REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd�
Sub cmd� Data Description
1A* 05 SET > Display
01 48 00 00 ~ 02 55
Send/read the LCD Backlight setting
(00 00=0% ~ 02 55=100%)
01 49 00/01 Send/read the LCD Backlight Auto
Adjust setting
(00=OFF, 01=ON)
01 50 00 ~ 06
Send/read the Screen Saver setting
( 00=OFF, 01=1min, 02=2min,
03=5min, 04=15min, 05=30min,
06=60min)
01 51 00/01
Send/read the Screen OFF
[POWER] Switch setting
(00=OFF, 01=ON)
01 52 00/01
Send/read the Meter Peak Hold setting
(00=OFF, 01=ON)
01 53 00/01 Send/read the Multi-func� Meter
Voltage Display setting
(00=DC IN, 01=V)
01 54 00/01
Send/read the Memory Name setting
(00=OFF, 01=ON)
01 55 00/01 Send/read the Group Name Popup
setting
(00=OFF, 01=ON)
01 56 00 ~ 03
Send/read the RX Call Sign Display
setting
( 00=OFF, 01=Normal,
02=RX Hold, 03=Hold)
01 57 00/01
Send/read the RX Position Indicator
setting
(00=OFF, 01=ON)
01 58 00/01 Send/read the RX Position Display
setting
(00=OFF, 01=ON)
01 59 00 ~ 04 Send/read the RX Position Display
Timer setting
( 00=5sec, 01=10sec, 02=15sec,
03=30sec, 04=Hold)
01 60 00/01 Send/read the Reply Position
Display setting
(00=OFF, 01=ON)
01 61 00/01 Send/read the RX Picture Indicator
setting
(00=OFF, 01=ON)
01 62 00/01
Send/read the DV RX Backlight setting
(00=OFF, 01=ON)
01 63 00 ~ 02
Send/read the TX Call Sign Display
setting
( 00=OFF, 01=Your Call Sign,
02=My Call Sign)
01 64 00/01 Send/read the Scroll Speed setting
(00=Slow, 01=Fast)
01 65 00/01
Send/read the Opening Message setting
(00=OFF, 01=ON)
01 66 00/01
Send/read the Power ON Check setting
(00=OFF, 01=ON)
01 67 00 ~ 02 Display Unit >
Send/read the Latitude/Longitude
setting
02=ddd�dddd°)
Cmd�
Sub cmd� Data Description
1A* 05 SET > Display
01 68 00/01 Display Unit >
Send/read the Altitude/Distance setting
(00=m, 01=ft/mi)
01 69 00 ~ 02 Display Unit >
Send/read the Speed setting
(00=km/h, 01=mph, 02=knots)
01 70 00/01 Display Unit >
Send/read the Temperature setting
(00=°C, 01=°F)
01 71 00 ~ 03 Display Unit >
Send/read the Barometric setting
(00=hPa, 01=mb, 02=mmHg, 03=inHg)
01 72 00/01 Display Unit >
Send/read the Rainfall setting
(00=mm, 01=inch)
01 73 00 ~ 03 Display Unit >
Send/read the Wind Speed setting
(00=m/s, 01=km/h, 02=mph, 03=knots)
01 74 00/01
Send/read the Display Language setting
(00=English, 01=Japanese)
01 75 00/01
Send/read the System Language setting
(00=English, 01=Japanese)
SET > Time Set
01 76 20 20 01 01 ~
20 99 12 31
Date/Time >
Send/read the Date setting
( 20 20 01 01=2020/1/1 ~
20 99 12 31=2099/12/31)
01 77 00 00 ~ 23 59 Date/Time >
Send/read the Time setting
(00 00=00:00 ~ 23 59=23:59)
01 78 00/01 Date/Time >
Send/read the NTP Function setting
(00=OFF, 01=ON)
01 79 See p� 19� Date/Time >
Send/read the NTP Server Address
setting
(Up to 64 characters)
01 80 00/01
Date/Time >
Send/read the GPS Time Correct
setting
(00=OFF, 01=Auto)
01 81 See p� 21� Send/read the UTC Offset setting
SET > SD Card
01 82 00 ~ 02 Import/Export > CSV Format >
Send/read the Separator/Decimal
setting
( 00=Separator is “ , ” and Decimal is “ � ,”
01=Separator is “ ; ” and Decimal is “ � ,”
02=Separator is “ ; ” and Decimal is “ , ”)
01 83 00 ~ 02 Import/Export > CSV Format >
Send/read the Date setting
( 00=“yyyy/mm/dd,” 01=“mm/dd/yyyy,”
02=“dd/mm/yyyy”)
SCOPE > SCOPE SET
01 84 00/01 Send/read the Scope during Tx
(CENTER Type) setting
(00=OFF, 01=ON)
01 85 00 ~ 02 Send/read the Max Hold setting
( 00=OFF, 01=10s Hold, 02=ON)
