5-4 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [
↑
] / [
↓
] of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [
←
] / [
→
] of the PC’s keyboard, then push [ENTER].
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
ADJUSTMENT
ITEM
VALUE
RECEIVE
SENSITIVITY
-Preparation-
1• Connect an SSG to the ant-
enna connector.
• Set the SSG as;
Frequency : 400.1000 MHz
[Low band]
450.1000 MHz
[High band]
Level : +20 dBµ (–87 dBm)
†
Modulation : 1 kHz
Deviation : 3.5 kHz
––
-Adjustment- 2 • Channel :
CH.12
• Receiving
1) Select the [BPF (T1)] item, then
push [ENTER].
2) Select the [BPF (T2)] item, then
push [ENTER].
[BPF (T1)]
[BPF (T2)]
(Automatic
adjustment)
CONVINIENT: [BPF (T1)] and [BPF (T2)] can be adjusted at the same time as below.
2 • Channel :
CH.12
• Receiving
• Select the [BPF ALL] item, then
push [ENTER].
[BPF ALL]
(Automatic
adjustment)
SQUELCH
-Preparation-
1• Connect an SSG to the ant-
enna connector.
• Set the SSG as;
Frequency : 400.1000 MHz
[Low band]
450.1000 MHz
[High band]
Level : –14 dBµ (–121 dBm)
†
Modulation : 1 kHz
Deviation : 3.5 kHz
––
-Adjustment- 2 • Channel : CH.12
• Receiving
1) Once close the squelch by
increasing the value of [SQL] item,
then decrease the value to open
the squelch.
2) Push [ENTER] to store the value.
[SQL]
(Automatic
adjustment)
†
; The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
