Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[MAIN UNIT] (for #11, #12, #21, #22, and #31) [MAIN UNIT] (for #11, #12, #21, #22, and #31)
5-7a
C79 4030023090 S.CER 0402B102K500CT B 30.3/100.9
C80 4030023090 S.CER 0402B102K500CT B 24.4/93.7
C81 4030023090 S.CER 0402B102K500CT B 28.2/94.7
C82 4030023030 S.CER 0402B103K250CT B 32.9/92.6
C83 4030023090 S.CER 0402B102K500CT B 33.8/92.6
C84 4030023090 S.CER 0402B102K500CT B 33.8/93.8
C85 4030022700 S.CER 0402N180J500CT B 34.1/95.1
C86 4030022580 S.CER 0402N7R0C500CT B 20.1/85.3
C87 4030022560 S.CER 0402N5R0B500CT B 13.7/99.9
C88 4030023030 S.CER 0402B103K250CT B 25.7/78.0
C90 4030023090 S.CER 0402B102K500CT B 29.0/76.2
C91 4030022590 S.CER 0402N8R0C500CT B 38.5/67.7
C92 4030023020 S.CER 0402B473K160CT B 35.6/64.9
C93 4030023090 S.CER 0402B102K500CT B 31.7/67.9
C95 4030023030 S.CER 0402B103K250CT B 31.6/68.8
C97 4550007520 S.TAN F931A106MAABMA B 36.6/81.0
C98 4030022640 S.CER 0402N101J500CT B 29.1/71.8
C99 4030023030 S.CER 0402B103K250CT B 28.6/70.6
C100 4030023200 S.CER 0402B471K500CT B 29.9/69.0
C101 4030019560 S.CER GRM21BB31C106KE15L B 36.5/78.1
C102 4030023200 S.CER 0402B471K500CT B 28.6/69.3
C103 4030022540 S.CER 0402N3R0B500CT B 43.0/74.1
C104 4030023030 S.CER 0402B103K250CT B 37.0/68.2
C106 4030023010 S.CER 0402B104K160CT B 40.1/70.6
C107 4030020000 S.CER C1005 JB 1A 105K-T T 42.6/67.4
C110 4030023090 S.CER 0402B102K500CT B 36.5/104.1
C113 4030023010 S.CER 0402B104K160CT B 42.8/80.9
C115 4030023010 S.CER 0402B104K160CT B 29.3/63.3
C116 4030023090 S.CER 0402B102K500CT T 18.5/75.9
C117 4030023090 S.CER 0402B102K500CT T 19.5/80.9
C118 4030023030 S.CER 0402B103K250CT T 18.6/80.9
C121 4030019560 S.CER GRM21BB31C106KE15L T 35.3/110.2
C125 4030023030 S.CER 0402B103K250CT T 21.9/109.5
C126 4030023010 S.CER 0402B104K160CT T 26.6/122.4
C127 4030023090 S.CER 0402B102K500CT T 33.9/109.6
C130 4510009700 S.ELE EEEFK1C101P T 37.9/115.5
C150 4030022680 S.CER 0402N150J500CT B 11.0/55.0
C151 4030022600 S.CER 0402N9R0C500CT B 11.9/51.8
C152 4030023090 S.CER 0402B102K500CT B 14.6/53.8
C153 4030023090 S.CER 0402B102K500CT B 14.1/49.0
C155 4030022810 S.CER 0402N330J500CT T 12.5/50.7
C156 4030023090 S.CER 0402B102K500CT B 15.9/48.9
C168 4550007550 S.TAN F931V334MAABMA T 17.6/38.3
C169 4550007390 S.TAN F931C225MAABMA B 25.0/48.6
C170 4030022720 S.CER 0402N1R5B500CT T 19.2/42.6
C171 4030023090 S.CER 0402B102K500CT B 12.8/59.1
C172 4030023010 S.CER 0402B104K160CT B 8.3/52.0
C173 4550008160 S.TAN F931A226MAA B 7.7/55.0
C174 4030023010 S.CER 0402B104K160CT B 22.2/50.1
C176 4030023010 S.CER 0402B104K160CT T 16.4/109.4
