Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=
Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
(Amended page)
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
REF
NO.
PART
NO.
DESCRIPTION M
.
H/V
LOCATION
March 2019
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
5-9a
IC1 1190004712 S.IC HRM1016-010022 [#13] T 37.3/13.5
1190004712 S.IC HRM1016-010022 [#14]
1190004712 S.IC HRM1016-010022 [#16]
1190004712 S.IC HRM1016-010022 [#17]
IC11 1110003790 S.IC NJM2903V-TE1-#FMZB [#13] B 17.6/8.1
1110003790 S.IC NJM2903V-TE1-#FMZB [#14]
1110003790 S.IC NJM2903V-TE1-#FMZB [#16]
1110003790 S.IC NJM2903V-TE1-#FMZB [#17]
IC12 1110006470 S.IC LMV324IPWR [#13] B 24.1/19.7
1110006470 S.IC LMV324IPWR [#14]
1110006470 S.IC LMV324IPWR [#16]
1110006470 S.IC LMV324IPWR [#17]
IC13 1110006740 S.IC LMV358IPWR [#13] B 8.4/11.0
1110006740 S.IC LMV358IPWR [#14]
1110006740 S.IC LMV358IPWR [#16]
1110006740 S.IC LMV358IPWR [#17]
IC17 1190004620 S.IC GSU-141A-098A [#13] B 23.8/85.9
1190004620 S.IC GSU-141A-098A [#14]
1190004620 S.IC GSU-141A-098A [#16]
1190004620 S.IC GSU-141A-098A [#17]
IC27 1140018060 S.IC R5F52108BDLK B 31.0/52.9
IC30 1180004760 S.REG S-1200B33-M5T1U [#13] T 18.2/10.2
1180004760 S.REG S-1200B33-M5T1U [#14]
1180004760 S.REG S-1200B33-M5T1U [#16]
1180004760 S.REG S-1200B33-M5T1U [#17]
IC31 1180004760 S.REG S-1200B33-M5T1U [#13] B 32.5/96.5
1180004760 S.REG S-1200B33-M5T1U [#14]
1180004760 S.REG S-1200B33-M5T1U [#16]
1180004760 S.REG S-1200B33-M5T1U [#17]
IC32 1110006490 S.IC LMV321IDCKR [#13] B 38.6/5.1
1110006490 S.IC LMV321IDCKR [#14]
1110006490 S.IC LMV321IDCKR [#16]
1110006490 S.IC LMV321IDCKR [#17]
IC34 1180003570 S.REG NJM2830U1-33-TE1-#ZZZB B 39.7/44.0
IC35 1130014260 S.IC SN74LVC2GU04DCKR B 29.0/13.8
IC36 1130014260 S.IC SN74LVC2GU04DCKR B 40.9/31.9
IC37 1130016621 S.IC GT24C128B-2ZLI-TR B 31.3/68.1
IC38 1110007780 S.IC NJU7704F3-28A-TE1-#ZZZH B 22.4/67.7
IC39 1110007780 S.IC NJU7704F3-28A-TE1
-#ZZZH [#13] T 22.1/13.2
1110007780 S.IC NJU7704F3-28A-TE1
-#ZZZH [#14]
1110007780 S.IC NJU7704F3-28A-TE1
-#ZZZH [#16]
1110007780 S.IC NJU7704F3-28A-TE1
-#ZZZH [#17]
IC40 1180005110 S.REG NJM2836DL3-05-TE1 B 31.8/35.9
IC41 1180003460 S.REG NJM2831F05-TE1-#ZZZB B 29.1/64.5
Q3 1530004190 S.TRA L2SC4617ST1G B 24.9/72.7
Q5 1590004070 S.TRA LDTC144EET1G [#13] T 36.3/21.2
1590004070 S.TRA LDTC144EET1G [#14]
1590004070 S.TRA LDTC144EET1G [#16]
1590004070 S.TRA LDTC144EET1G [#17]
Q13 1530004140 S.TRA L2SC4081RT1G [#13] B 21.1/12.6
1530004140 S.TRA L2SC4081RT1G [#14]
1530004140 S.TRA L2SC4081RT1G [#16]
1530004140 S.TRA L2SC4081RT1G [#17]
Q15 1590004530 S.TRA DMG564050R [#13] B 24.9/29.6
1590004530 S.TRA DMG564050R [#14]
1590004530 S.TRA DMG564050R [#16]
1590004530 S.TRA DMG564050R [#17]
Q16 1590004070 S.TRA LDTC144EET1G [#13] B 40.5/11.3
1590004070 S.TRA LDTC144EET1G [#14]
1590004070 S.TRA LDTC144EET1G [#16]
1590004070 S.TRA LDTC144EET1G [#17]
