit power using
[MAIN DIAL].
2) Push [F-7] key.
[POWER HF
10W]
10 W
<50 W> 3 • Transmitting (Automatically) [POWER HF
50W]
50 W
<100 W> 4 • Transmitting (Automatically) [POWER HF
100W]
100 W
<150 W> 5 • Transmitting (Automatically) [POWER HF
150W]
150 W
<200 W> 6 • Transmitting (Automatically) [POWER HF
200W]
195 W
POWER METER
(50 MHz BAND)
7 • Transmitting (Automatically) 1) Adjust the transmit power using
[MAIN DIAL].
2) Push [F-7] key.
[POWER 50M
10W]
10 W
<50 W> 8 • Transmitting (Automatically) [POWER 50M
50W]
50 W
<100 W> 9 • Transmitting (Automatically) [POWER 50M
100W]
100 W
<150 W> 10 • Transmitting (Automatically) [POWER 50M
150W]
150 W
<195 W> 11 • Transmitting (Automatically) [POWER 50M
200W]
195 W
[RESERVE
POWER SET]
(NO AJUSTMENT)
1
–
• "RESERVE POWER SET" appears.
Push [F-7] key.
––
POWER DOWN 1 • Transmitting (Automatically) 1) Adjust the transmit power using
[MAIN DIAL].
2) Push [F-7] key.
[POWER for
Power Down
HF/50M]
100 W
ALC METER 1 • Transmitting (Automatically) •

Push [F-7] key.
[ALC]
(Automatic
adjustment)
DRIVE LEVEL 1 • Transmitting (Automatically) •

Push [F-7] key.
[DRIVE]
(Automatic
adjustment)
DRAIN VOLTAGE
METER
1 • Transmitting (Automatically) •

Push [F-7] key.
[Vd48V]
(Automatic
adjustment)
DRAIN
CURRENT
METER
0A
1 • Transmitting (Automatically) •

Push [F-7] key.
[Id 0A] –
5A 2 • Transmitting (Automatically) • Monitoring drain current on the
display, adjust the current using
[MAIN DIAL], then push [F-7] key.
[Id 5A] 5 A
10A 3 • Transmitting (Automatically) • Monitoring drain current on the
display, adjust the current using
[MAIN DIAL], then push [F-7] key.
[Id 10A] 10 A
SWR METER 1 • Transmitting (Automatically) •

Push [F-7] key.
(Returns to adjustment main menu)
[SWR]
(Automatic
adjustment)
4 - 14