C180 4030023010 S.CER 0402B104K160CT T 34.7/18.7
C187 4030023010 S.CER 0402B104K160CT B 17.0/25.9
C188 4030017480 S.CER C1608 JB 1A 474K-T B 18.0/26.4
C190 4030022750 S.CER 0402N221J500CT B 14.4/104.1
C191 4030023030 S.CER 0402B103K250CT B 31.5/103.5
C192 4030023090 S.CER 0402B102K500CT B 26.9/99.6
C193 4030023090 S.CER 0402B102K500CT B 26.8/98.7
C196 4030023010 S.CER 0402B104K160CT B 22.6/28.8
C197 4030023020 S.CER 0402B473K160CT B 27.3/62.2
C201 4030022840 S.CER 0402N390J500CT B 38.5/68.6
C202 4030023010 S.CER 0402B104K160CT B 15.0/6.8
C211 4030023330 S.CER 0603N4R0B500CT T 13.2/119.4
C212 4030023700 S.CER 0603N390J500CT T 6.7/96.3
C223 4030024520 S.CER C1005 JB 1C 474K-T B 33.3/21.5
C225 4030024050 S.CER 0603B473K500CT B 6.8/12.9
C229 4030023030 S.CER 0402B103K250CT T 44.6/68.8
C232 4030022530 S.CER 0402N2R0B500CT B 24.1/91.6
C235 4030020000 S.CER C1005 JB 1A 105K-T B 8.2/108.9
C237 4030023090 S.CER 0402B102K500CT B 40.8/118.2
C238 4550007270 S.TAN F931A475MAABMA T 38.5/120.9
C239 4030022980 S.CER 0402B473K100CT B 44.7/116.2
C240 4030023090 S.CER 0402B102K500CT B 40.3/116.3
C241 4030023090 S.CER 0402B102K500CT B 45.3/114.2
C242 4030023010 S.CER 0402B104K160CT B 37.7/24.7
C243 4030023090 S.CER 0402B102K500CT B 40.4/114.5
C245 4030023010 S.CER 0402B104K160CT T 35.3/103.8
C249 4030023090 S.CER 0402B102K500CT T 27.2/52.8
C274 4030023090 S.CER 0402B102K500CT B 36.2/84.6
C293 4030023090 S.CER 0402B102K500CT B 12.7/4.0
C294 4030020000 S.CER C1005 JB 1A 105K-T B 29.6/55.7
C296 4030023760 S.CER 0603N680J500CT T 9.2/87.2
C297 4030023530 S.CER 0603N181J500CT T 6.7/95.1
C301 4030023090 S.CER 0402B102K500CT B 13.1/43.6
C302 4030022810 S.CER 0402N330J500CT T 20.9/42.6
C306 4030023670 S.CER 0603N330J500CT T 16.7/45.0
C307 4030022570 S.CER 0402N6R0C500CT T 11.7/42.3
C308 4030023090 S.CER 0402B102K500CT B 11.8/44.2
C309 4030023090 S.CER 0402B102K500CT B 11.4/46.5
C310 4030023670 S.CER 0603N330J500CT T 19.5/48.0
C311 4030023790 S.CER 0603N820J500CT T 9.5/45.2
C312 4030023090 S.CER 0402B102K500CT T 16.4/46.3
C313 4030023090 S.CER 0402B102K500CT T 12.5/48.6
C315 4030023670 S.CER 0603N330J500CT T 12.2/45.2
C316 4030024490 S.CER 0402NR75B500CT T 16.3/48.4
C317 4030024490 S.CER 0402NR75B500CT T 12.4/49.7
C319 4030023090 S.CER 0402B102K500CT T 19.6/49.8
C321 4030023030 S.CER 0402B103K250CT B 36.1/68.2
C323 4030023030 S.CER 0402B103K250CT B 27.3/94.7
C327 4030023090 S.CER 0402B102K500CT B 28.7/103.3
C328 4030023090 S.CER 0402B102K500CT B 26.9/101.1
C329 4030022530 S.CER 0402N2R0B500CT B 21.2/104.9
C330 4030023030 S.CER 0402B103K250CT B 31.1/58.4