Q17 1590004070 S.TRA LDTC144EET1G [#13] T 19.9/17.9
1590004070 S.TRA LDTC144EET1G [#14]
1590004070 S.TRA LDTC144EET1G [#16]
1590004070 S.TRA LDTC144EET1G [#17]
Q22 1530004000 S.TRA 2SC4738-GR (TE85LF) B 32.4/14.2
Q23 1510001100 S.TRA 2SA1832-GR (TE85RF) B 28.1/17.0
Q24 1510001100 S.TRA 2SA1832-GR (TE85RF) B 40.8/28.5
Q25 1560001730 S.FET RUE002N02 TL B 35.8/29.7
Q31 1510001100 S.TRA 2SA1832-GR (TE85RF) T 14.7/13.5
Q32 1510001100 S.TRA 2SA1832-GR (TE85RF) T 13.4/18.5
Q33 1590004070 S.TRA LDTC144EET1G T 17.2/7.4
Q34 1590004070 S.TRA LDTC144EET1G T 14.8/15.5
D1 1750001810 S.DIO L1SS400T1G T 6.1/104.9
D2 1750002220 S.DIO DA6J101K0R T 3.4/16.6
D4 1750001810 S.DIO L1SS400T1G [#23] T 3.9/12.1
1750001810 S.DIO L1SS400T1G [#24]
1750001810 S.DIO L1SS400T1G [#27]
1750001810 S.DIO L1SS400T1G [#33]
1750001810 S.DIO L1SS400T1G [#34]
1750001810 S.DIO L1SS400T1G [#36]
D5 1750001810 S.DIO L1SS400T1G [#13] T 13.0/98.5
1750001810 S.DIO L1SS400T1G [#14]
1750001810 S.DIO L1SS400T1G [#23]
1750001810 S.DIO L1SS400T1G [#24]
1750001810 S.DIO L1SS400T1G [#33]
1750001810 S.DIO L1SS400T1G [#34]
D6 1750001810 S.DIO L1SS400T1G [#14] B 11.2/56.2
1750001810 S.DIO
L1SS400T1G [#17]
1750001810 S.DIO L1SS400T1G [#24]
1750001810 S.DIO L1SS400T1G [#27]
1750001810 S.DIO L1SS400T1G [#34]
D7 1750001970 S.ZEN DZ2J082M0L B 29.4/73.2
D8 1750001810 S.DIO L1SS400T1G B 32.5/72.5
D16 1750001810 S.DIO L1SS400T1G [#13] B 13.2/6.8
1750001810 S.DIO L1SS400T1G [#14]
1750001810 S.DIO L1SS400T1G [#16]
1750001810 S.DIO L1SS400T1G [#17]
D17 1750001810 S.DIO L1SS400T1G [#13] B 17.5/12.6
1750001810 S.DIO L1SS400T1G [#14]
1750001810 S.DIO L1SS400T1G [#16]
1750001810 S.DIO L1SS400T1G [#17]
D18 1750001790 S.DIO 1SS390 TE61 B 40.7/57.6
D34 1750001810 S.DIO L1SS400T1G B 26.3/36.4
D35 1750001810 S.DIO L1SS400T1G B 45.0/44.6
D46 1750001810 S.DIO L1SS400T1G [#13] T 17.8/12.6
1750001810 S.DIO L1SS400T1G [#14]
1750001810 S.DIO L1SS400T1G [#16]
1750001810 S.DIO L1SS400T1G [#17]
D47 1750001810 S.DIO L1SS400T1G B 32.5/17.4
D48 1750001810 S.DIO L1SS400T1G B 36.0/28.1
X1 6050013790 S.XTA CR-981 (19.6608 MHz) B 39.7/53.9
R3 7030015910 S.RES RMC1/16S-101JTH (100) [#13] B 33.6/8.2
7030015910 S.RES RMC1/16S-101JTH (100) [#14]
7030015910 S.RES RMC1/16S-101JTH (100) [#16]
7030015910 S.RES RMC1/16S-101JTH (100) [#17]
R5 7030016020 S.RES RMC1/16S-104JTH (100 k) B 23.5/70.8
R16 7030016020 S.RES RMC1/16S-104JTH (100 k) B 22.6/70.8
R17 7030015970 S.RES RMC1/16S-103JTH (10 k) B 26.9/73.2
R18 7030015970 S.RES RMC1/16S-103JTH (10 k) B 28.3/71.6
R25 7030016160 S.RES RMC1/16S-820JTH (82) T 11.0/35.2
R26 7030016160 S.RES RMC1/16S-820JTH (82) T 22.0/35.2
R28 7030016560 S.RES RMC1/16SJPTH [#13] B 31.8/8.2
7030016560 S.RES RMC1/16SJPTH [#14]
7030016560 S.RES RMC1/16SJPTH [#16]
7030016560 S.RES RMC1/16SJPTH [#17]
R60 7030016340 S.RES RMC1/16S-393JTH (39 k) [#13] B 22.0/8.4
7030016340 S.RES RMC1/16S-393JTH (39 k) [#14]
