[CHASSIS PARTS] (CH)
REF ORDER
DESCRIPTION
QTY.
NO. NO.
P111* 6510003240 TMP-P01X-A1 1
P112* 6510003240 TMP-P01X-A1 1
P115* 6510003240 TMP-P01X-A1 1
P116* 6510003240 TMP-P01X-A1 1
P117* 6510003240 TMP-P01X-A1 1
P118* 6510003240 TMP-P01X-A1 1
P119* 6510003240 TMP-P01X-A1 1
P120* 6510003240 TMP-P01X-A1 1
P121* 6510003240 TMP-P01X-A1 1
P122* 6510003240 TMP-P01X-A1 1
P123* 6510003240 TMP-P01X-A1 1
P124* 6510003240 TMP-P01X-A1 1
P131* 6510003240 TMP-P01X-A1 1
P132* 6510003240 TMP-P01X-A1 1
P134* 6510003240 TMP-P01X-A1 1
P135* 6510003240 TMP-P01X-A1 1
P136* 6510003240 TMP-P01X-A1 1
P137* 6510003240 TMP-P01X-A1 1
P138* 6510003240 TMP-P01X-A1 1
P139* 6510003240 TMP-P01X-A1 1
P140* 6510003240 TMP-P01X-A1 1
P141* 6510003240 TMP-P01X-A1 1
P201* 6510019130 PHR-8 1
P202* 6510019130 PHR-8 1
P211* 6510018990 PHR-4 1
P212* 6510020280 PHR-9 1
P213* 6510019010 PHR-13 1
P231* 5610000490 PHR-6 1
P232* 5610000490 PHR-6 1
P241* 6510003630 EHR-03 1
P242* 6510003640 EHR-04 1
P243* 6510019000 PHR-7 1
P251* 5610000350 PHR-10 1
P252* 5610000350 PHR-10 1
P261* 6510020280 PHR-9 1
P262* 6510020280 PHR-9 1
P301* 6510009600 ZHR-4 1
P302* 6510009600 ZHR-4 1
P331* 5610000490 PHR-6 1
P332* 5610000490 PHR-6 1
P341* 5610000490 PHR-6 1
P342* 6510019130 PHR-8 1
P343* 6510020750 PHR-3 1
P381* 6510009660 ZHR-10 1
P382* 6510009660 ZHR-10 1
SP1 2510001390 2844 SP BOX 1
W1
†
8900015500 OPC-1113A 1
W2
†
8900017320 OPC-1840 1
W3
†
8900017270 OPC-1835 1
W4
†
8900017330 OPC-1841 1
W5
†
8900017510 OPC-1851 1
W6
†
8900015120 OPC-942B 1
W7
†
8900017080 OPC-1806 1
W8
†
8900017240 OPC-1832 1
W9
†
8900017250 OPC-1833 1
W10
†
8900017110 OPC-1814 1
W11
†
8900017310 OPC-1839 1
W12
†
8900017090 OPC-1826 1
W101
†
8900013031 OPC-1346R 1
W102
†
8900013041 OPC-1347R 1
W103
†
8900013051 OPC-1348R 1
W111
†
9025900220 62/99/390/C31/C31 1
W112
†
9086700300 WIRE 8 1
W113
†
9030090320 OPC-1859 1
W115
†
9025900590 62/99/360/C31/C31 1
W116
†
9086700300 WIRE 8 1
W117
†
9025900590 62/99/360/C31/C31 1
W118
†
9086700300 WIRE 8 1
W119
†
9025900590 62/99/360/C31/C31 1
W120
†
9086700300 WIRE 8 1
W121
†
9025900620 62/99/510/C31/C31 1
W122
†
9086700300 WIRE 8 1
W123
†
9025900620 62/99/510/C31/C31 1
W124
†
9086700300 WIRE 8 1
W125
†
9030090310 OPC-1850 1
W127
†
9030090330 OPC-1860 1
W129
†
9030090450 OPC-1881 1
W131
†
9025900590 62/99/360/C31/C31 1
W132
†
9086700300 WIRE 8 1
W133
†
9030090160 OPC-1804 1
W134
†
9025900280 62/99/600/C31/C31 1
W135
†
9086700300 WIRE 8 1
W136
†
9025900110 62/99/300/C31/C31 1
W137
†
9086700300 WIRE 8 1
W138
†
9025900110 62/99/300/C31/C31 1
W139
†
9086700300 WIRE 8 1
W140
†
9025900210 62/99/450/C31/C31 1
W141
†
9086700300 WIRE 8 1
W201
†
9030090350 17/02/470/B11/B11 1
W202
†
9030090350 17/02/470/B11/B11 1
W203
†
9030090350 17/02/470/B11/B11 1
W204
†
9030090350 17/02/470/B11/B11 1
W205
†
9030090350 17/02/470/B11/B11 1
W206
†
9030090360 15/09/470/B11/B11 1
W207
†
9030090360 15/09/470/B11/B11 1
W208
†
9030090350 17/02/470/B11/B11 1
W211
†
9030090280 17/01/490/B11/B11 1
W212
†
9030090280 17/01/490/B11/B11 1
W213
†
9030090280 17/01/490/B11/B11 1
W214
†
9030090280 17/01/490/B11/B11 1
W221
†
9030090370 17/03/430/B11/B11 1
[CHASSIS PARTS] (CH)
REF ORDER
DESCRIPTION
QTY.
NO. NO.
