5 - 15
M.=Mounted side (T: Mounted on the Top side B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
EP752 6910014730 S.BEA MPZ2012S331A-T T 8.9/95.9
EP811 6910014690 S.BEA MPZ1608S221A-T T 32.2/5.3
EP812 6910014690 S.BEA MPZ1608S221A-T T 30.8/5.4
EP813 6910014690 S.BEA MPZ1608S221A-T T 26.2/5.3
EP814 6910012350 S.BEA MMZ1608Y 102BT T 24.2/5.3
EP815 6910014690 S.BEA MPZ1608S221A-T T 22.2/5.4
EP816 6910014690 S.BEA MPZ1608S221A-T T 19.4/16.6
EP842 6910014690 S.BEA MPZ1608S221A-T T 35/59.6
EP843 6910014690 S.BEA MPZ1608S221A-T T 35/57.6
EP851 6910012350 S.BEA MMZ1608Y 102BT B 75.3/71.7
EP852 6910012350 S.BEA MMZ1608Y 102BT B 75.3/73.5
EP853 6910012350 S.BEA MMZ1608Y 102BT B 75.3/75.3
EP854 6910014690 S.BEA MPZ1608S221A-T B 75.3/77.1
EP855 6910012350 S.BEA MMZ1608Y 102BT B 75.3/80.1
EP941 6910012350 S.BEA MMZ1608Y 102BT B 10/31
EP942 6910012350 S.BEA MMZ1608Y 102BT T 4.8/30
EP943 6910012350 S.BEA MMZ1608Y 102BT B 9.9/29
EP944 6910012350 S.BEA MMZ1608Y 102BT T 4.8/28
EP954 6910012350 S.BEA MMZ1608Y 102BT B 10/19.3
EP987 6910012350 S.BEA MMZ1608Y 102BT T 172.1/39
EP991 6910012350 S.BEA MMZ1608Y 102BT T 166.1/38
EP992 6910012350 S.BEA MMZ1608Y 102BT T 166.1/40.6
EP1001 6910014690 S.BEA MPZ1608S221A-T B 119.2/17
EP1251 6910014690 S.BEA MPZ1608S221A-T T 112.3/8.1
EP1401 6910014690 S.BEA MPZ1608S221A-T T 85/31
EP1498 6910014690 S.BEA MPZ1608S221A-T T 103.6/71.7
EP1651 6910014690 S.BEA MPZ1608S221A-T B 162.6/11.1
EP1911 6910014690 S.BEA MPZ1608S221A-T B 120.1/83.4
S.=Surface mount
[PLL UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1130011530 S.IC CD74HC4094M96 B 151.5/16.9
IC2 1130009691 S.IC TC74HCT7007AF (F) T 152.7/17.7
IC51 1180001251 S.IC TA7808F (TE16L,Q) T 164.8/92.2
IC61 1180000421 S.IC TA78L05F (TE12R,F) B 168.5/68.5
IC101 1190002101 S.IC AD9951YSVZ T 101.2/27.2
IC102 1130010560 S.IC SN74AHC244PWR T 113/33
IC103 1180003190 S.REG uPD120N33TA-E1-A T 111.4/40.1
IC104 1180003200 S.REG uPD120N18TA-E1-A T 103.2/40.1
IC201 1130013270 S.IC ADF4116BRUZ T 149.5/36.7
IC501 1140007881 S.IC TC190G08EFG0046JDZ/SC1246A T 50.1/42.7
IC503 1130003831 S.IC TC7S04F (TE85R,F) T 38.5/43.1
IC602 1130006441 S.IC TC7S08F (TE85R,F) T 98.2/50.6
IC651 1140007881 S.IC TC190G08EFG0046JDZ/SC1246A T 12.7/71
IC652 1130003831 S.IC TC7S04F (TE85R,F) T 10.2/58.4
IC1651 1130003831 S.IC TC7S04F (TE85R,F) T 30.7/26.5
IC1652 1140007881 S.IC TC190G08EFG0046JDZ/SC1246A T 16.7/22.8
IC1701 1130006441 S.IC TC7S08F (TE85R,F) T 30.4/20.3
Q1 1590001050 S.TR DTC114TUA T106 B 158.2/17.2
Q30 1530002060 S.TR 2SC4081 T106 R B 74.5/32.1
Q41 1590000680 S.TR DTC114EUA T106 T 142.8/8.9
Q101 1530003151 S.TR 2SC4673D-TD-E T 89.7/30.3
Q151 1530002060 S.TR 2SC4081 T106 R B 130.9/43.8
Q201 1590000680 S.TR DTC114EUA T106 T 154.3/38.1
Q220 1560000331 S.FET 2SK210-GR (TE85R,F) T 150.8/83
Q230 1560000331 S.FET 2SK210-GR (TE85R,F) T 138.3/83
Q240 1560000331 S.FET 2SK210-GR (TE85R,F) T 125.8/83
Q250 1560000331 S.FET 2SK210-GR (TE85R,F) T 113.3/83
Q260 1560000331 S.FET 2SK210-GR (TE85R,F) T 100.8/83
Q270 1560000331 S.FET 2SK210-GR (TE85R,F) T 88.9/83
Q280 1590000680 S.TR DTC114EUA T106 T 150.3/92.8
