4-4 RECEIVE ADJUSTMENTS
1) Select an adjustment item by pushing [CLR]/[MR].
2)Setormodifytheadjustmentvalueasspeciedbypush[ ▲ ]/[ ▼ ], and then push [ENT].
ADJUSTMENT
ADJUSTMENT
ITEM NAME
TRANSCEIVER’S
CONDITION
OPER ATION VALUE
RECEIVE
TRACKING
(AM)
1 T1 • Frequency: 108.025 MHz
• Receiving
• Connect the standard signal
generator (SSG) to the antenna
connector and set it as:
Frequency: 108.025 MHz
Level: 0 dBµ (–107 dBm)
Modulation: None
Push [ENT]
(Automatic
adjustment)
2 T2 • Frequency: 127.500 MHz
• Receiving
• Set the SSG as:
Frequency: 127.500 MHz
3 T3 • Frequency: 136.975 MHz
• Receiving
• Set the SSG as:
Frequency: 136.975 MHz
(FM)
*
4 T4 • Frequency: 161.650 MHz
• Receiving
• Set the SSG as:
Frequency: 161.650 MHz
5 T5 • Frequency: 163.275 MHz
• Receiving
• Set the SSG as:
Frequency: 163.275 MHz
NOISE
SQUELCH
LEVEL
(AM)
1 NL • Frequency: 118.025 MHz
• Receiving
• Connect the SSG to the antenna
connector and set it as:
Frequency: 118.025 MHz
Level: –10 dBµ (–117 dBm)
Modulation: None
Push [ENT]
(Automatic
adjustment)
2 • Frequency: 127.500 MHz
• Receiving
• Set the SSG as:
Frequency: 127.500 MHz
3 • Frequency: 136.975 MHz
• Receiving
• Set the SSG as:
Frequency: 136.975 MHz
(AM-Narrow) 4 • Frequency: 118.030 MHz
• Receiving
• Set the SSG as:
Frequency: 118.025 MHz
5 • Frequency: 127.505 MHz
• Receiving
• Set the SSG as:
Frequency: 127.500 MHz
6 • Frequency: 136.980 MHz
• Receiving
• Set the SSG as:
Frequency: 136.975 MHz
(FM)
*
7 • Frequency: 162.550 MHz
• Receiving
• Set the SSG as:
Frequency: 162.550 MHz
Level: –17 dBµ (–124 dBm)
S-METER
SQUELCH
LEVEL
(AM)
1 OS • Frequency: 118.025 MHz
• Receiving
• Connect the SSG to the antenna
connector and set it as:
Frequency: 118.025 MHz
Level: –10 dBµ (–117 dBm)
Modulation: None
Push [ENT]
(Automatic
adjustment)
2 CS • Set the SSG as:
Level: –13 dBµ (–120 dBm)
3 OT • Set the SSG as:
 Level: +13dBµ(–94dBm)
4 CT • Set the SSG as:
 Level: +10dBµ(–97dBm)
(AM-Narrow) 5 OS • Frequency: 118.030 MHz
• Receiving
• Set the SSG as:
Frequency: 118.025 MHz
Level: –10 dBµ (–117 dBm)
6 CS • Set the SSG as:
Level: –13 dBµ (–120 dBm)
7 OT • Set the SSG as:
 Level: +13dBµ(–94dBm)
8 CT • Set the SSG as:
 Level: +10dBµ(–97dBm)
(FM)
*
9 OS • Frequency: 162.550 MHz
• Receiving
• Set the SSG as:
Frequency: 162.550 MHz
Level: –10 dBµ (–117 dBm)
10 CS • Set the SSG as:
Level: –13 dBµ (–120 dBm)
11 OT • Set the SSG as:
 Level: +13dBµ(–94dBm)
12 CT • Set the SSG as:
 Level: +10dBµ(–97dBm)
*
No adjustment is necessary for the EUR versions.
