[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band S.=Surface mount
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT][MAIN UNIT]
R1 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R2 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R3 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R5 7030000220 S.RESISTOR MCR10EZHJ 47 Ω (470)
R7 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R8 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R12 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R13 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R14 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R15 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R17 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R18 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R19 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R20 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R21 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R22 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R23 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R32 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) [MH]
7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) other
R33 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R34 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
[L], [ML], [MH]
7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
[H1], [H2]
R40 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R41 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R42 7410000950 S.ARRAY EXB-V8V 102JV
R44 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R45 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R46 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R48 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R49 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R50 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R51 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R52 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R53 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R54 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R55 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R59 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R62 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R63 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R64 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R65 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R66 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ)
R67 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R68 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R69 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R70 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R72 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R75 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R77 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R82 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) N
7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) W
R83 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R84 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R85 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R86 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) N
7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) W
R87 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) N
7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ) w
R88 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R89 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R90 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) N
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) W
R92 7310004110 S.TRIMMER EVM-1YSX50 B54 (503)
R93 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R94 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R95 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R96 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R97 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R98 7030003880 S.RESISTOR ERJ3GEYJ 244 V (240 kΩ) e
7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ) u
R99 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R100 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R101 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R102 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R103 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R104 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R105 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) N
7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω) W
R107 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ) N-e
7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) N-u
7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ) W-e
7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ) W-u
R108 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ) N
7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) W
R109 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R112 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R113 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) e
7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) u
R114 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R115 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R116 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R117 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R118 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R119 7310004090 S.TRIMMER EVM-1YSX50 B14 (103)
R120 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R121 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R122 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R123 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R125 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R126 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R127 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R128 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R130 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R131 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R132 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R133 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R134 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R135 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R137 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R139 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R141 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R142 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R144 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R146 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R147 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R148 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R149 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R150 7310004110 S.TRIMMER EVM-1YSX50 B54 (503)
R153 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R154 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ)
R155 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R156 7030000160 S.RESISTOR MCR10EZHJ 15 Ω (150)
R157 7030000160 S.RESISTOR MCR10EZHJ 15 Ω (150)
R158 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R159 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R160 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R161 7030007330 S.RESISTOR ERJ1WRSJR15U (0.15 Ω)
R162 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R163 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R164 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R165 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R166 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R167 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R168 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R169 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R170 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R171 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R172 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R174 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R176 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R178 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
R181 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R182 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
R183 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω)
R184 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R185 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R186 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R190 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R191 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R192 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R193 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R194 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R195 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R196 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R197 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R199 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R200 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R202 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R203 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
6 - 7
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
