Icom IC-F4 User Manual

[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band S.=Surface mount
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT][MAIN UNIT]
R204 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R205 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R207 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R208 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R209 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R210 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R214 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R215 7030005520 S.RESISTOR RR0816R-334-D (330 kΩ)
R216 7030005630 S.RESISTOR RR0816R-154-D (150 kΩ)
R218 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) e
7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) u
R219 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) e
7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) u
R220 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R221 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R224 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
N-[H1]/[H2]
7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
N-other
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
W-[H2]
7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
W-other
R226 7410000950 S.ARRAY EXB-V8V 102JV
R227 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R228 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R229 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R230 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R231 7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
R234 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R235 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R236 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R237 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R400 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R401 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R402 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R403 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R404 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R405 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R406 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω) N
7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) W
R407 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R408 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R409 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R410 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R411 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
[L], [ML]
7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
[MH], [H1], [H2]
R412 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R413 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R414 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R415 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R416 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R417 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R419 7030004040 S.RESISTOR ERJ3GEYJ 4R7 V (4.7 Ω)
R420 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
[L], [ML], [MH]
7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
[H1], [H2]
R421 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R422 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R424 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R425 7410000950 S.ARRAY EXB-V8V 102JV
R426 7410000950 S.ARRAY EXB-V8V 102JV
R427 7410000770 S.ARRAY EXB-V4V 102JV (1 kΩ)
R428 7410000950 S.ARRAY EXB-V8V 102JV
R429 7410000950 S.ARRAY EXB-V8V 102JV
R430 7410000950 S.ARRAY EXB-V8V 102JV
R431 7410000770 S.ARRAY EXB-V4V 102JV (1 kΩ)
R432 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R433 7410000950 S.ARRAY EXB-V8V 102JV
R434 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R436 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R437 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R438 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R439 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R440 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R441 7510000930 S.THERMISTOR NTCCF2012 3NH 103KC-T
R442 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R443 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R444 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R445 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R446 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R447 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R448 7030003210 S.RESISTOR ERJ3GEYJ 120 V (12 Ω)
R449 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R450 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R451 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R452 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R453 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ) N
7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) W
R454 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) e
7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) u
R455 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
e-N-[L]/[ML]/[MH]
7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
e-W-[L]/[ML]/[MH]
7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
u-N-[L]/[ML]/[MH]
7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
u-W-[L]/[ML]
7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
N-[H1]/[H2]
7030003710 S.RESISTOR ERJ3GEYJ 184 V (180 kΩ)
W-[H2]
R456 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R457 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R458 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R459 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R460 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
[L], [ML]
R461 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R464 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R465 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
[L], [ML]
7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
[MH], [H1], [H2]
R466 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R468 7030003540 S.RESISTOR ERJ3GEYJ 682 V (6.8 kΩ) e
7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) u
R469 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R470 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
[MH], [H1], [H2]
R471 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
C3 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A [MH]
4030007020 S.CERAMIC C1608 CH 1H 120J-T-A other
C5 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
[L]
4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
[ML]
4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
[MH]
4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[H1], [H2]
C7 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A [L]
4030009910 S.CERAMIC C1608 CH 1H 040B-T-A other
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C10 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C11 4030004880 S.CERAMIC C2012 CH 1H 120J-T-A
[L]
4030004850 S.CERAMIC C2012 CH 1H 080D-T-A
[ML]
4030004810 S.CERAMIC C2012 CH 1H 040C-T-A
[MH], [H1], [H2]
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C14 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C15 4030007060 S.CERAMIC C1608 CH 1H 270J-T-A [L]
4030009990 S.CERAMIC C1608 CH 1H 200J-T-A other
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C21 4510005310 S.ELECTROLYTIC ECEV1CA220SR
C22 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[L], [H1], [H2]
4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
[ML], [MH]
C24 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
6 - 8
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F4/S

Icom IC-F4 Specifications
