Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[MAIN UNIT] (for #11, #12, #21, #22, and #31) [MAIN UNIT] (for #11, #12, #21, #22, and #31)
5-8a
C514 4030023010 S.CER 0402B104K160CT B 33.9/44.3
C515 4030023010 S.CER 0402B104K160CT B 32.4/48.1
C516 4030019560 S.CER GRM21BB31C106KE15L B 28.4/49.8
C517 4030023010 S.CER 0402B104K160CT B 29.9/38.8
C518 4030023090 S.CER 0402B102K500CT B 26.3/50.7
C519 4030023090 S.CER 0402B102K500CT B 28.7/47.7
C520 4030023090 S.CER 0402B102K500CT B 15.5/42.4
C521 4030023090 S.CER 0402B102K500CT B 16.4/47.7
C522 4030023090 S.CER 0402B102K500CT T 19.5/50.7
C523 4030023090 S.CER 0402B102K500CT B 21.9/38.5
C524 4030023090 S.CER 0402B102K500CT B 21.5/37.3
C525 4030023090 S.CER 0402B102K500CT B 44.1/67.8
C526 4030022630 S.CER 0402N100C500CT B 42.4/67.8
C527 4030021240 S.CER C1005 JB 1C 105K-T B 40.5/65.4
C528 4030023010 S.CER 0402B104K160CT B 39.6/65.4
C529 4030023010 S.CER 0402B104K160CT B 44.5/64.6
C530 4030021240 S.CER C1005 JB 1C 105K-T B 41.9/63.1
C531 4030023010 S.CER 0402B104K160CT T 21.0/62.0
C532 4030019560 S.CER GRM21BB31C106KE15L T 26.5/54.9
C533 4030023010 S.CER 0402B104K160CT T 24.8/54.9
C534 4030023090 S.CER 0402B102K500CT T 32.5/33.3
C535 4030023010 S.CER 0402B104K160CT T 24.8/36.0
C536 4030019560 S.CER GRM21BB31C106KE15L T 24.7/34.0
C537 4030023010 S.CER 0402B104K160CT T 30.5/33.8
C538 4520000020 S.NIO NOJC227M006RWJV T 30.3/26.1
C539 4030023090 S.CER 0402B102K500CT B 41.3/96.4
C541 4030021240 S.CER C1005 JB 1C 105K-T B 34.8/27.6
C542 4030023010 S.CER 0402B104K160CT B 34.5/23.2
C543 4030023090 S.CER 0402B102K500CT T 15.9/9.5
C544 4030023090 S.CER 0402B102K500CT T 13.0/6.6
C549 4030017810 S.CER C1608 CH 1H 102J-T B 5.6/31.1
C550 4030022910 S.CER 0402N681J500CT B 8.7/33.2
C551 4030018620 S.CER C1608 CH 1H 222J-T B 6.0/28.1
C552 4030022820 S.CER 0402N331J500CT B 9.0/28.0
C553 4030019570 S.CER C1608 CH 1H 332J-T B 5.6/19.4
C554 4030022670 S.CER 0402N121J500CT B 8.0/23.4
C555 4030022350 S.CER C1608 CH 1H 822JT B 5.5/14.7
C557 4030022930 S.CER 0402N821J500CT B 11.4/35.3
C558 4030022930 S.CER 0402N821J500CT B 13.0/31.7
C559 4030022690 S.CER 0402N151J500CT B 10.5/33.2
C560 4030020170 S.CER C1608 CH 1H 472J-T B 13.7/27.4
C561 4030022870 S.CER 0402N471J500CT B 11.2/28.3
C562 4030020940 S.CER C1608 CH 1H 392JT B 14.1/22.1
C563 4030022640 S.CER 0402N101J500CT B 12.1/23.2
C564 4030020160 S.CER C1608 CH 1H 103J-T B 14.1/19.1
C565 4030022680 S.CER 0402N150J500CT B 9.3/18.3
C566 4030021240 S.CER C1005 JB 1C 105K-T T 41.5/35.4
C567 4030021240 S.CER C1005 JB 1C 105K-T T 41.9/36.8
C568 4030021240 S.CER C1005 JB 1C 105K-T T 40.9/25.9
C569 4030023010 S.CER 0402B104K160CT T 42.6/26.5
C570 4030023010 S.CER 0402B104K160CT T 39.6/26.3
C571 4030019560 S.CER GRM21BB31C106KE15L T 35.0/37.1
C572 4030019560 S.CER GRM21BB31C106KE15L T 37.6/34.9
