Icom IC-905 Reference Guide

8
REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data Description
1A* 05 SET > Connectors
01 17 00/01 USB/AV-OUT AF/IF Output
>
Send/read the Output Select setting
(00=AF, 01=IF)
01 18 00 00 ~ 02 55 USB/AV-OUT AF/IF Output
>
Send/read the AF Output Level
setting
(
00 00=0% ~ 02 55=100%)
01 19 00/01 USB/AV-OUT AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
01 20 00/01 USB/AV-OUT AF/IF Output
>
Send/read the AF Beep/Speech���
Output setting
(00=OFF, 01=ON)
01 21 00 00 ~ 02 55 USB/AV-OUT AF/IF Output
>
Send/read the IF Output Level
setting
(
00 00=0% ~ 02 55=100%)
01 22 00/01 LAN AF/IF Output >
Send/read the Output Select setting
(00=AF, 01=IF)
01 23 00/01
LAN AF/IF Output >
Send/read the AF SQL setting
(00=OFF (Open), 01=ON)
01 24 00 00 ~ 02 55 MOD Input >
Send/read the USB MOD Level setting
(00 00=0% ~ 02 55=100%)
01 25 00 00 ~ 02 55 MOD Input >
Send/read the LAN MOD Level setting
(00 00=0% ~ 02 55=100%)
01 26 00 ~ 03
MOD Input >
Send/read the DATA OFF MOD setting
( 00=MIC, 01=USB,
02=MIC, USB, 03=LAN)
01 27 00 ~ 03 MOD Input >
Send/read the DATA MOD setting
( 00=MIC, 01=USB,
02=MIC, USB, 03=LAN)
01 28 00 00 ~ 02 55 MOD Input >
Send/read the AV-IN MOD Level
setting
(00 00=0% ~ 02 55=100%)
01 29 00 ~ 05 MOD Input >
Send/read the ATV MOD setting
( 00=MIC, 01=AV-IN, 02=MIC, AV-IN,
03=USB, 04=MIC, USB, 05=LAN)
01 30 00/01 SEND Output >
Send/read the 144M setting
(00=OFF, 01=ON)
01 31 00/01 SEND Output >
Send/read the 430M setting
(00=OFF, 01=ON)
01 32 00/01 SEND Output >
Send/read the 1200M setting
(00=OFF, 01=ON)
01 33 00/01 SEND Output >
Send/read the 2400M setting
(00=OFF, 01=ON)
01 34 00/01 SEND Output >
Send/read the 5600M setting
(00=OFF, 01=ON)
Cmd� Sub cmd� Data Description
1A* 05 SET > Connectors
01 35 00/01 SEND Output >
Send/read the 10G setting
(00=OFF, 01=ON)
01 36 00 ~ 04 USB SEND/Keying >
Send/read the USB SEND setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L You cannot select the terminal
which is already selected in the
“USB Keying (CW)” or “USB
Keying (RTTY)” item�
01 37 00 ~ 04 USB SEND/Keying >
Send/read the USB Keying (CW)
setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L You cannot select the terminal
which is already selected in the
“USB SEND” item�
01 38 00 ~ 04 USB SEND/Keying >
Send/read the USB Keying (RTTY)
setting
( 00=OFF, 01=USB (A) DTR,
02=USB (A) RTS, 03=USB (B) DTR,
04=USB (B) RTS)
L You cannot select the terminal
which is already selected in the
“USB SEND” item�
01 39 00/01 External Keypad >
Send/read the VOICE setting
(00=OFF, 01=ON)
01 40 00/01 External Keypad >
Send/read the KEYER setting
(00=OFF, 01=ON)
01 41 00/01 External Keypad >
Send/read the RTTY setting
(00=OFF, 01=ON)
01 42 00/01 CI-V >
Send/read the CI-V Transceive setting
(00=OFF, 01=ON)
01 43 00/01 CI-V >
Send/read the CI-V USB Echo Back
setting
(00=OFF, 01=ON)
01 44 00 ~ 03 USB (B) Function >
Send/read the USB (B) Function
setting
( 00=OFF, 01=RTTY Decode,
02=DV Data, 03=Weather)
01 45 00/01 USB (B) Function >
Send/read the GPS Out setting
(00=OFF, 01=ON)
L It is valid when “USB (B) Function”
is set to “OFF” or “DV Data�”
01 46 00/01 Send/read the MIC Jack 8V
Output setting
(00=OFF, 01=ON)
01 47 00/01 Send/read the REF OUT setting
(00=Auto (CX-10G:ON), 01=ON)
