[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band S.=Surface mount
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT]
6-2 IC-F4/F4S
[MAIN UNIT]
IC1 1130007610 S.IC µPD3140GS-E1 (DS8)
IC2 1110003490 S.IC TA31136FN (D,EL)
IC3 1110003780 S.IC NJM2902V-TE1
IC4 1130008090 S.IC BU4066BCFV-E1
IC5 1110001810 S.IC TA7368F (TP1)
IC6 1180001080 S.IC S-81250PG-PD-T1
IC7 1140005620 S.IC X25080SI-2.7T6 [16 ch]
1130008670 S.IC 25LC160T-I/SN [2-BANK]
IC8 1140006460 S.IC HD6433875A40H [16 ch]
1140008380 S.IC HD6433875B26H [2-BANK]
IC10 1110003690 S.IC M62354GP 75EC
IC11 1110003500 S.IC S-80742SL-A6-T1
Q1 1560000950 S.FET 2SK2595AXTB
Q2 1560000960 S.FET 2SK2596BXTL
Q3 1530002620 S.TRANSISTOR 2SC3585 R44-T2B
Q4 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q5 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q6 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q7 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q8 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q9 1590002160 S.TRANSISTOR XP6401-(TX)
Q11 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q12 1580000720 S.FET 3SK239AXRTL
Q13 1580000680 S.FET 3SK241-R(TX)
Q15 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q16 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q17 1590002530 S.TRANSISTOR UN911H (TX)
Q18 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q19 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q20 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q21 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q22 1510000580 S.TRANSISTOR 2SA1362-GR (TE85R)
Q23 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q25 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q26 1590000430 S.TRANSISTOR DTC144EUA T106
Q27 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q28 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q29 1590001770 S.TRANSISTOR XP1213 (TX)
Q31 1590000660 S.TRANSISTOR DTC144TU T107
Q33 1590001650 S.TRANSISTOR XP4601 (TX)
Q34 1560000540 S.FET 2SK880-Y (TE85R)
Q35 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q36 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q37 1590000720 S.TRANSISTOR DTA144EUA T106
Q38 1590000430 S.TRANSISTOR DTC144EUA T106
Q400 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q401 1590001400 S.TRANSISTOR XP1214 (TX)
Q402 1590000430 S.TRANSISTOR DTC144EUA T106
Q403 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q404 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q405 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1790000620 S.DIODE MA77 (TX)
D2 1790000490 S.DIODE HSM88AS-TR
D3 1790000620 S.DIODE MA77 (TX)
D4 1790000620 S.DIODE MA77 (TX)
D5 1720000370 S.VARICAP HVU350TRF
D7 1720000670 S.VARICAP HVU17TRF
D8 1790000620 S.DIODE MA77 (TX)
D10 1720000370 S.VARICAP HVU350TRF
D11 1720000370 S.VARICAP HVU350TRF
D12 1720000370 S.VARICAP HVU350TRF
D15 1790001280 S.DIODE MA111 (TX)
D16 1790001200 S.DIODE MA6S121 (TX)
