SPECIFICATIONS AND OPTIONS
■ Specications
D General
• Frequency range:
IC-A120 118.000 to 136.99166 MHz
IC-A120E (AUS version) 118.000 to 136.97500 MHz
IC-A120E (Others) 118.000 to 136.99166 MHz
• Channel spacing: 25 kHz/8.33*
1
kHz
• Type of emission:
IC-A120 6K00A3E/5K60A3E (FCC/EXP)
6K00A3E (Industry Canada)
IC-A120E 6K80A3E/5K00A3E*
1
• Number of memory channels: 200
• Antenna impedance: 50 ø (nominal)
• Antenna connector: SO-239
• Power supply requirement: 13.75 V/27.5 V DC
(negative ground)
• Current drain (at 13.75 V):
TX 5.0 A
Maximum audio 4.0 A
• Operating temperature range:
IC-A120 –30˚C to +60˚C,
–22˚F to +140˚F
IC-A120E –20˚C to +55˚C
• Dimensions:
(projections not included) 161 (W)✕45 (H)✕175 (D) mm,
6.3 (W)✕1.8 (H)✕6.9 (D) inches
• Weight (approximately): 1.5 kg, 3.3 lb
D Transmitter
• Output power:
IC-A120 9 W (Carrier power) typical
IC-A120E 9 W±1.5 dB
(+15˚C to +35˚C)
9 W+1.5 dB/–3dB
(–20˚C to +55˚C)
• Frequency stability:
IC-A120 ±5 ppm
(–30˚C to +60˚C, –22˚F to +140˚F)
IC-A120E ±1 ppm (0˚C to +40˚C)
• Modulation system: Last stage modulations
• Audio frequency distortion:
IC-A120 Less than 10%
(at 70% modulation)
IC-A120E Less than 10%
(at 85% modulation +3 dB)
• Spurious emissions:
IC-A120 Less than –60 dBc
IC-A120E*
2
9 kHz to 30 MHz Less than –46 dBm
30 MHz to 1 GHz Less than –36 dBm
(For Harmonics)
Less than –46 dBm
(For Non-Harmonics)
1 GHz to 4 GHz Less than –30 dBm
(For Harmonics)
Less than –40 dBm
(For Non-Harmonics)
*
1
Except IC-A120E (AUS version).
In Canada, use of 8.33 kHz Channel Spacing of this radio is strictly prohibited and shall not be used.
*
2
Except for operating frequency ±1 MHz.
