5 - 9
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
J103 6510023750 CNR 01K1971-10 ()
J104 6510023750 CNR 01K1971-10 ()
J105 6510023750 CNR 01K1971-10 ()
J106 6510007020 CNR TMP-J01X-V6
J108 6510007020 CNR TMP-J01X-V6
J351 6510007020 CNR TMP-J01X-V6
J352 6510007020 CNR TMP-J01X-V6
J391 6510007020 CNR TMP-J01X-V6
J501 6510007020 CNR TMP-J01X-V6
J502 6510007020 CNR TMP-J01X-V6
J503 6510007020 CNR TMP-J01X-V6
J801 6510007020 CNR TMP-J01X-V6
J808 6510007020 CNR TMP-J01X-V6
J810 6510007020 CNR TMP-J01X-V6
J1001 6510007020 CNR TMP-J01X-V6
J1101 6510007020 CNR TMP-J01X-V6
J1301 6510007020 CNR TMP-J01X-V6
J1401 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1402 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1403 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1404 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1405 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1406 6910004741 CNR IMSA-9202B-1-03Z041-PT1
J1501 6510015541 S.CNR B4B-ZR-SM4-TF (LF) (SN) T 168.2/21.6
J1651 6510007020 CNR TMP-J01X-V6
J2001 6510024940 CNR HEC2305-016250
J2002 6510023730 CNR LGY6502-0600C
J2003 6510023730 CNR LGY6502-0600C
J2004 6510007020 CNR TMP-J01X-V6
J2006 6510019991 S.CNR 52808-2271 (2291) T 168.3/166.7
J2007 6510018921 S.CNR B8B-PH-SM4-TB (LF) (SN) T 168.2/204.1
F3 5210000041 FUS FGB 2A PBF (FGB0 125V)
F2001 5220000230 HOL S-N5054 #01
F2002 5220000230 HOL S-N5054 #01
W1 8970024311 WIR 1.5D COAXIAL TUBE/C31
W3 9030090170 WIR OPC-1805
W1411 7120000480 S.JMP MJP-0.4-T T 67.2/15
EP902 6910012350 S.BEA MMZ1608Y 102BT B 60.6/134.1
EP903 6910012350 S.BEA MMZ1608Y 102BT B 60.6/148.7
EP904 6910012350 S.BEA MMZ1608Y 102BT B 104.9/141.8
EP1091 6910014690 S.BEA MPZ1608S221A-T T 49/51.9
EP1092 6910014690 S.BEA MPZ1608S221A-T T 49/53.2
EP1093 6910014690 S.BEA MPZ1608S221A-T T 49/54.5
EP1201 6910012350 S.BEA MMZ1608Y 102BT B 59/124.9
EP1202 6910012350 S.BEA MMZ1608Y 102BT B 59/94.2
EP1210 6910012350 S.BEA MMZ1608Y 102BT B 59/128
EP1229 6910014690 S.BEA MPZ1608S221A-T B 28.2/69.2
EP1309 6910014690 S.BEA MPZ1608S221A-T B 38.1/72.4
EP1504 6910014690 S.BEA MPZ1608S221A-T B 132.3/22.7
EP1505 6910014690 S.BEA MPZ1608S221A-T T 143.3/10.6
EP1654 6910012350 S.BEA MMZ1608Y 102BT B 84.5/35
EP1801 6910012350 S.BEA MMZ1608Y 102BT B 78.9/102.4
EP1802 6910012350 S.BEA MMZ1608Y 102BT T 41.6/139.1
EP1803 6910014690 S.BEA MPZ1608S221A-T B 75.8/102.4
EP1805 6910012350 S.BEA MMZ1608Y 102BT B 104.9/143.4
EP1806 6910012350 S.BEA MMZ1608Y 102BT B 78.9/105.6
EP1807 6910012350 S.BEA MMZ1608Y 102BT B 75.8/105.6
EP1808 6910012350 S.BEA MMZ1608Y 102BT B 154.1/14.5
EP1809 6910012350 S.BEA MMZ1608Y 102BT B 104.9/145
EP1810 6910012350 S.BEA MMZ1608Y 102BT T 23.1/132.8
EP1811 6910012350 S.BEA MMZ1608Y 102BT T 23.1/135.6
EP1812 6910012350 S.BEA MMZ1608Y 102BT B 104.9/146.6
EP1813 6910012350 S.BEA MMZ1608Y 102BT T 55.2/131.7
EP1814 6910012350 S.BEA MMZ1608Y 102BT T 55.2/130.4
EP1815 6910012350 S.BEA MMZ1608Y 102BT T 6.8/124
EP1816 6910012350 S.BEA MMZ1608Y 102BT T 55.2/133
EP1817 6910012350 S.BEA MMZ1608Y 102BT B 15.4/140.2
EP1818 6910012350 S.BEA MMZ1608Y 102BT B 104.9/138.6
EP1826 6910012350 S.BEA MMZ1608Y 102BT B 104.9/140.2
EP1828 6910014690 S.BEA MPZ1608S221A-T B 172.1/100
