Icom IC-7700

5 - 31
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[DC-DC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC201 1180003100 S.REG BD9302FP-E2 T 124.4/52.7
IC401 1180003100 S.REG BD9302FP-E2 T 51.4/52.3
IC601 1180003100 S.REG BD9302FP-E2 T 87.9/52.3
IC801 1180002530 S.REG LM2594M-12 T 160.2/59.4
Q141 1590003310 S.TR DTD113ZK T146 T 28.4/79.8
D141 1750000520 S.DIO DAN222TL T 26.2/77.8
D201 1750000960 S.DIO RB081L-20 T 122.8/61.3
D301 1750000960 S.DIO RB081L-20 T 124.7/44.2
D401 1750000960 S.DIO RB081L-20 T 49.8/61.9
D501 1750000960 S.DIO RB081L-20 T 53.8/43.6
D601 1750000960 S.DIO RB081L-20 T 86.4/60.8
D801 1710000840 S.DIO 1SR154-400 TE25 T 149.2/41.5
D802 1750001011 S.DIO MBRD835LT4G T 150.5/57.5
D803 1750000960 S.DIO RB081L-20 T 156.8/67.5
L141 6200001831 S.COL NLV32T-100J T 30.4/74.4
L201 6200013280 S.COL SLF10145T-330M1R6-PF T 118.5/68.1
L211 6200010881 S.COL CDRH124NP-330MC T 132.7/66.9
L301 6200013280 S.COL SLF10145T-330M1R6-PF T 132.2/37.6
L302 6200010901 S.COL CDRH104RNP-100NC T 116.7/37.5
L401 6200013280 S.COL SLF10145T-330M1R6-PF T 45.8/68.9
L411 6200010881 S.COL CDRH124NP-330MC T 59.6/66.2
L501 6200013280 S.COL SLF10145T-330M1R6-PF T 46.2/37
L601 6200013280 S.COL SLF10145T-330M1R6-PF T 82.4/67.6
L611 6200010881 S.COL CDRH124NP-330MC T 96.2/65.9
L801 6190001640 S.COL SLF12555T-101M1R1-PF T 159/47.5
L802 6190001191 S.COL D10F-#A814AY-101K T 166.3/33
L803 6200013280 S.COL SLF10145T-330M1R6-PF T 147.2/30.8
R141 7030008190 S.RES ERJ12YJ330U (33) T 27/73.6
R201 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 114.1/59.1
R202 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 116.9/59.1
R204 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 117.6/57.2
R205 7030005451 S.RES ERA3YED 153V (15 k) T 118/55.4
R301 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 113.4/47.4
R302 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 116.4/47.4
R303 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 118.3/46.5
R304 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 117.6/48.4
R401 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 41.3/58.8
R402 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 43.3/58.1
R403 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k) T 44/60
R404 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 44.6/57.2
R405 7030005451 S.RES ERA3YED 153V (15 k) T 45/55
R501 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 41.5/46
R502 7030003590 S.RES ERJ3GEYJ 183 V (18 k) T 44.3/46
R504 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 44.9/47.8
R601 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 78.1/58.7
R602 7030003600 S.RES ERJ3GEYJ 223 V (22 k) T 80.8/58.7
R604 7030003610 S.RES ERJ3GEYJ 273 V (27 k) T 81.3/56.8
R605 7030005451 S.RES ERA3YED 153V (15 k) T 81.9/54.9
R706 7030003860 S.RES ERJ3GE JPW V T 81.8/49.6
R801 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 155.9/61.4
R802 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 158.1/62.8
C8 4030006880 S.CER C1608 JB 1H 472K-T T 112.7/17.9
C9 4510008700 S.ELE 25 CV 330 BS T 111.6/11.9
C141 4030011600 S.CER C1608 JB 1E 104K-T T 30.7/79.6
C201 4030011280 S.CER C1608 CH 1H 271J-T T 114.1/57.9
C202 4030006860 S.CER C1608 JB 1H 102K-T T 116.1/57.2
C203 4030011600 S.CER C1608 JB 1E 104K-T T 118/54.2
C204 4030011600 S.CER C1608 JB 1E 104K-T T 129.8/57.3
C205 4030018970 S.CER C3225 JB 1C 226MT-N T 114.9/61.3
C206 4030007130 S.CER C1608 CH 1H 101J-T T 118.9/57.4
C207 4030018970 S.CER C3225 JB 1C 226MT-N T 114.4/54
C211 4030011600 S.CER C1608 JB 1E 104K-T T 129.9/54.5
