Icom IC-9700 Service Manual

TABLE OF CONTENTS
SECTION 1 SPECIFICATIONS
SECTION 2 INSIDE VIEWS
SECTION 3 INTERFACE INFORMATION
SECTION 4 ADJUSTMENT PROCEDURE
4-1 PREPARATION ……………………………………………………………………………………… 4-1
4-2 FRONT PANEL OPERATION VERIFICATION …………………………………………………… 4-4
4-3 TRANSMIT ADJUSTMENTS ……………………………………………………………………… 4-5
4-4 REFERENCE ADJUSTMENTS …………………………………………………………………… 4-8
4-5 RECEIVE ADJUSTMENTS ………………………………………………………………………… 4-9
SECTION 5 PARTS LIST
SECTION 6 MECHANICAL PARTS
SECTION 7 BOARD LAYOUTS
SECTION 8 WIRING DIAGRAM
SECTION 9 BLOCK DIAGRAM
SECTION 10 SCHEMATIC DIAGRAM
DISTRIBUTORS ADDRESS
www.PH4X.com

Icom IC-9700 Specifications

General

Receiver Type	Triple conversion superheterodyne
Display	4.3 inch color TFT touch screen
Type	VHF/UHF/1.2GHz All Mode Transceiver
Receiver System	Triple conversion superheterodyne
D-STAR	Yes
Antenna Impedance	50 ohms
Power Supply	13.8V DC ±15%
Frequency Range	144-146 MHz, 430-440 MHz, 1240-1300 MHz
Mode	FM, SSB, CW, AM
Antenna Connector	2m/70cm: SO-239, 23cm: Type-N
Dimensions	240 x 94 x 238 mm
Weight	Approx. 4.7 kg
RF Power Output	2m/70cm: 100W, 23cm: 10W
GPS	Yes (Internal)
Sensitivity	0.18 μV (FM)