C573 4030023090 S.CER 0402B102K500CT T 9.1/21.3
C574 4030022900 S.CER 0402N680J500CT B 27.5/10.2
C577 4030021520 S.CER GRM31CB31H106KA12L B 21.7/9.3
C579 4030021520 S.CER GRM31CB31H106KA12L B 23.8/9.3
C580 4030021520 S.CER GRM31CB31H106KA12L B 34.9/6.7
C585 4030023010 S.CER 0402B104K160CT B 25.4/9.5
C586 4030023030 S.CER 0402B103K250CT B 26.3/9.5
C587 4030022870 S.CER 0402N471J500CT B 40.4/23.7
C588 4030022860 S.CER 0402N470J500CT B 41.6/21.9
C589 4030021240 S.CER C1005 JB 1C 105K-T B 39.1/22.5
C590 4030023090 S.CER 0402B102K500CT B 35.2/87.5
C591 4030022640 S.CER 0402N101J500CT B 36.9/88.1
C592 4030022640 S.CER 0402N101J500CT B 40.1/96.7
C593 4030023090 S.CER 0402B102K500CT B 41.5/94.8
C596 4030023090 S.CER 0402B102K500CT T 11.7/10.7
C597 4030023010 S.CER 0402B104K160CT B 26.6/26.3
C598 4030021240 S.CER C1005 JB 1C 105K-T B 25.7/26.3
C599 4030023090 S.CER 0402B102K500CT T 23.4/118.8
C602 4030023090 S.CER 0402B102K500CT T 21.2/120.6
C605 4030022640 S.CER 0402N101J500CT T 28.2/123.0
C608 4030019560 S.CER GRM21BB31C106KE15L B 21.2/29.9
C610 4030023090 S.CER 0402B102K500CT T 23.0/97.1
C612 4030019560 S.CER GRM21BB31C106KE15L T 27.8/91.6
C613 4030023090 S.CER 0402B102K500CT T 22.1/100.3
C614 4030023010 S.CER 0402B104K160CT T 25.7/92.4
C615 4030023010 S.CER 0402B104K160CT T 23.9/97.1
C616 4030023090 S.CER 0402B102K500CT T 24.8/92.4
C622 4030023060 S.CER 0402B183K250CT T 46.7/42.3
C623 4030023060 S.CER 0402B183K250CT T 46.7/40.7
C624 4030023010 S.CER 0402B104K160CT T 46.6/38.4
C627 4030023010 S.CER 0402B104K160CT B 10.8/9.2
C628 4030023010 S.CER 0402B104K160CT B 13.9/5.3
C629 4050000340 S.FEE NFM21PC224R1C3D B 32.9/6.7
C631 4030022560 S.CER 0402N5R0B500CT B 10.2/18.3
C632 4030022810 S.CER 0402N330J500CT B 7.6/17.6
C633 4030023010 S.CER 0402B104K160CT B 11.1/18.7
C634 4030023010 S.CER 0402B104K160CT B 13.0/24.2
C635 4030023010 S.CER 0402B104K160CT B 12.1/28.8
C636 4030023010 S.CER 0402B104K160CT B 13.1/15.0
C637 4030023010 S.CER 0402B104K160CT B 12.2/13.7
C638 4030023010 S.CER 0402B104K160CT B 25.5/57.0
C639 4030023090 S.CER 0402B102K500CT B 40.6/108.4
C640 4030023090 S.CER 0402B102K500CT B 45.6/104.3
C641 4030023010 S.CER 0402B104K160CT T 43.6/46.2
C642 4030023010 S.CER 0402B104K160CT T 47.9/39.2
C643 4030023010 S.CER 0402B104K160CT T 41.7/43.5
C644 4030023200 S.CER 0402B471K500CT T 48.0/41.1
C645 4030023010 S.CER 0402B104K160CT T 42.1/50.2
C646 4030019560 S.CER GRM21BB31C106KE15L T 32.8/91.3
C647 4030023010 S.CER 0402B104K160CT T 28.1/89.8
C648 4030023090 S.CER 0402B102K500CT B 12.2/60.3
C649 4030023090 S.CER 0402B102K500CT B 10.2/61.7
C650 4030023010 S.CER 0402B104K160CT T 19.8/15.8
C651 4030023010 S.CER 0402B104K160CT T 13.8/21.2
C652 4030023010 S.CER 0402B104K160CT T 11.7/15.2
C653 4030021240 S.CER C1005 JB 1C 105K-T T 22.0/97.1