7030016340 S.RES RMC1/16S-393JTH (39 k) [#16]
7030016340 S.RES RMC1/16S-393JTH (39 k) [#17]
R61 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 13.3/8.8
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R62 7030016020 S.RES RMC1/16S-104JTH (100 k) [#13] B 12.2/8.4
7030016020 S.RES RMC1/16S-104JTH (100 k) [#14]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#16]
7030016020 S.RES RMC1/16S-104JTH (100 k) [#17]
R63 7030016330 S.RES RMC1/16S-153JTH (15 k) [#13] B 11.0/2.3
7030016330 S.RES RMC1/16S-153JTH (15 k) [#14]
7030016330 S.RES RMC1/16S-153JTH (15 k) [#16]
7030016330 S.RES RMC1/16S-153JTH (15 k) [#17]
R64 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 4.5/9.2
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R65 7030016040 S.RES RMC1/16S-224JTH (220 k) [#13] B 9.2/6.6
7030016040 S.RES RMC1/16S-224JTH (220 k) [#14]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#16]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#17]
R66 7030016040 S.RES RMC1/16S-224JTH (220 k) [#13] B 9.2/5.7
7030016040 S.RES RMC1/16S-224JTH (220 k) [#14]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#16]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#17]
R67 7030015970 S.RES RMC1/16S-103JTH (10 k) [#13] B 5.9/10.2
7030015970 S.RES RMC1/16S-103JTH (10 k) [#14]
7030015970 S.RES RMC1/16S-103JTH (10 k) [#16]
7030015970 S.RES RMC1/16S-103JTH (10 k) [#17]
R68 7030016200 S.RES RMC1/16S-274JTH (270 k) [#13] B 5.9/11.8
7030016200 S.RES RMC1/16S-274JTH (270 k) [#14]
7030016200 S.RES RMC1/16S-274JTH (270 k) [#16]
7030016200 S.RES RMC1/16S-274JTH (270 k) [#17]
R69 7030016360 S.RES RMC1/16S-123JTH (12 k) [#13] B 2.8/14.3
7030016360 S.RES RMC1/16S-123JTH (12 k) [#14]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#16]
7030016360 S.RES RMC1/16S-123JTH (12 k) [#17]
R72 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 9.9/15.3
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R73 7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#13] B 21.7/24.9
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#14]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#16]
7030015960 S.RES RMC1/16S-472JTH (4.7 k) [#17]
R74 7030016040 S.RES RMC1/16S-224JTH (220 k) [#13] B 21.7/24.0
7030016040 S.RES RMC1/16S-224JTH (220 k) [#14]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#16]
7030016040 S.RES RMC1/16S-224JTH (220 k) [#17]
R75 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 23.7/24.0
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
R76 7030016110 S.RES RMC1/16S-473JTH (47 k) [#13] B 22.7/26.4
7030016110 S.RES RMC1/16S-473JTH (47 k) [#14]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#16]
7030016110 S.RES RMC1/16S-473JTH (47 k) [#17]
The underlined parts have been updated from the previous version of the addendum, or the original page.
[LOGIC-1 UNIT]
( for #13, #14, #16, #17, #23, #24, #27, #33, #34, and #36)