C331 4030023010 S.CER 0402B104K160CT B 12.5/10.2
C333 4030023090 S.CER 0402B102K500CT B 6.8/97.0
C335 4030023670 S.CER 0603N330J500CT T 12.9/46.4
C336 4030022860 S.CER 0402N470J500CT T 10.5/42.2
C338 4030023670 S.CER 0603N330J500CT T 18.6/44.4
C347 4030023010 S.CER 0402B104K160CT B 36.5/76.7
C349 4550007550 S.TAN F931V334MAABMA B 24.9/41.1
C350 4030022860 S.CER 0402N470J500CT T 16.7/75.9
C351 4030022750 S.CER 0402N221J500CT T 7.2/67.1
C352 4030023090 S.CER 0402B102K500CT T 9.2/72.7
C354 4030023090 S.CER 0402B102K500CT B 36.2/61.6
C355 4030021240 S.CER C1005 JB 1C 105K-T B 30.8/38.8
C356 4030023010 S.CER 0402B104K160CT B 40.1/72.5
C357 4030022980 S.CER 0402B473K100CT B 35.1/66.9
C361 4030022550 S.CER 0402N4R0B500CT B 30.3/81.1
C364 4030022540 S.CER 0402N3R0B500CT B 32.5/90.4
C365 4030022680 S.CER 0402N150J500CT B 33.5/84.2
C372 4030023090 S.CER 0402B102K500CT T 15.4/91.0
C373 4030023090 S.CER 0402B102K500CT T 11.1/66.7
C375 4030022610 S.CER 0402N0R3B500CT T 9.7/112.8
C376 4030023090 S.CER 0402B102K500CT B 32.9/50.0
C377 4030022620 S.CER 0402N0R5B500CT T 10.2/49.3
C379 4030023330 S.CER 0603N4R0B500CT T 16.8/43.8
C381 4030023090 S.CER 0402B102K500CT B 36.2/62.8
C383 4030023330 S.CER 0603N4R0B500CT T 11.4/43.6
C384 4030021520 S.CER GRM31CB31H106KA12L T 25.0/109.6
C385 4030021240 S.CER C1005 JB 1C 105K-T T 21.6/106.1
C386 4030022560 S.CER 0402N5R0B500CT T 11.7/41.2
C387 4030023090 S.CER 0402B102K500CT B 28.4/41.5
C388 4030023090 S.CER 0402B102K500CT T 20.3/90.4
C389 4030022560 S.CER 0402N5R0B500CT T 12.1/39.0
C390 4030023090 S.CER 0402B102K500CT B 32.8/76.8
C391 4030022900 S.CER 0402N680J500CT B 26.5/76.4
C392 4030023090 S.CER 0402B102K500CT B 23.6/75.2
C393 4030020000 S.CER C1005 JB 1A 105K-T B 24.7/76.4
C394 4030023030 S.CER 0402B103K250CT B 23.8/76.4
C395 4030023090 S.CER 0402B102K500CT B 15.9/54.2
C396 4030022660 S.CER 0402N120J500CT B 15.1/56.7
C397 4030022680 S.CER 0402N150J500CT B 16.2/60.5
C398 4030022860 S.CER 0402N470J500CT B 42.1/74.1
C399 4030022650 S.CER 0402N110J500CT B 42.8/75.6
C400 4030022640 S.CER 0402N101J500CT B 41.2/74.1
C401 4030022550 S.CER 0402N4R0B500CT B 41.2/75.5
C402 4030022880 S.CER 0402N560J500CT B 40.3/74.1
C403 4030023090 S.CER 0402B102K500CT B 33.0/43.9
C405 4030023090 S.CER 0402B102K500CT B 19.4/99.2
C407 4030020450 S.CER C1005 JB 0J 475M-T B 16.3/105.4
C418 4030023090 S.CER 0402B102K500CT T 40.3/12.6
C420 4030023090 S.CER 0402B102K500CT T 37.3/104.8
C429 4030022860 S.CER 0402N470J500CT T 16.4/91.0
C430 4030021240 S.CER C1005 JB 1C 105K-T B 22.7/78.8
C431 4030023090 S.CER 0402B102K500CT T 37.2/16.9
