Icom IC-7700

6 - 9
[ANT-SW BOARD] (ANT)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510017930 1771P145-20 1
J3* 6510007020 TMP-J01X-V6 1
J4* 6510019971 52808-1071 1
J51* 6510000410 MR-DSE-02 1
J61* 6510000410 MR-DSE-02 1
J71* 6510000410 MR-DSE-02 1
J81* 6510000410 MR-DSE-02 1
[CTRL BOARD] (CTR)
REF ORDER
DESCRIPTION QTY.
NO. NO.
CP1* 6910009670 HK3-S-T 1
CP101* 6910009670 HK3-S-T 1
J1* 6510023771 52793-2470 1
J2* 6510023761 S10B-PH-SM4-TB (LF) (SN) 1
J51* 6510023771 52793-2470 1
J52* 6510022031 B10B-ZR-SM4-TF (LF) (SN) 1
J53* 6510021431 S8B-ZR-SM4A-TF (LF) (SN) 1
J101* 6510017920 1811P342 1
J251* 6510017920 1811P342 1
J252* 6510017920 1811P342 1
J301* 6510017920 1811P342 1
J351* 6510007020 TMP-J01X-V6 1
W1 9029804001 72/99/040/X98/X98 1
EP1 9040902903 IRRAX D=0.7 L=22MM 1
MP1 8510015760 2590 A-CTRL CASE 1
MP2 8930014140 EARTH SPRING (D) 1
MP3 8930048681 INSULATION PIPE (K)-1 1
MP4 8930048681 INSULATION PIPE (K)-1 1
MP5 8930048681 INSULATION PIPE (K)-1 1
MP6 8930048681 INSULATION PIPE (K)-1 1
MP7 8930014140 EARTH SPRING (D) 1
[DC-DC UNIT] (DCD)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022801 B10B-PH-SM4-TB (LF) (SN) 1
J2* 6510020251 B9B-PH-SM4-TB (LF) (SN) 1
J3* 6510018941 B13B-PH-SM4-TB (LF) (SN) 1
J5* 6510018951 B7B-PH-SM4-TB (LF) (SN) 1
J6* 6510023261 B6B-PH-SM4-TB (LF) (SN) 1
J7* 6510018921 B8B-PH-SM4-TB (LF) (SN) 1
J8* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
W1
†
9030090150 OPC-1803 1
MP201 8510015720 2590 DC-DC A-CASE 1
MP203 8930074750 FERRITE SHEET (V) 1
MP401 8510015720 2590 DC-DC A-CASE 1
MP403 8930074750 FERRITE SHEET (V) 1
MP601 8510015720 2590 DC-DC A-CASE 1
MP603 8930074750 FERRITE SHEET (V) 1
MP801 8510015740 2590 DC-DC B-CASE 1
[DIGISEL UNIT] (DSL)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510007020 TMP-J01X-V6 1
J2* 6510007020 TMP-J01X-V6 1
J11* 6510009870 PD054-02M 1
J12* 6510009870 PD054-02M 1
J2017* 6510019971 52808-1071 1
J2018* 6510003391 B03B-EH-S (LF) (SN) 1
W11
†
9030090110 61/99/070/D33D/D33D 1
W12
†
9011130220 WIRE 08 DD 1
MP1 8930062740 2590 M-SPRING 1
MP2 8930062740 2590 M-SPRING 1
MP3 8930062740 2590 M-SPRING 1
MP4 8930062740 2590 M-SPRING 1
MP5 8930062740 2590 M-SPRING 1
MP8 8510018460 3009 DIGISEL CASE 1
MP9 8510018470 3009 DIGISEL COVER 1
MP14 8810007231 SETSCREW (H) 3X8 ZC3 7
MP15 8810007231 SETSCREW (H) 3X8 ZC3 6
[FILTER UNIT] (FIL)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J901* 6510017930 1771P145-20 1
J902* 6510022031 B10B-ZR-SM4-TF (LF) (SN) 1
J903* 6510019971 52808-1071 1
J904* 6510017930 1771P145-20 1
J905* 6510019421 B8B-ZR-SM4-TF (LF) (SN) 1
[LOGIC UNIT] (LG)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022490 AXK5S30045P 1
