ACCESSORIES ATTACHMENTS
3
1
Attaching accessories (Continued)
D Belt clip
To attach:
1. Remove the battery pack from the transceiver, if it
is attached.
2. Slide the belt clip in the direction of the arrow until
the belt clip is locked and makes a ‘click’ sound.
To detach:
Lift the tab up (1), and slide the belt clip in the
direction of the arrow (2).
BE CAREFUL! Don’t break your ngernail.
Belt clip
2
1

Icom IC-A16 Specifications

General

Channel Spacing	8.33 kHz/25 kHz
Number of Memory Channels	200 channels
Antenna Impedance	50 Ω
Waterproof	IP67
Display	LCD
Frequency Range	118.000–136.9916 MHz
Output Power	6 W (PEP), 1.8 W (carrier)
Weight	Approx. 300 g (with standard battery)
Power Supply Requirement	7.2 V DC
Current Drain (Transmit)	1.5 A
Mode	AM
Channels	200
Voltage	7.2V
