Icom IC-7700

5 - 32
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[CTRL BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1140004120 S.IC M38022M2-138FP T 65.7/81.8
IC2 1130010390 S.IC HN58X2416TI T 54/86.9
IC3 1130003921 S.IC TC4S69F (TE85R,F) T 62/59.5
IC4 1180001071 S.IC TA7805F (TE16L,Q) B 71.5/47.5
IC5 1130009691 S.IC TC74HCT7007AF (F) B 92.5/91.6
IC6 1130006441 S.IC TC7S08F (TE85R,F) T 81.7/70.3
IC51 1130011530 S.IC CD74HC4094M96 T 42.2/72.4
IC52 1130007690 S.IC BU4066BCF-E2 B 12.5/76.9
IC55 1130011530 S.IC CD74HC4094M96 B 100.2/76.1
IC56 1130011530 S.IC CD74HC4094M96 B 114.3/76.1
IC57 1160000131 S.IC TD62783AFG (S,EL) T 99.6/73.1
IC58 1160000131 S.IC TD62783AFG (S,EL) T 113.7/73.1
IC101 1110000960 S.IC NJM4558M-TE1-#FMZB T 18.3/47.8
IC151 1120002301 S.IC TC74AC04F (F) B 32.8/53.1
IC153 1130012011 S.IC TC7SZ32F (TE85L,F) T 27.8/48.6
IC154 1130012011 S.IC TC7SZ32F (TE85L,F) T 40.4/48.6
IC155 1130012011 S.IC TC7SZ32F (TE85L,F) T 34.2/51.9
IC156 1130012021 S.IC TC74ACT112F (EL,F) T 35.4/58.9
IC201 1110000960 S.IC NJM4558M-TE1-#FMZB B 61.3/58.2
IC301 1110002690 S.IC NJM2903M-TE1-#FMZB T 80/59
IC401 1160000131 S.IC TD62783AFG (S,EL) T 13.6/86.1
IC402 1160000131 S.IC TD62783AFG (S,EL) T 31.6/84.7
IC403 1160000131 S.IC TD62783AFG (S,EL) B 24.7/88
Q1 1590001330 S.TR DTA114EUA T106 T 78.5/75.2
Q2 1590000680 S.TR DTC114EUA T106 T 77.8/71.2
Q3 1590000680 S.TR DTC114EUA T106 T 128.4/74.5
Q4 1590000680 S.TR DTC114EUA T106 T 128.4/77
Q5 1590000680 S.TR DTC114EUA T106 T 128.4/81.3
Q6 1590000680 S.TR DTC114EUA T106 T 128.4/83.8
Q7 1590000680 S.TR DTC114EUA T106 T 128.4/88.5
Q8 1590000680 S.TR DTC114EUA T106 T 128.4/91
Q9 1590000680 S.TR DTC114EUA T106 T 128.4/95.7
Q10 1590000680 S.TR DTC114EUA T106 T 128.4/100.5
Q11 1590000680 S.TR DTC114EUA T106 B 85.7/99.8
Q51 1590000680 S.TR DTC114EUA T106 T 6.1/78.6
Q52 1590000680 S.TR DTC114EUA T106 T 12.5/78.6
Q53 1590000680 S.TR DTC114EUA T106 B 6.6/72.8
Q54 1560001260 S.FET 2SK3018 T106 B 121.8/80.4
Q55 1590000680 S.TR DTC114EUA T106 B 130.2/68.9
Q59 1590000680 S.TR DTC114EUA T106 T 56.8/69.5
Q151 1590000680 S.TR DTC114EUA T106 B 39.8/42.3
Q152 1590000680 S.TR DTC114EUA T106 B 39.8/39.5
Q153 1590001330 S.TR DTA114EUA T106 B 39.8/45.1
Q201 1560000871 S.FET 2SK515-T1B-A (X33) B 50.4/51.8
Q252 1520000561 S.TR 2SB1123 T-TD-E T 18.8/6.7
Q253 1540000441 S.TR 2SD1619T-TD-E B 26.6/6.7
Q254 1590000680 S.TR DTC114EUA T106 T 24.9/5.4
Q255 1590002420 S.TR UMD3N TR T 97.4/12.1
Q256 1590000680 S.TR DTC114EUA T106 T 101.4/12.4
D1 1730000411 S.ZEN RD5.1M-T2B-A B2 T 69.8/58.7
D2 1710000780 S.DIO MA114 (TX) T 73.8/58.7
D3 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/98.1
D4 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/90
D5 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/82.8
D6 1750000201 S.DIO 1SS319 (TE85R,F) B 129.5/76
D7 1730000031 S.ZEN RD5.6M-T2B-A B2 T 69.8/55.3
D101 1790000491 S.DIO HSM88ASTR-E B 16.5/37.1
D102 1790000491 S.DIO HSM88ASTR-E B 20.5/37.1
D103 1750000201 S.DIO 1SS319 (TE85R,F) B 18.5/57
D151 1790000491 S.DIO HSM88ASTR-E B 33.5/45.3
D152 1790000491 S.DIO HSM88ASTR-E T 37/44.2
D153 1790000491 S.DIO HSM88ASTR-E B 27.6/61.1
D154 1790000491 S.DIO HSM88ASTR-E B 39.4/61.1
D201 1790000491 S.DIO HSM88ASTR-E B 50.3/45.6
D202 1790000491 S.DIO HSM88ASTR-E T 44.9/45.5
D203 1750000201 S.DIO 1SS319 (TE85R,F) B 54.5/58.2
D301 1790000491 S.DIO HSM88ASTR-E B 82.8/52.5
D302 1790000491 S.DIO HSM88ASTR-E B 89.2/58
D303 1710000140 DIO U05G
D304 1750000271 S.DIO 1SS301 (TE85L,F) T 94.6/12.3
X1 6050009890 S.XTL CR-569 (6.144 MHz) T 83.2/79.5
L1 6200003261 S.COL NLV32T-101J T 51.1/76.5
L2 6200003261 S.COL NLV32T-101J T 54.5/77.8