C432 4030023090 S.CER 0402B102K500CT B 38.1/106.7
C438 4030022630 S.CER 0402N100C500CT B 32.9/41.4
C439 4030022640 S.CER 0402N101J500CT B 43.7/69.2
C440 4030023090 S.CER 0402B102K500CT B 33.8/41.4
C441 4030020000 S.CER C1005 JB 1A 105K-T B 34.8/38.9
C443 4030023090 S.CER 0402B102K500CT B 23.1/39.7
C444 4030023010 S.CER 0402B104K160CT B 35.4/46.5
C445 4030021240 S.CER C1005 JB 1C 105K-T B 34.8/44.3
C446 4030023030 S.CER 0402B103K250CT B 45.1/79.6
C451 4030023010 S.CER 0402B104K160CT B 24.4/81.3
C458 4030023010 S.CER 0402B104K160CT B 29.9/91.1
C459 4030023010 S.CER 0402B104K160CT B 31.0/80.1
C460 4030023010 S.CER 0402B104K160CT B 40.0/75.8
C461 4030023010 S.CER 0402B104K160CT T 25.3/85.9
C462 4030023010 S.CER 0402B104K160CT T 38.2/72.1
C463 4030023010 S.CER 0402B104K160CT T 26.2/72.1
C464 4030023010 S.CER 0402B104K160CT T 44.5/71.7
C466 4030023010 S.CER 0402B104K160CT T 28.9/72.3
C467 4030023010 S.CER 0402B104K160CT T 42.1/71.7
C468 4030023010 S.CER 0402B104K160CT T 26.2/86.8
C469 4030023010 S.CER 0402B104K160CT B 26.7/84.2
C470 4030023010 S.CER 0402B104K160CT B 26.6/89.5
C471 4030023010 S.CER 0402B104K160CT B 33.7/90.8
C472 4030023010 S.CER 0402B104K160CT B 33.1/80.6
C473 4030022560 S.CER 0402N5R0B500CT B 41.6/70.4
C474 4030022570 S.CER 0402N6R0C500CT B 43.9/72.8
C475 4030022880 S.CER 0402N560J500CT B 41.3/71.7
C476 4030023090 S.CER 0402B102K500CT B 26.8/80.2
C477 4030023090 S.CER 0402B102K500CT B 29.7/94.7
C478 4030023030 S.CER 0402B103K250CT B 22.0/64.9
C479 4030023030 S.CER 0402B103K250CT B 24.9/62.8
C481 4030019560 S.CER GRM21BB31C106KE15L B 9.6/109.5
C484 4030023030 S.CER 0402B103K250CT B 8.7/52.9
C485 4030023090 S.CER 0402B102K500CT T 25.7/66.2
C486 4030023090 S.CER 0402B102K500CT T 26.7/66.2
C487 4030023090 S.CER 0402B102K500CT T 27.7/66.2
C488 4030019560 S.CER GRM21BB31C106KE15L B 9.5/106.0
C489 4030020000 S.CER C1005 JB 1A 105K-T B 24.2/72.3
C490 4030023010 S.CER 0402B104K160CT B 35.7/38.9
C491 4030023090 S.CER 0402B102K500CT B 31.5/57.5
C492 4030020450 S.CER C1005 JB 0J 475M-T T 28.9/70.5
C493 4030020450 S.CER C1005 JB 0J 475M-T T 40.3/71.7
C495 4030021520 S.CER GRM31CB31H106KA12L T 19.6/82.7
C496 4030021520 S.CER GRM31CB31H106KA12L T 21.3/107.7
C508 4030023090 S.CER 0402B102K500CT T 14.4/41.4
C509 4030023090 S.CER 0402B102K500CT T 13.9/38.5
C510 4030023090 S.CER 0402B102K500CT B 26.6/45.7
C511 4030022640 S.CER 0402N101J500CT B 29.4/40.4
C512 4030024500 S.CER C1005 JB 1C 224K-T B 30.3/40.4
C513 4030019560 S.CER GRM21BB31C106KE15L B 27.6/38.7
The underlined parts have been updated from the previous version of the addendum, or the original page.
