SPECIFICATIONS
P GENERAL
• Frequency coverage : 400–470 MHz [USA-06], [CSA-01], [CSA-03]
450–512 MHz [USA-07], [CSA-02], [CSA-04]
• Type of emission : 16K0F3E (25.0 kHz) for Wide
: 11K0F3E (12.5 kHz) for Narrow
• Channel spacing : 12.5/25.0 kHz
• Number of conventional channels : 16 ch
• Antenna impedance : 50
Ω
• Operating temperature range : –30˚C to +60˚C (–22˚F to +140˚F)
• Power supply requirement : Specified Icom's battery pack only (7.2 V DC nominal; negative ground)
• Current drain (at 7.2 V DC ; approx.) :
RECEIVING TRANSMITTING
Stand-by Max. audio
High (at 4 W) Low (at 1 W)
75 mA 300 mA 1.6 A 0.8 A
• Dimensions (projections not included) : 53.0 (W)×120.0 (H)×38.0 (D) mm; 2
3
⁄32(W)×4
23
⁄32(H)×1
1
⁄2(D) in
• Weight (Including BP-231) : Approx. 260 g (9
3
⁄16 oz)
P
TRANSMITTER
• Output power (at 7.2 V DC) : 4 W (Hi)/2 W (L2)/1 W (L1)
• Modulation : Variable reactance frequency modulation
• Maximum permissible deviation : ±5.0 kHz (Wide), ±2.5 kHz (Narrow)
• Frequency error : ±2.5 ppm
• Spurious emissions : 70 dB (min.)
• Adjacent channel power : 70 dB min. (75dB typ.) for Wide
60 dB min. (68dB typ.) for Narrow
• Audio harmonic distortion : 3% typ. (at 1 kHz, 40% deviation)
• FM Hum and Noise
(without CCITT filter)
: 40 dB min. (46 dB typ.) for Wide
34 dB min. (40 dB typ.) for Narrow
• Limiting charact of modulator : 60–100% of maximum deviation
• Microphone impedance : 2.2 k
Ω
P
RECEIVER
• Receive system : Double conversion superheterodyne system
• Intermediate frequencies : 1st IF: 46.35 MHz, 2nd IF: 450 kHz
• Sensitivity : 0.25 µV (–119 dBm) typ. at 12 dB SINAD
• Adjacent channel selectivity : 70 dB min. (75 dB typ.) for Wide
60 dB min. (65 dB typ.) for Narrow
• Spurious response : 70 dB min.
• Intermodulation rejection ratio : 70 dB min. (74 dB typ.)
• Hum and Noise (without CCITT filter) : 40 dB min. (45 dB typ.) for Wide
34 dB min. (40 dB typ.) for Narrow
• Audio output power : 0.5 W typ. (at 5% distortion with an 8
Ω
load)
• Squelch sensitivity (at threshold) : 0.25 µV typ.
• Output impedance (audio) : 8
Ω
Specifications are measured in accordance with TIA-603.
All stated specifications are subject to change without notice or obligation.