L5 6200005131 S.COL NLC453232T-101K-PF T 121.6/100.3
L51 6200003261 S.COL NLV32T-101J T 106.3/86.9
L52 6200005131 S.COL NLC453232T-101K-PF T 114.9/88.1
L101 6140004410 COL LR-502
L102 6200001831 S.COL NLV32T-100J T 26.7/56.3
L103 6200003261 S.COL NLV32T-101J T 14/56.3
L151 6140004410 COL LR-502
L152 6200001831 S.COL NLV32T-100J T 43.1/62.7
L201 6140004410 COL LR-502
L202 6180003300 COL T6-222J (2.2M)
L301 6140004410 COL LR-502
L302 6200003261 S.COL NLV32T-101J B 76.9/60.8
L403 6140004670 COL LR-527 (CH160808TR271)
L404 6140004670 COL LR-527 (CH160808TR271)
R2 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 63/71
R3 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 64.3/71
R4 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 65.6/71
R5 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 66.9/71
R6 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 74.7/71
R7 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 73.4/71
R8 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 55.4/72.8
S.=Surface mount
[CTRL BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R9 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 54.7/74.7
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 57.3/72.9
R11 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 53.4/74.7
R12 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 78.3/83.9
R13 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 76.6/75.6
R14 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 78.5/78.2
R15 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 61.7/62
R16 7030003320 S.RES ERJ3GEYJ 101 V (100) T 62.2/55.8
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 54.1/82.2
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 54.1/80.9
R19 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 64.7/59
R20 7030003570 S.RES ERJ3GEYJ 123 V (12 k) T 67.7/61.1
R21 7030003650 S.RES ERJ3GEYJ 563 V (56 k) T 66/59
R22 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k) T 73.3/61.1
R23 7030003400 S.RES ERJ3GEYJ 471 V (470) B 105.1/100
R24 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 102.9/98.8
R25 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/99.1
R26 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/97.1
R27 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/91
R28 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/89
R29 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/83.8
R30 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/81.8
R31 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/77
R32 7030003380 S.RES ERJ3GEYJ 331 V (330) B 126/75
R40 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 61.2/99.9
R42 7030003860 S.RES ERJ3GE JPW V T 60.4/71
R43 7030003860 S.RES ERJ3GE JPW V T 60.7/69
R44 7030003860 S.RES ERJ3GE JPW V T 68.2/71
R45 7030003860 S.RES ERJ3GE JPW V T 65.7/68.5
R46 7030003860 S.RES ERJ3GE JPW V T 70.6/68.9
R51 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 35.5/77.3
R52 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 34.2/77.3
R53 7030003860 S.RES ERJ3GE JPW V T 32.9/77.3
R54 7030003860 S.RES ERJ3GE JPW V T 31.6/77.3
R55 7030003860 S.RES ERJ3GE JPW V B 29.6/80.1
R56 7030003860 S.RES ERJ3GE JPW V B 28/80.1
R57 7030003860 S.RES ERJ3GE JPW V B 26.4/80.1
R58 7030003860 S.RES ERJ3GE JPW V B 24.8/80.1
R59 7030003860 S.RES ERJ3GE JPW V T 18.3/78.7
R60 7030003860 S.RES ERJ3GE JPW V T 17/76
R61 7030003860 S.RES ERJ3GE JPW V T 15.7/76
R62 7030003860 S.RES ERJ3GE JPW V T 14.4/78.7
R63 7030003860 S.RES ERJ3GE JPW V T 10.6/78.7
R64 7030003860 S.RES ERJ3GE JPW V T 9.3/74.8
R65 7030003860 S.RES ERJ3GE JPW V T 8/74.8
R66 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) B 15.6/81.6