D17 1790001200 S.DIODE MA6S121 (TX)
D24 1750000130 S.DIODE DA204U T107
D25 1790000670 S.DIODE SB07-03C-TB
D26 1160000060 S.DIODE DAN202U T107
D27 1750000130 S.DIODE DA204U T107
D33 1790001280 S.DIODE MA111 (TX) F4 only
D400 1790001210 S.DIODE 1SS375-TL
D401 1720000370 S.VARICAP HVU350TRF
D402 1790001210 S.DIODE 1SS375-TL
D403 1720000370 S.VARICAP HVU350TRF
D404 1720000520 S.VARICAP 1T365-01-T8A
D405 1720000360 S.DIODE HSU88TRF
D406 1790000620 S.DIODE MA77 (TX)
FI1 2010002100 XTAL FL-267 (46.35 MHz) N
2010002120 XTAL FL-271 (46.35 MHz) W
FI2 2020001410 CERAMIC CFWM450G N
2020001270 CERAMIC CFWM450E W
X1 6050009991 XTAL CR-576A (15.3 MHz)
X2 6050008840 S.XTAL CR-463 (6.8 MHz)
X3 6070000210
S.DISCRIMINATOR CDBCA450CX24
L1 6200005780 S.COIL 33CS-Y655LY-03K=P3
[L], [ML], [MH]
6200005800 S.COIL 33CS-Y655LY-02M=P3
[H1], [H2]
L2 6200005770 S.COIL 33CS-Y655LY-04K=P3
[L], [ML]
6200005780 S.COIL 33CS-Y655LY-03K=P3
[MH]
6200005800 S.COIL 33CS-Y655LY-02M=P3
[H1], [H2]
L3 6200005770 S.COIL 33CS-Y655LY-04K=P3
[L], [ML]
6200005780 S.COIL 33CS-Y655LY-03K=P3
[MH]
6200005800 S.COIL 33CS-Y655LY-02M=P3
[H1], [H2]
L5 6110003230 S.COIL LA-515
L6 6200006780 S.COIL ELJRE 1N8Z-F [L]
6200006770 S.COIL ELJRE 1N5Z-F other
L7 6200005680 S.COIL ELJRE 15NG-F [L]
6200005670 S.COIL ELJRE 12NG-F other
L8 6200005400 S.COIL LL1608-F27NJ [L], [ML], [MH]
6200005380 S.COIL LL1608-F18NJ [H1], [H2]
L9 6200005400 S.COIL LL1608-F27NJ
L11 6200003690 S.COIL MC152-E558ANA-100051=P3
[L], [ML]
6200004110 S.COIL MC152-E558ANA-100050
[MH], [H1], [H2]
L12 6200003550 S.COIL MLF1608A 4R7K-T
L13 6200003960 S.COIL MLF1608A 1R0K-T
L14 6200002450 S.COIL LL2012-F15NK
L15 6200002100 S.COIL LQN 1A 17NJ04
L17 6200002320 S.COIL LQN 1A 8N8J04
L18 6200002320 S.COIL LQN 1A 8N8J04
L19 6200002320 S.COIL LQN 1A 8N8J04
L20 6200004480 S.COIL MLF1608D R82K-T
L21 6200005460 S.COIL LL1608-F82NJ [L]
6200005430 S.COIL LL1608-F47NJ other
L22 6200004660 S.COIL MLF1608A 1R8K-T
L24 6200004480 S.COIL MLF1608D R82K-T
L25 6200004480 S.COIL MLF1608D R82K-T
L26 6200003590 S.COIL EXCCL3225U1
L27 6200003590 S.COIL EXCCL3225U1
L400 6200003540 S.COIL MLF1608D R22K-T [L], [ML]
6200005430 S.COIL LL1608-F47NJ [MH], [H1], [H2]
L401 6200002100 S.COIL LQN 1A 17NJ04
L402 6200002320 S.COIL LQN 1A 8N8J04
L403 6200004780 S.COIL MLF1608A 1R5K-T
L404 6200004780 S.COIL MLF1608A 1R5K-T
L405 6200004110 S.COIL MC152-E558ANA-100050
L406 6200004780 S.COIL MLF1608A 1R5K-T
L407 6200003550 S.COIL MLF1608A 4R7K-T
L409 6200003550 S.COIL MLF1608A 4R7K-T
L410 6200003960 S.COIL MLF1608A 1R0K-T
L411 6200005400 S.COIL LL1608-F27NJ
L412 6200003960 S.COIL MLF1608A 1R0K-T
L413 6200005400 S.COIL LL1608-F27NJ [L]
6200005370 S.COIL LL1608-F15NJ [ML]
L414 6200003540 S.COIL MLF1608D R22K-T
L415 6200007220 S.COIL EXCCL4532U1
L416 6200003540 S.COIL MLF1608D R22K-T
L417 6200005400 S.COIL LL1608-F27NJ [MH]
6200005390 S.COIL LL1608-F22NJ [H1], [H2]
6 - 6
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F4/S