EP1830 6910012350 S.BEA MMZ1608Y 102BT B 69.6/10.5
EP1831 6910012350 S.BEA MMZ1608Y 102BT T 38.4/88.2
EP1832 6910012350 S.BEA MMZ1608Y 102BT T 42.3/88.2
EP1833 6910012350 S.BEA MMZ1608Y 102BT T 49/50.6
EP1834 6910012350 S.BEA MMZ1608Y 102BT B 27.5/2.9
EP1835 6910012350 S.BEA MMZ1608Y 102BT T 49/48
EP1836 6910012350 S.BEA MMZ1608Y 102BT B 27.5/6.1
EP1837 6910012350 S.BEA MMZ1608Y 102BT T 49/49.3
EP1838 6910012350 S.BEA MMZ1608Y 102BT B 27.5/4.5
EP1901 6910014690 S.BEA MPZ1608S221A-T T 136.8/137.7
EP2001 6910012350 S.BEA MMZ1608Y 102BT B 166.5/245.8
EP2002 6910014690 S.BEA MPZ1608S221A-T T 115.4/235.4
EP2003 6910012350 S.BEA MMZ1608Y 102BT B 142.1/245.8
EP2004 6910012350 S.BEA MMZ1608Y 102BT T 172.8/177.5
EP2005 6910012350 S.BEA MMZ1608Y 102BT T 161.9/175.2
EP2006 6910012350 S.BEA MMZ1608Y 102BT T 172.8/172.9
EP2007 6910012350 S.BEA MMZ1608Y 102BT T 161.9/173.7
EP2008 6910012350 S.BEA MMZ1608Y 102BT T 161.9/172.2
EP2009 6910012350 S.BEA MMZ1608Y 102BT T 161.9/170.7
EP2010 6910012350 S.BEA MMZ1608Y 102BT T 172.8/170.2
EP2011 6910012350 S.BEA MMZ1608Y 102BT T 172.8/160.2
EP2012 6910012350 S.BEA MMZ1608Y 102BT T 172.8/158.2
EP2013 6910014690 S.BEA MPZ1608S221A-T T 163.5/208
EP2014 6910014690 S.BEA MPZ1608S221A-T T 163.5/205.4
EP2015 6910014690 S.BEA MPZ1608S221A-T T 163.5/202.8
EP2016 6910014690 S.BEA MPZ1608S221A-T T 163.5/200.2
EP2017 6910014690 S.BEA MPZ1608S221A-T T 163.5/197.6
EP2018 6910014690 S.BEA MPZ1608S221A-T T 163.5/210.6
S.=Surface mount
[MCF-W BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI1401 2030000281 S.MLH FL-364A (64.455 MHz) T 19.9/6.5
L1401 6150004280 COL LS-484B (C-14927)
L1402 6150004280 COL LS-484B (C-14927)
C1401 4030006900 S.CER C1608 JB 1H 103K-T T 4.3/6.5
C1402 4030007030 S.CER C1608 CH 1H 150J-T T 14.6/6.5
C1404 4030006990 S.CER C1608 CH 1H 080D-T T 18.5/2.1
C1406 4030007030 S.CER C1608 CH 1H 150J-T T 25.3/6.5
C1408 4030006900 S.CER C1608 JB 1H 103K-T T 35.6/6.5
[MCF-M BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI1401 2030000331 S.MLH FL-358A (64.455 MHz) T 19.9/6.5
L1401 6150004280 COL LS-484B (C-14927)
L1402 6150004280 COL LS-484B (C-14927)
C1401 4030006900 S.CER C1608 JB 1H 103K-T T 4.3/6.5
C1402 4030009920 S.CER C1608 CH 1H 050B-T T 14.6/6.5
C1403 4030007020 S.CER C1608 CH 1H 120J-T T 13.3/6.5
C1404 4030006990 S.CER C1608 CH 1H 080D-T T 18.5/2.1
C1405 4030009920 S.CER C1608 CH 1H 050B-T T 21.3/2.1
C1406 4030007020 S.CER C1608 CH 1H 120J-T T 25.3/6.5
C1407 4030009920 S.CER C1608 CH 1H 050B-T T 26.6/6.5
C1408 4030006900 S.CER C1608 JB 1H 103K-T T 35.6/6.5
[MCF-N BOARD]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
FI1401 2030000510 S.MLH FL-396 (64.455 MHz) T 19.9/6.5
L1401 6150004280 COL LS-484B (C-14927)
L1402 6150004280 COL LS-484B (C-14927)
C1401 4030006900 S.CER C1608 JB 1H 103K-T T 4.3/6.5
C1402 4030007020 S.CER C1608 CH 1H 120J-T T 14.6/6.5
C1403 4030007020 S.CER C1608 CH 1H 120J-T T 13.3/6.5
C1404 4030007030 S.CER C1608 CH 1H 150J-T T 18.5/2.1
C1405 4030007030 S.CER C1608 CH 1H 150J-T T 21.3/2.1
C1406 4030007020 S.CER C1608 CH 1H 120J-T T 25.3/6.5
C1407 4030007020 S.CER C1608 CH 1H 120J-T T 26.6/6.5
C1408 4030006900 S.CER C1608 JB 1H 103K-T T 35.6/6.5
