2 - 1
SECTION 2
.
INSIDE
VIEWS
+5 Regulator
(IC9:
NJM2870F05)
AF amplifier
(IC12:
T
A7368F)
D/A conv
er
ter
(IC8:
M62363FP)
R5 Regulator
(Q22:
2SA1577)
CPU
(IC13:
HD6433687A91
F
S5 Regulator
Q23:
2SB1132
Q24:
XP6501
Q25:
UNR9113G0L
Crystal filter
(FI1:
FL-335)
FM IF IC
(IC1:
T
A31136FNG)
IF amplifier
(Q4:
2SC4215)
EEPROM
(IC15:
BR24L16FV)
P
ower amplifier
(Q7:
RD07MVS2)
T5 Regulator
(Q21:
2SA1577)
PLL IC
(IC4:
MB15A02PFV1)
Pre-drive
(Q5:
2SC3356)
APC amplifier
(IC2:
TC75S51F)
VCO circuit
T
OP VIEW
BO
TTOM VIEW
• MAIN UNIT
Drive amplifier
(Q8:
RD01MUS2)
4
6
Table of Contents
Default Chapter
3
Table of Contents
3
Specifications
4
Section 3Disassembly Instruction
7
Circuit Descripiton
7
Receiver Circuits
7
Transmitter Circuits
8
Pll Circuits
10
Other Circuits
11
Power Supply Circuits
11
Port Allocations
11
Adjustment Procedures
13
Preparation
13
Frequency Adjustments
16
Transmit Adjustments
17
Receive Adjustment
18
Parts List
19
Connect Unit
19
Ant Unit
19
Main Unit
20
Section 9Block Diagram
30
Voltage Diagram
30
