Icom IC-A25C Service Manual

4-2
ENTERING THE ADJUSTMENT MODE ■
Right click the CS-A25's icon on the desktop and select 1.
the "Properties."
• The CS-A25 properties window appears.
Append " /Expert" to the end of the contents of the Target 2.
field, and then click [OK].
• A space is necessary before slash.
Append “ /Expert,”
then click [OK].
Boot up the programming software, CS-A25.3.
Connect the transceiver and the PC using with the OPC-4.
478UC, and then turn the power ON.
Read the transceiver data into the PC.5.
Set "Adjustment Mode" in the "Expert" to "Enable."6.
Click
Select “Enable”
Write the data to the transceiver.7.
Turn the power OFF, and then disconnect the OPC-8.
478UC from the transceiver.
While holding down [9. F] and [CLR], turn ON the power.
• Enters to the adjustment mode.
While holding down
Turn the power ON
ADJUSTMENT MODE SCREEN ■
Adjustment frequency
Adjustment item name
A
djustment item number
KEY ASSIGNMENTS FOR THE ADJUSTMENT ■
MODE
Push [• Y] to select the next adjustment item, push [Z] to
select the previous adjustment item.
Rotate [DIAL] to set or modify the adjustment value.•
Push [ENT] to store the adjusted value, and select the •
next adjustment item.
[Y]
[DIAL]
[Z]
[ENT]

Icom IC-A25C Specifications

General

Purpose	Aviation Service (Air Band)
Operating frequency	118.000 – 136.992 MHz
Display type	LCD
Display diagonal	2.3 \
Battery type	BP-288
Battery life (max)	10.5 h
Battery low indication	Yes
Number of batteries supported	1
Product color	Black
Operating temperature (T-T)	-10 - 60 °C
Number of batteries included	1 pc(s)
Antenna connector type	FA-B02AR

Weight and Dimensions

Depth	31.8 mm
Width	58.9 mm
Height	148.4 mm
Weight	384 g
