Icom IC-F4 User Manual

[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band S.=Surface mount
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT][MAIN UNIT]
C25 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C26 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C27 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C28 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C30 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C31 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C32 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C33 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C42 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C47 4550006410 S.TANTALUM ECST1VY334R [MH]
4550006360 S.TANTALUM ECST1VY104R other
C48 4550006450 S.TANTALUM ECST1EY105R
C51 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C52 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C53 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C54 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C55 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C56 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C57 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C58 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C59 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C60 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C61 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C62 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
C63 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C64 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C65 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C66 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C67 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C69 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C70 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C71 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C72 4550006320 S.TANTALUM ECST0JY475R
C73 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C75 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C76 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A [L]
4030006980 S.CERAMIC C1608 CH 1H 070D-T-A other
C77 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
[L], [ML]
4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
[MH]
4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
[H1], [H2]
C78 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[L], [ML]
4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
[MH], [H1], [H2]
C79 4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
C84 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C85 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
[L]
4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
[ML], [MH]
4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
[H1], [H2]
C86 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
[L]
4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
[ML]
4030009550 S.CERAMIC C1608 CH 1H 2R5B-T-A
[MH]
4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
[H1], [H2]
C87 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C88 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C89 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C90 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C91 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
[L]
4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[ML]
4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
[MH]
4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
[H1], [H2]
C92 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A [L]
4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[ML]
4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
[MH], [H1], [H2]
C93 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C94 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C95 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C96 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A
[L]
4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[ML]
4030011770 S.CERAMIC C1608 CH 1H 060B-T-A
[MH], [H1], [H2]
C97 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
[L]
4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
[ML]
4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
[MH]
4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
[H1], [H2]
C98 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C105 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C106 4030011770 S.CERAMIC C1608 CH 1H 060B-T-A N
4030007010 S.CERAMIC C1608 CH 1H 100D-T-A W
C107 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C108 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C109 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A N
4030007010 S.CERAMIC C1608 CH 1H 100D-T-A W
C112 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C113 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C114 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C115 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C116 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A N
4030007100 S.CERAMIC C1608 CH 1H 560J-T-A W
C117 4550006700 S.TANTALUM ECST1AY106R
C118 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C120 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C121 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C122 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C123 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C124 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C125 4030009980 S.CERAMIC C1608 JB 1H 152K-T-A
C126 4030010770 S.CERAMIC C1608 JB 1H 392K-T-A
C128 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C129 4550006680 S.TANTALUM ECST0JY156R
C131 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C132 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C133 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C134 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A N
4030007150 S.CERAMIC C1608 CH 1H 151J-T-A W
C135 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A N
4030007130 S.CERAMIC C1608 CH 1H 101J-T-A W
C136 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C137 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C139 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C140 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C141 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C142 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C143 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C144 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C145 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C146 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C147 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C148 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C149 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C150 4550006200 S.TANTALUM ECST0JY106R
C151 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C152 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C153 4550006670 S.TANTALUM ECST1AD107R
C154 4550006200 S.TANTALUM ECST0JY106R
C155 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C156 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C157 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C158 4510005320 S.ELECTROLYTIC ECEV0JA101SP
C159 4550006320 S.TANTALUM ECST0JY475R
C160 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C161 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C162 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C163 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C164 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C165 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C166 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C167 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C168 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
6 - 9
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F4/S
