Icom IC-7700

5 - 38
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[FRONT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
W1 8900017300 CBL OPC-1838 (P1,N16,L140)
W2 8900015940 CBL OPC-875A (P1,N20,L70)
W3 8900015930 CBL OPC-886A (P1,N10,L75)
W4 8900017280 CBL OPC-1836 (P1,N10,L60)
W5 8900014720 CBL OPC-909A (P1,N10,L110)
W6 8900017290 CBL OPC-1837 (P1,N10,L170)
W7 8900017100 CBL OPC-1825 (P1,N18,L70)
W8 8900015930 CBL OPC-886A (P1,N10,L75)
W9 8900014871 CBL OPC-1332A-1 (P0.5,N40,L100)
W10 8900014720 CBL OPC-909A (P1,N10,L110)
W11 8900015930 CBL OPC-886A (P1,N10,L75)
W12 8900015930 CBL OPC-886A (P1,N10,L75)
W13 8900014871 CBL OPC-1332A-1 (P0.5,N40,L100)
EP1 6910015291 UBD LTA070B790F
EP11 6910011090 SUT RMS20-250-201-P
EP12 0880001460 UBD EX-2500 [EUR]
EP101 6910015650 E.OTH S-G2218-3#01 (MOUNT PLATE)
EP102 6910015650 E.OTH S-G2218-3#01 (MOUNT PLATE)
S.=Surface mount
[DISPLAY BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R229 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 32.9/13.4
R230 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 34.2/13.4
R232 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 83.9/13.5
R233 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 85.2/13.5
R234 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 86.5/13.5
R235 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 87.8/13.5
R236 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 89.1/13.5
R237 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 90.4/13.5
R238 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 91.7/13.5
R239 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 30.8/53.2
R240 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 30.8/51.9
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 30.9/54.6
R242 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 33.5/52.3
R246 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 65.3/13.4
R247 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 64/13.4
R248 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 62.7/13.4
R249 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 61.4/13.4
R250 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 60.1/13.4
R251 7030003320 S.RES ERJ3GEYJ 101 V (100) T 58.8/13.4
R252 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 57.5/13.4
R253 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 56.2/13.4
R254 7030003680 S.RES ERJ3GEYJ 104 V (100 k) T 54.9/13.4
R255 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 22.6/14.1
R256 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 26.5/14.1
R257 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 23.9/14.1
R258 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 25.2/14.1
R259 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 40.9/63.4
R260 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 16.4/59.4
R261 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/58.7
R262 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 16/56
R263 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/55.6
R264 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 16/54.7
R265 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/54.3
R266 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 16/53.4
R267 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/53
R268 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.2/52.1
R270 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.2/50.8
R272 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/51.7
R273 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/50.4
R274 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.2/49.5
R275 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/49.1
R276 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/72.6
R278 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/62.2
R279 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/62
R280 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/63.5
R281 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/63.3
R282 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/64.8
R295 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/67.4
R296 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.2/67.2
R297 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/68.7
R298 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/68.5
R299 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/64.6
R300 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 15.9/71.3
R301 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 6.3/71.1
R302 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 6.3/69.8
R303 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 15.9/70
R304 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 6.3/65.9
R305 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 15.9/66.1
R310 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/22.4
R311 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 14.6/21.1
R312 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/20.4
R313 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/19.1
R320 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/26.9
R321 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/25.6
R322 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/24.3
R323 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 135/28.2
R326 7030003360 S.RES ERJ3GEYJ 221 V (220) T 119.8/54.4
R327 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 115.4/55.1
R328 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 115/61.2
R329 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 52/21.3
R330 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k) T 134.4/63
