Icom IC-F6022 Instruction Manual

16
3
CONNECTION AND MAINTENANCE
■ Antenna
A key element in the performance of any communication
systems is an antenna. Contact your dealer for more infor-
mation regarding antennas and how to install them.
■ Fuse replacement
A fuse is installed in the supplied DC power cable. If a fuse
blows or the transceiver stops functioning, track down the
source of the problem if possible, and then replace the dam-
aged fuse with a new rated one.
❑Fuserating:10A
USE the 10 A fuse only.
■ Cleaning
If the transceiver becomes dusty or dirty, wipe it clean with a
soft, dry cloth.
DO NOT use solvents such as benzene or alco-
hol, as they may damage the transceiver surfaces.
■ Options
•OPC-1939a c c c a b l e
Allows you to connect to an external terminal.
•HM-152/HM-152T/HM-148G/HM-148T
h a n d m i c r o p h o n e
 HM-152 :Handmicrophone
 HM-152T :DTMFmicrophone
 HM-148G :Selfgroundheavydutymicrophone
 HM-148T :Selfgroundheavydutymicrophonewith10-keypad
The 10-keypad of this microphone can be used for the
DTMF code transmission only.
•SM-25
d e s k t o p m i c r o p h o n e
•SP-5/SP-10/SP-35 e x t e r n a l s p e a k e r
 Inputimpedance :4ø
 Maximuminputpower:5W(SP-5/SP-10)/7W(SP-35)
 SP-5 :Largespeakerforgoodaudioquality.
 SP-10 :Forall-roundmobileoperation.
 SP-35 :Compactandeasy-to-install.
•UT-108R
d t m f d e c o d e r u n i t
Provides pager and code squelch capabilities.
•UT-109R/UT-110R
s c r a m b l e r u n i t s
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice scrambler
unit provides higher communication security.