R67 7030003200 S.RES ERJ3GEYJ 100 V (10) T 99.8/90.4
R68 7030003200 S.RES ERJ3GEYJ 100 V (10) T 98.5/90.4
R69 7030003200 S.RES ERJ3GEYJ 100 V (10) T 97.2/90.4
R70 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 104.8/65.9
R71 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 103.5/65.9
R72 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 102.2/65.9
R73 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 100.9/65.9
R74 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 99.6/65.9
R75 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 98.3/65.9
R76 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 97/65.9
R77 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) T 95.7/65.9
R78 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7) B 120.1/64.6
R84 7030003240 S.RES ERJ3GEYJ 220 V (22) B 110.5/64.6
R85 7030003240 S.RES ERJ3GEYJ 220 V (22) B 108.9/64.6
R86 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 116.1/83.6
R87 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 71.8/94.4
R88 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 75.7/88.1
R89 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 73.3/94.4
R90 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 77.2/88.1
R91 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 74.8/94.4
R92 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 78.7/88.1
R93 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 76.3/94.4
R95 7030003860 S.RES ERJ3GE JPW V T 15.7/78.7
R97 7030003860 S.RES ERJ3GE JPW V T 8/78.7
R101 7030010950 S.RES ERJ1TYJ 100U (10) T 16.4/39.4
R102 7030010950 S.RES ERJ1TYJ 100U (10) T 20.2/39.4
R103 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 16.7/42.9
R104 7030003560 S.RES ERJ3GEYJ 103 V (10 k) B 20.3/42.9
R105 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 15.1/44.5
R106 7030003720 S.RES ERJ3GEYJ 224 V (220 k) B 21.9/44.5
R107 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 12.4/45.8
R108 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 24.1/45.8
R109 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 12.4/47.1
R110 7030003720 S.RES ERJ3GEYJ 224 V (220 k) T 24.1/47.1
R111 7030009340 S.RES ERJ3GEYJ 275V (2.7 M) T 12.4/48.4
R112 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M) T 24.1/48.4
R113 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 14.5/51.4
R114 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 22.4/51.4
R115 7030009340 S.RES ERJ3GEYJ 275V (2.7 M) T 12.4/49.7
R118 7030003860 S.RES ERJ3GE JPW V B 17.5/40.5
R119 7030003860 S.RES ERJ3GE JPW V B 19.5/40.5
R131 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 73.1/81
R132 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 70.1/81.9
R133 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 73.2/82.8
R134 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 70.1/83.7
R135 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 73.2/84.6
R136 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 70.1/85.5
R137 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 73.1/86.4
R138 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 70.1/87.5
R139 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 63.8/94.4
R140 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 65.1/94.4
R141 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 66.4/94.4
R142 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 67.7/94.4
R143 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 69/94.4
R144 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 70.3/94.4
R145 7030003440 S.RES ERJ3GEYJ 102 V (1 k) B 83.5/71.7
R151 7030007190 S.RES ERJ12YJ220U (22) T 32.8/36.7
R152 7030010620 S.RES ERJ12YJ180U (18) B 33.2/36.7