W222
†
9030090370 17/03/430/B11/B11 1
W223
†
9030090370 17/03/430/B11/B11 1
W224
†
9030090370 17/03/430/B11/B11 1
W225
†
9030090370 17/03/430/B11/B11 1
W226
†
9030090370 17/03/430/B11/B11 1
W227
†
9030090370 17/03/430/B11/B11 1
W228
†
9030090370 17/03/430/B11/B11 1
W229
†
9030090370 17/03/430/B11/B11 1
W231
†
9030090410 17/06/360/B11/B11 1
W232
†
9030090410 17/06/360/B11/B11 1
W233
†
9030090410 17/06/360/B11/B11 1
W234
†
9030090420 15/09/360/B11/B11 1
W235
†
9030090410 17/06/360/B11/B11 1
W236
†
9030090410 17/06/360/B11/B11 1
W241
†
9030090430 17/07/250/B06/B11 1
W242
†
9030090430 17/07/250/B06/B11 1
W243
†
9030090430 17/07/250/B06/B11 1
W244
†
9030090440 17/10/180/B06/B11 1
W245
†
9030090440 17/10/180/B06/B11 1
W246
†
9030090440 17/10/180/B06/B11 1
W247
†
9030090440 17/10/180/B06/B11 1
W251
†
9030090190 17/04/600/B11/B11 1
W252
†
9030090190 17/04/600/B11/B11 1
W253
†
9030090190 17/04/600/B11/B11 1
W254
†
9030090190 17/04/600/B11/B11 1
W255
†
9030090190 17/04/600/B11/B11 1
W256
†
9030090190 17/04/600/B11/B11 1
W257
†
9030090190 17/04/600/B11/B11 1
W258
†
9030090190 17/04/600/B11/B11 1
W259
†
9030090190 17/04/600/B11/B11 1
W261
†
9030090180 15/05/600/B11/B11 1
W262
†
9030090180 15/05/600/B11/B11 1
W263
†
9030090180 15/05/600/B11/B11 1
W264
†
9030090180 15/05/600/B11/B11 1
W265
†
9030090180 15/05/600/B11/B11 1
W266
†
9030090180 15/05/600/B11/B11 1
W267
†
9030090180 15/05/600/B11/B11 1
W268
†
9030090180 15/05/600/B11/B11 1
W269
†
9030090180 15/05/600/B11/B11 1
W271
†
9030090341 OPC-1861A 1
W301
†
9030090290 51/99/360/B09A/B09A 1
W302
†
9086400440 WIRE 08 A A 1
W303
†
9030090290 51/99/360/B09A/B09A 1
W304
†
9086400440 WIRE 08 A A 1
W311
†
9030090120 OPC-1800 1
W321
†
9030090130 OPC-1801 1
W331
†
9030090260 17/01/370/B11/B11 1
W332
†
9030090250 17/02/370/B11/B11 1
W333
†
9030090240 17/03/370/B11/B11 1
W334
†
9030090230 17/04/370/B11/B11 1
W335
†
9030090220 17/05/370/B11/B11 1
W336
†
9030090380 17/06/370/B11/B11 1
W341
†
9030090390 51/99/730/B11A/B11A 1
W342
†
9086400440 WIRE 08 A A 1
W343
†
9030090390 51/99/730/B11A/B11A 1
W344
†
9086400440 WIRE 08 A A 1
W345
†
9030090390 51/99/730/B11A/B11A 1
W346
†
9086400440 WIRE 08 A A 1
W347
†
9030090400 51/99/640/B11A/B11A 1
W348
†
9086400440 WIRE 08 A A 1
W351
†
9030090140 OPC-1802 1
W371
†
8900013060 OPC-1349 1
W381
†
9025900300 23/01/070/B09/B09 1
W382
†
9025900310 23/02/070/B09/B09 1
W383
†
9025900320 23/03/070/B09/B09 1
W384
†
9025900330 23/04/070/B09/B09 1
W385
†
9025900340 23/05/070/B09/B09 1
W386
†
9025900350 23/06/070/B09/B09 1
W387
†
9025900360 23/07/070/B09/B09 1
W388
†
9025900370 23WIRE /08/070/B09/B09 1
W389
†
9025900380 23/09/070/B09/B09 1
W390
†
9025900390 23/00/070/B09/B09 1
EP5 6910011941 ZCAT2436-1330A (-BK) 1
MP1 8010020910 3009 CHASSIS 1
MP2 8110009271 3009 U-COVER-1 1
MP3 8110009281 3009 L-COVER-1 1
MP4 8210024160 3009 REAR PANEL 1
MP5 8930074920 3009 A-SP ANGLE 1
MP6 8510018430 3009 DC-DC COVER 1
MP7 8930073120 3009 RF CONNECTOR ANGLE 1
MP8 8510018490 3009 RF COVER 1
MP9 8930073130 3009 MAIN CONNECTOR ANGLE 1
MP10 8510018440 3009 LOGIC CASE 1
MP11 8510018450 3009 LOGIC COVER 1
MP12 8510018500 3009 SCOPE PLATE 1
MP13 8510018510 3009 RF PLATE 1
MP14 8510018520 3009 A-RF PLATE 1
MP15 8510018530 3009 OSC PLATE 1
MP16 8510018480 3009 PLL COVER 1
MP19 8930061281 2590 ANT ANGLE-1 1
MP20 8930061350 2590 MAIN STAND 2
MP21 8930061840 2590 A-STAND SHEET 2
MP22 8930011680 RUBBER REG (G) 2
MP23 8510016281 2590 K-PLATE-1 1
MP24 8930056160 DOUBLESIDED TAPE (AG) 4
MP25 8510015851 2590 FILTER CASE-1 1
MP26 8930062770 HIMELON SHEET (CN) 1
MP29 8930073801 RACK MOUNT ANGLE (B)-1 2
MP101 8810008451 SCREW BiH M4X8 ZK3 14
MP102 8810008451 SCREW BiH M4X8 ZK3 7
MP103 8810008451 SCREW BiH M4X8 ZK3 4
†