J2* 6510019870 AXK5S40045P 1
J52* 6510023261 B6B-PH-SM4-TB (LF) (SN) 1
J102* 6510019981 52808-1671 1
J602* 6510019971 52808-1071 1
J604* 6510019971 52808-1071 1
J804* 6510022031 B10B-ZR-SM4-TF (LF) (SN) 1
J805* 6510020081 52808-2071 1
J806* 6510022471 40FLT-SM2-TB (LF) (SN) 1
J808* 6510020001 52808-3071 1
J809* 6510020001 52808-3071 1
J810* 6510020251 B9B-PH-SM4-TB (LF) (SN) 1
J811* 6510021561 52808-2470 1
J813* 6510019991 52808-2271 1
J814* 6510019981 52808-1671 1
J816* 6510019981 52808-1671 1
J820* 6510022801 B10B-PH-SM4-TB (LF) (SN) 1
J821* 6510020251 B9B-PH-SM4-TB (LF) (SN) 1
J824* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J826* 6510015541 B4B-ZR-SM4-TF (LF) (SN) 1
J2001* 6510023720 LGY6501-0600C 1
J2052* 6510023120 CD6109SA1J0 1
J2101* 6510024040 TM11R-5M2-88-LP 1
J2201* 6450001941 KEY-15S-2A3A (LF) (SN) 1
MP201 8930065740 2590 D-EARTH SPRING 1
MP2001 8930049470 RUBBER SHEET (AS) 2
MP2051 8850001860 FLAT WASHER M3 SUS 3X6X0.5 2
MP2052 8850000420 S-WASHER M3 NI 2
[MEMORY BOARD] (MEM)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510024410 AXK6S30545 1
J2* 6510020120 AXK6S40545P 1
MP1 8930025070 SPONGE (CW) 1
MP2 8930025070 SPONGE (CW) 1
MP3 8930063720 AL SHEET (AN) 1
[NETWORK BOARD] (NET)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510021561 52808-2470 1
J2* 6510017930 1771P145-20 1
J3* 6510017930 1771P145-20 1
J4* 6510003521 S04B-EH-S (LF) (SN) 1
MP1 8510011480 1900 AL COVER 1
[OSC UNIT] (OSC)
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1071* 6510007020 TMP-J01X-V6 1
J1072* 6510007020 TMP-J01X-V6 1
J2016* 6510020091 52808-0871 1
J2017* 6510003401 B04B-EH-S (LF) (SN) 1
[PA UNIT] (PA)
REF ORDER
DESCRIPTION QTY.
NO. NO.
P2* 6510018990 PHR-4 1
P3* 5610000500 179228-3 1
P4* 5610000500 179228-3 1
MF1 2710000860 FBA08A12H 1
MF2 2710000860 FBA08A12H 1
W1
†
8900012790 OPC-1299 1
W2
†
9030090030 16/00/320/B11/V05 1
W3
†
9030090030 16/00/320/B11/V05 1
W4
†
9030090040 16WIRE /08/400/B11/V05 1
W5
†
9030090040 16WIRE /08/400/B11/V05 1
MP1 8820000551 CAP BOLTM4X8 ZK3 8
MP2 8930047252 1900 SPACER-2 7
MP6 8510015991 2590 PA COVER-1 1
MP7 8410002550 2590 PA HEATSINK 1
MP8 8930062121 2590 PA SHEET-1 1
MP9 8930073140 3009 PA ANGLE 1
MP10 8930061221 2590 R-PA ANGLE-1 1
MP12 8930062210 THERMALLY SHEET (AL) 1
MP13 8810009040 SETSCREW (H) 2.6X10 NI 6
MP14 8810007231 SETSCREW (H) 3X8 ZC3 10
MP15 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 8
MP16 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT) 5
MP20 8930063150 THERMALLY SHEET (AR) 2
MP21 8950003640 COATING CLIP CS-2 2
†
: Refer to “GENERAL WIRING” for the connection.
*: Refer to “BOARD LAYOUTS” for the location.