C212 4550007140 S.TAN TEESVD 1C 107M12R T 134.1/49.5
C213 4030018970 S.CER C3225 JB 1C 226MT-N T 133.1/56.6
C214 4030011600 S.CER C1608 JB 1E 104K-T T 137.3/74.4
C301 4030011280 S.CER C1608 CH 1H 271J-T T 114.7/47.4
C302 4030006860 S.CER C1608 JB 1H 102K-T T 115.5/49.4
C303 4030011600 S.CER C1608 JB 1E 104K-T T 118.5/50.3
C304 4030011600 S.CER C1608 JB 1E 104K-T T 129.6/48.1
C305 4030018970 S.CER C3225 JB 1C 226MT-N T 125.3/39.7
C306 4030007130 S.CER C1608 CH 1H 101J-T T 119/48.4
C307 4030018970 S.CER C3225 JB 1C 226MT-N T 116.3/44.4
C308 4030011600 S.CER C1608 JB 1E 104K-T T 106.9/36.2
C401 4030011280 S.CER C1608 CH 1H 271J-T T 41.3/60
C402 4030006860 S.CER C1608 JB 1H 102K-T T 41.9/56.9
C403 4030011600 S.CER C1608 JB 1E 104K-T T 45/53.8
C404 4030011600 S.CER C1608 JB 1E 104K-T T 56.8/56.6
C405 4030018970 S.CER C3225 JB 1C 226MT-N T 41.9/62.1
C406 4030007130 S.CER C1608 CH 1H 101J-T T 46/57.2
C408 4030011600 S.CER C1608 JB 1E 104K-T T 34.6/60
C411 4030011600 S.CER C1608 JB 1E 104K-T T 56.8/53.8
C412 4550007140 S.TAN TEESVD 1C 107M12R T 61/45.3
C413 4030018970 S.CER C3225 JB 1C 226MT-N T 59.6/54.3
C501 4030011280 S.CER C1608 CH 1H 271J-T T 41.5/47.3
C502 4030006860 S.CER C1608 JB 1H 102K-T T 43.5/47.8
C503 4030011600 S.CER C1608 JB 1E 104K-T T 45.3/49.8
C504 4030011600 S.CER C1608 JB 1E 104K-T T 56.7/47.6
C505 4030018970 S.CER C3225 JB 1C 226MT-N T 43.6/43.8
C506 4030007130 S.CER C1608 CH 1H 101J-T T 46.1/47.8
C508 4030011600 S.CER C1608 JB 1E 104K-T T 35.4/47.1
C601 4030011280 S.CER C1608 CH 1H 271J-T T 78.1/57.4
C602 4030006860 S.CER C1608 JB 1H 102K-T T 80.1/56.8
C603 4030011600 S.CER C1608 JB 1E 104K-T T 82.2/52.9
C604 4030011600 S.CER C1608 JB 1E 104K-T T 93.2/56.6
S.=Surface mount
[DC-DC UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C605 4030018970 S.CER C3225 JB 1C 226MT-N T 78.9/60.8
C606 4030007130 S.CER C1608 CH 1H 101J-T T 82.5/56.8
C607 4030018970 S.CER C3225 JB 1C 226MT-N T 77.3/55.3
C608 4030018970 S.CER C3225 JB 1C 226MT-N T 79/52.3
C611 4030011600 S.CER C1608 JB 1E 104K-T T 93.2/54
C612 4550007140 S.TAN TEESVD 1C 107M12R T 97.7/45.3
C613 4030018970 S.CER C3225 JB 1C 226MT-N T 95.9/54.4
C801 4510008910 S.ELE EEEFC1C101P T 148.1/48.1
C802 4030011600 S.CER C1608 JB 1E 104K-T T 160.7/62.8
C803 4510008940 S.ELE EEEFC1V470P T 147.6/66.3
C805 4030018970 S.CER C3225 JB 1C 226MT-N T 150/23.5
RL142 6330001760 RLY AW3023
J1 6510022801 S.CNR B10B-PH-SM4-TB (LF) (SN) T 24.5/23.9
J2 6510020251 S.CNR B9B-PH-SM4-TB (LF) (SN) T 24.5/54.1
J3 6510018941 S.CNR B13B-PH-SM4-TB (LF) (SN) T 60.2/24.5
J5 6510018951 S.CNR B7B-PH-SM4-TB (LF) (SN) T 55.9/10.2
J6 6510023261 S.CNR B6B-PH-SM4-TB (LF) (SN) T 80.3/10.2
J7 6510018921 S.CNR B8B-PH-SM4-TB (LF) (SN) T 91/24.5
J8 6510018971 S.CNR B4B-PH-SM4-TB (LF) (SN) T 112.9/24.5
W1 9030090150 WIR OPC-1803
EP201 6910014730 S.BEA MPZ2012S331A-T T 112/57.1
EP211 6910014730 S.BEA MPZ2012S331A-T T 128.3/74.2
EP301 6910014730 S.BEA MPZ2012S331A-T T 124.8/33.2
EP302 6910014730 S.BEA MPZ2012S331A-T T 103.6/28.4
EP401 6910014730 S.BEA MPZ2012S331A-T T 38.9/60.3
EP402 6910014730 S.BEA MPZ2012S331A-T T 33.4/57.6
EP501 6910014730 S.BEA MPZ2012S331A-T T 40/48.8
EP502 6910014730 S.BEA MPZ2012S331A-T T 34.3/49.3
EP601 6910014730 S.BEA MPZ2012S331A-T T 75.7/58.3
EP602 6910014730 S.BEA MPZ2012S331A-T T 75.7/52.2
[TUNER UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
MF1 2710000780 MTR MP24Z ( STEPPING MOTOR
MF2 2710000780 MTR MP24Z ( STEPPING MOTOR
MF3 2710000470 FAN MF60B-12H901
W1 8900012901 CBL OPC-1345R
W2 8900012901 CBL OPC-1345R
W3 8900017140 CBL OPC-927A (P1,N24,L100)
W51 8600037090 CBL SX2590 P51*P52*P53TU
