Icom IC-A25C

(Replacement page)
REF
NO.
PART
NO.
DESCRIPTION QT Y.
REF
NO.
PART
NO.
DESCRIPTION QT Y.
SECTION 6 MECHANICAL PARTS
6-1a
March 2019
REF
NO.
PARTS
NO.
DESCRIPTION QT Y.
SP1 2510002150 C36N07M-7 1
W1 8900009641 OPC-963 -1 1
EP1 3310005090 GNBA-A13A [#11] 1
3310005090 GNBA-A13A [#12] 1
3310005090 GNBA-A13A [#13] 1
3310005090 GNBA-A13A [#14] 1
3310005090 G N BA -A13A [#16] 1
3310005090 G N BA -A13A [#17] 1
EP2 8940000081 3699 KEY P.C.B.-1 1
MP1 8010024120 3699 CHASSIS 1
MP2 8210032970 3699 FRONT PANEL ASSEMBLY [#11] 1
8210032970 3699 FRONT PANEL ASSEMBLY [#12] 1
8210032970 3699 FRONT PANEL ASSEMBLY [#13] 1
8210032970 3699 FRONT PANEL ASSEMBLY [#14] 1
8210032970 3699 FRONT PANEL ASSEMBLY [#16] 1
8210032970 3699 FRONT PANEL ASSEMBLY [#17] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#21] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#22] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#23] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#24] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#27] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#31] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#33] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#34] 1
8210032960 3699 FRONT PANEL (A) ASSEMBLY [#36] 1
MP5 8310091150 3699 WINDOW PLATE 1
MP6 8610016330 KNOB N-449 1
MP7 8610016340 KNOB N-450 1
MP10 8930096800 3699 JACK CAP (KOB) 1
MP11 8930096810 3699 DC CAP 1
MP12 8930096820 3699 MAIN SEAL (SHJ) 1
MP13 8930096830 3699 MIC RUBBER (TOP) 1
MP14 8930096840 3699 CONTACT RUBBER (TOP) 1
MP15 8930098760 INSULATION SHEET (OP) [#11] 1
8930098760 INSULATION SHEET (OP) [#12] 1
8930098760 INSULATION SHEET (OP) [#13] 1
8930098760 INSULATION SHEET (OP) [#14] 1
8930098760 INSULATION SHEET (OP) [#16] 1
8930098760 INSULATION SHEET (OP) [#17] 1
MP16 8930096850 3699 WINDOW SHEET 1
MP18 8930083690 3322 GPS SPONGE [#11] 1
8930083690 3322 GPS SPONGE [#12] 1
8930083690 3322 GPS SPONGE [#13] 1
8930083690 3322 GPS SPONGE [#14] 1
8930083690 3322 GPS SPONGE [#16] 1
8930083690 3322 GPS SPONGE [#17] 1
MP20 8830004260 3776 ANT NUT 1
MP21 8830003900 VR NUT (AF) 1
MP23 8930074350 O-RING (BW) (KSK) 1
MP24 8930088050 O-RING (CS) (TOT) 1
MP25 8930090100 O-RING (CX) (TOT) 1
MP26 8850003421 SEALING WASHER (AA)-1 (TOT) 1
MP27 8930098360 3699 VOL RUBBER (TOP) 1
MP28 8930084870 3384 REAR SHEET 1
MP29 8930088670 3521 VENT SHEET 1
MP30 8930068980 2905 VENT SHEET 1
MP32 8930083700 DOUBLE SIDE TAPE (BM) [#11] 1
8930083700 DOUBLE SIDE TAPE (BM) [#12] 1
