2-2
• FRONT UNIT (BOTTOM VIEW)
SPEAKER
(SP1: CHASSIS UNIT)
FRONT PANEL
FRONT UNIT
J1
RESET IC
(IC509)
Bluetooth MODULE
(IC506)
BUFFER
(IC507)
+3.3 V REGULATOR
(IC508)