Q281 1590000680 S.TR DTC114EUA T106 T 137.8/92.8
Q282 1590000680 S.TR DTC114EUA T106 T 125.3/92.8
Q283 1590000680 S.TR DTC114EUA T106 T 112.8/92.8
Q284 1590000680 S.TR DTC114EUA T106 T 100.3/92.8
Q285 1590000680 S.TR DTC114EUA T106 T 88.3/92.8
Q301 1530003431 S.TR 2SC5226-4-TL-E T 154.6/102.6
Q302 1530003431 S.TR 2SC5226-4-TL-E B 141.5/99.6
Q303 1530003431 S.TR 2SC5226-4-TL-E B 158/101.7
Q341 1590000680 S.TR DTC114EUA T106 T 148/96.8
Q351 1580000751 S.FET 3SK294 (TE85L,F) T 127.8/103.2
Q352 1530003431 S.TR 2SC5226-4-TL-E B 121/99.6
Q441 1590000680 S.TR DTC114EUA T106 T 111/97
Q502 1590000680 S.TR DTC114EUA T106 T 63.3/52.9
Q540 1530002060 S.TR 2SC4081 T106 R T 57.7/75.9
Q541 1560000331 S.FET 2SK210-GR (TE85R,F) T 41.1/73.5
Q561 1530003431 S.TR 2SC5226-4-TL-E T 41.4/82.4
Q580 1530003431 S.TR 2SC5226-4-TL-E T 45.2/53.1
Q591 1530003151 S.TR 2SC4673D-TD-E B 64.9/84.2
Q592 1520000561 S.TR 2SB1123 T-TD-E B 73/87.3
Q593 1590000680 S.TR DTC114EUA T106 B 72.8/97.5
Q680 1530002060 S.TR 2SC4081 T106 R T 8.5/85.5
Q702 1530002601 S.TR 2SC4215-O (TE85R,F) B 78.1/38.7
Q801 1560000561 S.FET 2SK882-GR (TE85L,F) T 61.1/92.1
Q811 1560000561 S.FET 2SK882-GR (TE85L,F) T 18.3/92.7
Q831 1560000561 S.FET 2SK882-GR (TE85L,F) T 22.1/102.6
Q832 1520000561 S.TR 2SB1123 T-TD-E T 53/99.4
Q833 1590000680 S.TR DTC114EUA T106 B 51.7/106.6
Q1601 1530002601 S.TR 2SC4215-O (TE85R,F) T 80.7/56.2
Q1680 1530002060 S.TR 2SC4081 T106 R T 15.9/51.6
D201 1750000520 S.DIO DAN222TL T 144.7/6.6
D205 1790001250 S.DIO MA2S111-(TX) T 154.3/30.7
D220 1720000590 S.VCP MA357 (TX) T 152.9/61.3
D221 1720000590 S.VCP MA357 (TX) T 152.9/63.4
D222 1790000620 S.DIO MA77 (TX) T 154.9/93.4
D230 1720000590 S.VCP MA357 (TX) T 140.5/61.3
D231 1720000590 S.VCP MA357 (TX) T 140.5/63.4
D232 1790000620 S.DIO MA77 (TX) T 142.5/93.1
D240 1720000590 S.VCP MA357 (TX) T 128/61.3
D242 1790000620 S.DIO MA77 (TX) T 129.9/93.4
D250 1720000590 S.VCP MA357 (TX) T 115.5/61.3
D252 1790000620 S.DIO MA77 (TX) T 117.4/93.4
D261 1720000590 S.VCP MA357 (TX) T 103/63.4
D262 1790000620 S.DIO MA77 (TX) T 104.9/93.4
D263 1720000590 S.VCP MA357 (TX) T 100.3/62.9
D270 1720000590 S.VCP MA357 (TX) T 90.5/61.3
D271 1720000590 S.VCP MA357 (TX) T 88/62.9
D272 1790000620 S.DIO MA77 (TX) T 92.7/93.4
D341 1790000620 S.DIO MA77 (TX) T 147.5/100.5
D342 1160000070 S.DIO DAN202K T146 B 136/91.6
D441 1790000620 S.DIO MA77 (TX) T 110.3/100.1
D501 1750000520 S.DIO DAN222TL T 60.5/53.4
D542 1720000590 S.VCP MA357 (TX) T 45.5/62.1
D821 1750000431 S.DIO HSB88WSTR-E T 43.4/97.3
FI101 2020001820 S.CER SFECV10M5FA00-R0 T 112.2/22.2
FI831 2030000300 S.MLH FL-356 (64.491 MHz) T 27/103
L1 6200003261 S.COL NLV32T-101J B 156.6/23.9
L2 6200003261 S.COL NLV32T-101J T 155.8/24.7
L20 6200003321 S.COL NLV32T-3R3J T 79.6/102.1
L30 6200005491 S.COL NLV32T-331J T 73.1/27.7
L101 6200001831 S.COL NLV32T-100J T 114.6/39.5
L102 6200002641 S.COL NLV25T-R15J T 90.4/23.4
L103 6140002810 S.COL LR-317 ( T 104/15.2
L123 6200004951 S.COL NLV25T-1R8J T 113.7/16.7
L161 6200001981 S.COL NLV25T-1R0J B 123.4/35.6
L201 6200005011 S.COL NLV25T-100J T 143.3/31
L211 6200003661 S.COL NLV25T-R68J B 153/54.3