8930083700 DOUBLE SIDE TAPE (BM) [#13] 1
8930083700 DOUBLE SIDE TAPE (BM) [#14] 1
8930083700 DOUBLE SIDE TAPE (BM) [#16] 1
8930083700 DOUBLE SIDE TAPE (BM) [#17] 1
MP34 8810011050 BT O M2×3 NI-ZC3 11
MP35 8810009181 BT M2×5 NI-ZC3 2
MP36 8810009511 PH BT M2×4 NI-ZC3 (3.6-4.0) 1
MP37 8810011050 BT O M2×3 NI-ZC3 6
MP38 8810010850 PH BT B0 M2×8 SUS SSBC 2
MP39 8810011830 TAPPING SCREW B0 2×4 SUS SSBC 1
MP40 8850003250 PLAIN WASHER (AU) 1
MP41 8950009290 3766 T-KEY (B) (YTP) [#11] 1
8950009290 3766 T-KEY (B) (YTP) [#12] 1
8950009300 3766 T-KEY (C) (YTP) [#13] 1
8950009300 3766 T-KEY (C) (YTP) [#14] 1
8950009290 3766 T-KEY (B) (YTP) [#16] 1
8950009290 3766 T-KEY (B) (YTP) [#17] 1
8950009310 3766 T-KEY (D) (YTP) [#21] 1
8950009310 3766 T-KEY (D) (YTP) [#22] 1
8950009320 3766 T-KEY (E) (YTP) [#23] 1
8950009320 3766 T-KEY (E) (YTP) [#24] 1
8950009310 3766 T-KEY (D) (YTP) [#27] 1
8950009310 3766 T-KEY (D) (YTP) [#31] 1
8950009320 3766 T-KEY (E) (YTP) [#33] 1
8950009320 3766 T-KEY (E) (YTP) [#34] 1
8950009310 3766 T-KEY (D) (YTP) [#36] 1
MP42 8930097220 3699 SP HOLDER 1
MP43 8930097830 3699 SPONGE 2
DS5 5030004360 TM128160D1CIWUGND 1
S23* 2260003320 SKRTLAE010 1
S24* 2260003320 SKRTLAE010 1
S25* 2260003320 SKRTLAE010 1
MP1* 8510022120 3699 VCO CASE [#11] 1
8510022120 3699 VCO CASE [#12] 1
MP2 8930096860 3699 WHITE SHEET 1
MP3 8930096870 3699 LCD FILTER 1
MP4 8930094680 DOUBLE SIDE TAPE (CC) 2
MP5 8210032890 3699 REFLECTOR 1
MP6 8510022280 3699 CPU SHIELD 1
MP7 8930097820 3699 LCD HOLDER 1
MP8 8930083700 DOUBLE SIDE TAPE (BM) 1
[MAIN UNIT] (for #11, #12, #21, #22, and #31)
[LOGIC UNIT] (for #11, #12, #21, #22, and #31)
[CHASSIS UNIT]
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
MC1 7700003060 F6027AP-SBC-462 1
S1 2260003640 SKHLLCA010 1
MP1* 8410003040 3699 PA HEATSINK 1
MP3* 8510022120 3699 VCO CASE 1
MP5 8950009230 3699 CONTACT SPRING 1
MP10 8930097700 3699 JACK SHEET 1
MP11 8510022270 3699 ANT SHIELD 1
MP12 8510022260 3699 PA CASE 1
MP20 8930070581 SHIELD SPONGE (BA)-1 1
MP21 8930085101 SHIELD SPONGE (CW)-1 1
MP22 8930085111 SHIELD SPONGE (CX)-1 1
MP23 8930058510 INSULATION SHEETHC 1
MP24 8930084910 THERMAL SHEET (CB) 2
REF
NO.
PART
NO.
DESCRIPTION QT Y.
[CHASSIS UNIT]
MP44 8930098420 SPONGE (PK) 2
MP45 8930098420 SPONGE (PK) 1
MP46 8930098430 SPONGE (PL) 3
MP47 8930098410 SPONGE (PJ) 1
MP49 8930098420 SPONGE (PK) 2
The underlined parts have been updated from the previous version of the addendum, or the original page.