R333 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 16/57.3
R334 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 6.3/56.9
R337 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 19.7/57.3
R338 7030003670 S.RES ERJ3GEYJ 823 V (82 k) T 2.8/56.9
R339 7070000261 RES ERG2SJ 220 (22)
R340 7070000261 RES ERG2SJ 220 (22)
R342 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 80.2/38.1
R343 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 115.1/57.7
R351 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135.3/74.9
R352 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135.3/76.2
R353 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 50/69.5
R354 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 50/66.8
R355 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 50/68.2
R356 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 128.4/9.8
R357 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 119.4/10
R358 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 128.5/11.8
R359 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 119.4/11.3
R360 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 128.5/13.8
R361 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 119.4/12.6
R362 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/23
R363 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 135/21.7
R364 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 51.1/51.6
R365 7030004730 S.RES ERJ3GEYF 222 V (2.2 k) T 49.8/51.6
R366 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 134.4/70.6
R369 7030003860 S.RES ERJ3GE JPW V T 44.8/51.7
R501 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 52/22.6
R502 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 52/23.9
R503 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 54.7/20.6
R504 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 134.4/69.3
R505 7030003330 S.RES ERJ3GEYJ 121 V (120) T 134.4/68
R506 7030003640 S.RES ERJ3GEYJ 473 V (47 k) T 52/20
R601 7030003860 S.RES ERJ3GE JPW V T 119.6/80.2
R602 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k) T 115.8/80.2
[DISPLAY BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1130009640 S.IC BU4051BCFV-E2 T 113/15
IC3 1130009640 S.IC BU4051BCFV-E2 T 85.2/18.4
IC4 1130009640 S.IC BU4051BCFV-E2 T 43.4/78.7
IC5 1130009640 S.IC BU4051BCFV-E2 T 44.7/68.7
IC6 1140014420 S.IC M30620FCMGP (SX-3009B) T 52.4/39
IC7 1130011510 S.IC BU2099FV-E2 T 72.2/59.8
IC201 1130009301 S.IC TC7SET08FU (T5L,JF) T 81/40.5
IC202 1130009301 S.IC TC7SET08FU (T5L,JF) T 117.2/58.5
IC601 1130011551 S.IC RX-4581NB-F T 35.5/29.3
IC651 1110005821 S.IC R3112N281A-TR-F T 120.7/71.8
Q200 1590000430 S.TR DTC144EUA T106 T 117.7/80.1
Q201 1530003301 S.TR 2SC3647S-TD-E T 100.7/47.1
Q202 1530003301 S.TR 2SC3647S-TD-E T 98.1/26.5
Q203 1530002060 S.TR 2SC4081 T106 R T 85.4/50.2
Q204 1520000651 S.TR 2SB1201S-TL-E T 91/53.9
Q205 1590000680 S.TR DTC114EUA T106 T 82.3/45.9
Q206 1590000680 S.TR DTC114EUA T106 T 134.4/14.6
Q209 1520000651 S.TR 2SB1201S-TL-E T 123.9/59.9
Q210 1530002060 S.TR 2SC4081 T106 R T 117.3/55.3
Q211 1590001330 S.TR DTA114EUA T106 T 131.8/63.5
Q212 1590000680 S.TR DTC114EUA T106 T 84/43.1
Q501 1590000680 S.TR DTC114EUA T106 T 131.5/73.3
Q502 1590000680 S.TR DTC114EUA T106 T 29.6/46
Q503 1590000680 S.TR DTC114EUA T106 T 29.6/48.5
Q504 1590001330 S.TR DTA114EUA T106 T 131.5/68.3
Q505 1590000680 S.TR DTC114EUA T106 T 131.5/70.8
Q601 1510000501 S.TR 2SA1162-GR (TE85R,F) T 113.6/80.4
D7 1750000520 S.DIO DAN222TL T 130.4/18.3
D8 1160000140 S.DIO DAP222 TL T 130.4/16.2
D9 1730002340 S.ZEN MA8047-M (TX) T 85.8/48.1
D10 1730002590 S.ZEN MA8033-H (TX) T 119.5/56.9
D11 1790001670 S.DIO RB706F-40T106 T 135.2/17.1
D12 1790001670 S.DIO RB706F-40T106 T 50.7/54
D601 1790001250 S.DIO MA2S111-(TX) T 111.5/81.6
D602 1790001250 S.DIO MA2S111-(TX) T 113.3/78
D603 1790001250 S.DIO MA2S111-(TX) T 111.5/78.9
X1 6050009870 S.XTL CR-567 (9.8304 MHz) T 35.6/40.5
L201 6200001831 S.COL NLV32T-100J T 31.1/58.1
L204 6200001831 S.COL NLV32T-100J T 25.9/73.2
L210 6190001191 S.COL D10F-#A814AY-101K T 88.9/64.9
L211 6190001191 S.COL D10F-#A814AY-101K T 89.6/30.2
L601 6200001831 S.COL NLV32T-100J T 116.7/77.3
R200 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 84.6/40.4
R201 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) T 103.6/43.6
R202 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k) T 103.6/32.9
R203 7030003800 S.RES ERJ3GEYJ 105 V (1 M) T 38.9/40.5
R208 7030003360 S.RES ERJ3GEYJ 221 V (220) T 86.5/45.7
R209 7030003860 S.RES ERJ3GE JPW V T 16.1/24.6
R210 7030003860 S.RES ERJ3GE JPW V T 23.7/24
R212 7030003660 S.RES ERJ3GEYJ 683 V (68 k) T 80.1/45.5
R213 7030003580 S.RES ERJ3GEYJ 153 V (15 k) T 81.8/43.4
R214 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 50.7/13.4
R215 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 49.4/13.4
R216 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 48.1/13.4
R217 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 46.8/13.4
R218 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 45.5/13.4
R219 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 44.2/13.4
R220 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 41.6/13.6
R221 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 42.9/13.4
R222 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 40.6/16.1
R223 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 39.8/13.5
R224 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 39.1/16.1
R225 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 38.3/13.4
R226 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 37.6/16.1
R227 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 36.8/13.4
R228 7030003440 S.RES ERJ3GEYJ 102 V (1 k) T 35.5/13.4
