Icom IC-A16 Full Manual

PANEL DESCRIPTION
5
2
Function display
1 2 3 4 5 6
7
8 9

1 FUNCTION ICON
Displayed for 3 seconds when you push [FUNC], to use secondary functions assigned to a key.
2 MEMORY CHANNEL ICON
Displayed when a Memory channel is selected. (p. 7)
3 TAG ICON
Displayed when a tagged Memory channel is selected. (p. 8)
4 BLUETOOTH ICON (For only the transceiver with the built-in Bluetooth unit)
Displayed when a Bluetooth headset is connected. (p. 12)
5 RX/TX ICON
Displayed while receiving or transmitting. (p. 7)
6 DUPLEX ICON
z Displayed when the Duplex function is ON. (p. 11)
z Blinks while entering a duplex frequency into a Memory channel. (p. 11)
7 AUTOMATIC NOISE LIMITER ICON
Displayed when the Automatic Noise Limiter function is ON. (p. 7)
8 WEATHER ALERT ICON (For only the USA version.)
Displayed when the Weather Alert function is ON. (p. 11)
9 LOCK ICON [
]
Displayed when the Lock function is ON. (p. 4)
 LOW BATTERY ICON
z Displayed when charging is required.
z Blinks when the battery exhausted.

Icom IC-A16 Specifications

General

Channel Spacing	8.33 kHz/25 kHz
Number of Memory Channels	200 channels
Antenna Impedance	50 Ω
Waterproof	IP67
Display	LCD
Frequency Range	118.000–136.9916 MHz
Output Power	6 W (PEP), 1.8 W (carrier)
Weight	Approx. 300 g (with standard battery)
Power Supply Requirement	7.2 V DC
Current Drain (Transmit)	1.5 A
Mode	AM
Channels	200
Voltage	7.2V