C656 4030023090 S.CER 0402B102K500CT T 15.6/7.8
C660 4030023090 S.CER 0402B102K500CT B 6.6/67.2
C661 4030023010 S.CER 0402B104K160CT T 40.6/46.4
C662 4030023010 S.CER 0402B104K160CT T 41.2/44.9
C663 4030023010 S.CER 0402B104K160CT T 33.2/85.4
C664 4030023010 S.CER 0402B104K160CT B 36.5/41.7
C665 4030023070 S.CER 0402B223K250CT B 20.7/75.2
C666 4030023010 S.CER 0402B104K160CT T 34.3/22.5
C667 4030023090 S.CER 0402B102K500CT B 14.0/15.0
C668 4030023090 S.CER 0402B102K500CT B 12.0/18.7
C669 4030023090 S.CER 0402B102K500CT B 13.9/24.2
C670 4030023090 S.CER 0402B102K500CT B 13.0/29.4
C671 4030022640 S.CER 0402N101J500CT B 6.0/21.5
C672 4030022640 S.CER 0402N101J500CT B 6.9/16.1
C673 4030023090 S.CER 0402B102K500CT T 42.4/45.6
C674 4030023090 S.CER 0402B102K500CT T 16.1/22.4
C675 4030023090 S.CER 0402B102K500CT T 6.5/15.7
C676 4030023090 S.CER 0402B102K500CT T 19.3/79.5
C677 4030019560 S.CER GRM21BB31C106KE15L [#11] B 24.5/68.6
4030019560 S.CER GRM21BB31C106KE15L [#12]
C680 4030023010 S.CER 0402B104K160CT [#11] T 32.7/86.6
4030023010 S.CER 0402B104K160CT [#12]
C681 4030023010 S.CER 0402B104K160CT [#11] T 35.2/81.9
4030023010 S.CER 0402B104K160CT [#12]
C682 4030023010 S.CER 0402B104K160CT T 30.1/71.4
C683 4030023090 S.CER 0402B102K500CT B 43.1/94.4
C684 4030023090 S.CER 0402B102K500CT B 38.9/95.7
J1 6450000870 CON HEC2711-01-020
J2 6450000131 CON HSJ1102-018540
J4 6510021901 S.CON BM02B-ASRS-TF (LF) (SN) T 13.0/4.0
J5 6450001060 CON HSJ1493-01-010
J6 6510031230 S.CON 50P4.5-JMCS-G-TF (N) (1) T 35.7/54.3
MC1 7700003060 MIC F6027AP-SBC-462
S1 2260003640 SWI SKHLLCA010
EP3 6910014640 S.BEA MPZ2012S221A-T T 39.3/14.4
EP4 6910014640 S.BEA MPZ2012S221A-T T 19.5/121.0
EP5 6910014730 S.BEA MPZ2012S331A-T T 37.0/102.8
EP6 6910014730 S.BEA MPZ2012S331A-T B 40.2/110.9
EP7 6910014730 S.BEA MPZ2012S331A-T B 41.8/106.3
EP10 6910014730 S.BEA MPZ2012S331A-T T 13.9/8.6
EP11 6910014730 S.BEA MPZ2012S331A-T B 39.7/103.7
EP13 6910020610 S.BEA BLM15BD102SN1D T 15.7/47.5
EP14 6910020610 S.BEA BLM15BD102SN1D T 12.5/47.6
EP15 6910014640 S.BEA MPZ2012S221A-T T 39.7/18.7
EP16 6910014640 S.BEA MPZ2012S221A-T T 18.5/89.0
EP18 6910020610 S.BEA BLM15BD102SN1D T 27.7/56.8
EP19 6910020610 S.BEA BLM15BD102SN1D T 23.5/54.5
EP20 6910020610 S.BEA BLM15BD102SN1D T 26.6/42.9
EP21 6910020610 S.BEA BLM15BD102SN1D T 32.6/34.2
EP23 6910014730 S.BEA MPZ2012S331A-T T 12.2/8.6
EP24 6910014730 S.BEA MPZ2012S331A-T B 42.4/92.3
EP25 6910020610 S.BEA BLM15BD102SN1D B 36.5/87.2
EP26 6910020610 S.BEA BLM15BD102SN1D B 40.1/95.7
EP28 6910020610 S.BEA BLM15BD102SN1D T 26.9/110.8
EP29 6910014640 S.BEA MPZ2012S221A-T T 30.3/110.0
EP30 6910014640 S.BEA MPZ2012S221A-T B 34.9/10.9
EP31 6910020610 S.BEA BLM15BD102SN1D T 19.5/111.2
The underlined parts have been updated from the previous version of the addendum, or the original page.
